OVER SOFA TABLE 10497
Please read and retain these instructions for future reference
PARTS:
A. Top board x 1
B. Back board x 1
C. Small side board x 2 ( C‐1 , C‐2)
D. Bottom board x 1
E. Side board of magazine rack x 2 (E‐1, E‐2)
F. Horizontal bar x 3
1. Bolts x 3
2. Nuts x 3
3. Screws x 12
4. Pads x 4
5. Plastic caps x 8
Instructions for Use
v001: 31/08/16
Advertisement
Related Manuals for Coopers of Stortford 10497
Summary of Contents for Coopers of Stortford 10497
- Page 1 OVER SOFA TABLE 10497 Instructions for Use Please read and retain these instructions for future reference v001: 31/08/16 PARTS: A. Top board x 1 B. Back board x 1 C. Small side board x 2 ( C‐1 , C‐2) D. Bottom board x 1 E. Side board of magazine rack x 2 (E‐1, E‐2) F. Horizontal bar x 3 1. Bolts x 3 2. Nuts x 3 3. Screws x 12 4. Pads x 4 5. Plastic caps x 8 ...
- Page 2 OVER SOFA TABLE 10497 Instructions for Use Please read and retain these instructions for future reference v001: 31/08/16 Assemble: 1. Set the Top board (A) upside down on a 2. Insert the back board (B) and tighten the clean, soft surface. Secure 3 bolts (1) into bolt by nut (2) inside of it. the holes in the Top (A). A 1 1 3. Assemble two small side boards (C) and 4. Use 4 screws (3) to secure back board (B) tighten bolts by nut (2). to two side board (C). C‐1 2 C‐2 5. Use 2 screws (3) to tighten the Bottom 6. Tighten the side board of magazine rack board (D) to Side board (B) and add 4 Pads (E‐1) by screws (3) from the side and (4) on 4 corners. bottom . ...
- Page 3 OVER SOFA TABLE 10497 Instructions for Use Please read and retain these instructions for future reference v001: 31/08/16 7. Insert 3 horizontal bar (F) to one 8. Put another side board o f magazine rack (E‐2) and using end of side board (E‐1). screws (3) to tighten it from side and bottom. E‐2 F ** The placement of screws (3) on ** Cover the plastic caps (5) on all screws holes. 2 side boards of magazine rack. 3 WARNINGS / CAUTIONS: Adult Assembly Required Do not place directly in front of or near sources of heat Periodically check that all fixings are secure and tighten if necessary. Weight limit: 6 kgs CLEANING INSTRUCTIONS: Clean with a dry cloth or duster. DISPOSAL: • Dispose of all packaging, paper, cartons and plastic, plastic bags in accordance with your local recycling regulations. ...
