Summary of Contents for Virgin MF62
- Page 1 BROADBAND Mini WiFi Modem MF62 User Guide...
-
Page 2: Table Of Contents
TABLE Of CONTENTS Pre-Paid Customers Is your account activated First up, you need to activate your service: CLICK virginmobile.com.au/activate Welcome to Virgin Mobile! NB: You’ll need a different internet connection to activate online. What's in the box or CALL 1300 763 039 System requirements See page 8 for the final steps to get online. -
Page 3: Welcome To Virgin Mobile
WELCOmE TO VIRgIN mOBILE! System requirements • Windows XP Service Pack 2, Windows Vista or Windows 7. Congratulations! That cool gadget you’ve got in your hands is going to let you take the internet with you, so you’ll never have to miss a beat. -
Page 4: Your First Connection
The first time you connect, you’ll be taken to a special page to register your broadband service. Incoming mail server mail.virginbroadband.com.au Enter your first and last names and set up your primary Virgin Broadband email address, which we’ll use to contact you from time to time. Outgoing mail server smtp.virginbroadband.com.au... -
Page 5: Managing Your Account
To check your account details, go to virginmobile.com.au/myaccount Checking your data usage & topping up your account and log in with your Virgin Broadband Service Number and the 6 digit PIN you set up when you opened the account. To check your usage, go to mybroadbandusage.virginbroadband. -
Page 6: General Information
WiFi. ZTE cannot guarantee that third party hardware or Password software is compatible with this product. Default SSID Virgin Wifi xxxxxx. Details printed under your battery. Default 10 characters which are case sensitive. Warnings and Safety Notices Security Key Details printed under your battery. - Page 7 WiFi Alliance interoperability testing and is compatible with any wireless device bearing the logo as shown. Radio frequency Energy The model number is MF62. Your wireless router is a low-power radio transmitter and receiver. Additional information is available at When switched on it intermittently transmits radio frequency (RF) http://www.Wifi.org/certification_programs.php...
-
Page 8: Getting Started
2.1 Insert your USIM 2 gETTINg STARTED 2.1 Insert your USIm 1. Slide the back cover down to open. 1. Slide the back cover down to open. 2.1 Insert your USIM 2. Insert the (U)SIM card with the gold contacts facing down and the bevelled Antenna 1. - Page 9 For these situations it is recommended that, in addition to the charger being connected, the battery is 2.3 Insert a microSD(HC)™ memory card (Optional fully charged before extended data transfers commence. 2.2 Charge your Wireless Router Accessory) Use the device as portable storage drive with up to 32GB 1.
-
Page 10: Using The Wireless Router
Your security key is case sensitive, be sure to • Your wireless router is locked to the Virgin network. use the correct text. • When you insert a non-Virgin SIM card you are presented with unlock instructions in the web interface (http://virginmf.com) 3.2 Login to the Web based User Interface The router will work out of the box using the default settings. - Page 11 3.4 WAN Connection Always On The modem will connect to the cellular network automatically. Always on does not refer to the WiFi connection status. To operate as ‘always on’ for WiFi make sure there is a WiFi device connected that does not itself go into sleep mode. Manual Select Manual mode to manually control when the unit connects to the cellular data service.
- Page 12 3g Settings Wifi Security Settings • OPEN: Anyone can connect to your network without Wireless View network status authentication. info • SHARED: WLAN clients who have the same WEP key as the Network Select your preferred network mode. Only change if wireless router can access the wireless network. instructed by your service provider.
- Page 13 firewall Settings Firewall settings are intended for advanced users and network administrators. There is usually no need to apply any settings in a home environment. Note: You can set up to a maximum of 10 filter items for mAC/IP/ Port Filtering and Port forwarding. mAC / IP / Port filtering • Default Policy: Set how to handle the packet if none of the rules match.
- Page 14 You can set up virtual servers to provide internet services. Select • View Frequently Asked Questions on line: www.zte.com.au/ firewall > Port forwarding > Enable to configure the Virtual Server virgin Settings. IP Address: Set the IP address for the virtual server.
-
Page 15: Troubleshooting
4 TROUBLESHOOTINg Symptoms Possible Problems/ Solutions Symptoms Possible Problems/ Solutions I cannot access Check the LCD display which shows the My battery has In low coverage or high data transfer modes number of active connections. If this is 0 not charged the internal temperature of the device can the internet at all. -
Page 16: Technical Specifications
5 TECHNICAL SPECIfICATIONS 6 SAfETY PRECAUTIONS Some electronic devices may be susceptible to electromagnetic • Network & frequency Band WCDMA: 900, 2100MHz interference. • gSm 850, 900, 1800, 1900MHz The router may interfere with medical devices like hearing aids and • Data Services HSDPA Downlink: up to pacemakers. - Page 17 A qUESTION WE HAVEN’T ANSWERED HERE ? • Try virginmobile.custhelp.com or • Email virginmobile.com.au/contactus • Virgin Mobile stores are dotted around Oz – check online for your nearest • Old school mail can be addressed to: Virgin mobile Locked Bag 17...
- Page 18 - 34 -...
