- Page 1 2015 360 Y-DROP ASSEMBLY INSTRUCTIONS CASE 80’/90’ BOOM...
- Page 2 While these steps will help you install most of your 360 Y-DROP system, you may need to custom fit some components, based on your particular boom.
- Page 3 1. From center of the machine, there are five (5) mounting zones on each of the primary side booms (first fold) in which the mounting brackets will be installed. This depends on the width of your boom and account for both 20” & 30” row spacing. Extend the right and left primary booms (first fold) and measure from machine center, marking both ends of each of the following zones on both right and left primary booms:...
- Page 4 2. Assemble mounting bracket in Zone 1 on the boom and leave loose, shown in Fig 2. 1. One (1) 6” z-slider bracket 2. Two (2) 5” top plates 3. Two (2) 3/8” x 4” bolts 4. Four (4) 3/8” flat washers 5” ...
- Page 5 3. Install remainder of the mounting brackets in Zones 2 through 5 and leave loose, shown in FIG 3: 1. One (1) 6” z-slider bracket 2. Two (2) 5” plates 3. Two (2) 3/8” x 4” bolts 4. Four (4) 3/8” flat washers 5. ...
- Page 6 FIG 4 b FIG 4 c ...
- Page 7 7. Install z-bars and stop bolts in all 12 z-brackets, leave loose and carefully fold sprayer booms into cradle to adjust fore/aft locations. 1. Twelve (12) 38” z-bars 2. Twelve (12) 5/16” x 3/4” stop bolts and nuts 8. Install 3” z-slider brackets and stop bolts on all z-bars, shown in FIG 5: 1. ...
- Page 8 10. On both the left and right boom wings, assemble four (4) 5’ boom sections with 8” connector bars using provided hardware. Another 5’ boom section will need to be field cut in half to extend the length FIG 7 needed for all 24Rx30”...
- Page 9 11. Assemble (8) 2-section yokes to be used as support straps from 360 Y- DROP boom to left & right upper sprayer boom, shown in FIG 8. Note: Length will need to be adjusted to fit distance between booms. 1. (2) 23”...
- Page 10 12. Install ( 6) 2 -‐SecHon y okes t o b oth l eL & r ight h and s prayer boom a nd 3 60 Y -‐DROP b oom, a s s hown i n F IG 9 a & 9 b, spaced ...
- Page 11 13. Assemble (2) 2-section yokes to center sprayer boom to 360 Y- DROP boom, shown in FIG 10a & 10b. Note: Length will need to be adjusted to fit distance between booms. 1. (2) 23” yoke straps 2. (4) yoke ends 3. ...
- Page 12 2-‐SecHon Y okes FIG 1 0b ...
- Page 13 14. Assemble riser mount brackets to square boom with stainless steel hardware provided and leave loose, shown in FIG 11. Quantity and spacing will depend on your system configuration and application profile. 1. Riser mount brackets 2. 5/16” x 1-3/8” U-Bolts 3. ...
- Page 14 16. Assemble d rag h oses t o 3 60 Y -‐DROP b ase u nit, s hown i n F IG 1 2, using h ose c lamps p rovided. ...
- Page 15 17. Attach riser tube assembly to 360 Y-DROP base unit using stainless steel wire lock pin, shown in FIG 13a & 13b. Repeat for every drop. FIG 1 3a FIG 1 3b ...
- Page 16 18. Attach riser tube assembly / 360 Y-DROP to riser mount bracket on the 360 Y-DROP boom with stainless steel wire lock pin, as shown in FIG 17a & 17b. Repeat for every drop. 19. Connect and route riser hoses from 360 Y-DROP base unit up riser and connect to sprayer nozzle body.
