Boiling water heater
Hydroboil
®
Application areas
Boiling water supply:
> O ces
> Canteens / Bistros
> Restaurants / Hotels
> Hospitals
> Catering services
Subject to technical changes and version changes. Errors and omissions excepted. Date of publication: 09.19
Product Information 1 / 6
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for clage Hydroboil 15
Summary of Contents for clage Hydroboil 15
- Page 1 Boiling water heater Hydroboil ® Application areas Boiling water supply: > O ces > Canteens / Bistros > Restaurants / Hotels > Hospitals > Catering services Subject to technical changes and version changes. Errors and omissions excepted. Date of publication: 09.19 Product information 1 / 6...
- Page 2 Boiling water heater Hydroboil ® Product information boiling > Hydroboil | Hydroboil | Hydroboil ® ® ® Part number [case painted white]: Water connection (thread connection): G ½" Temperature range [°C]: 99 – 100 Boiling water content [litres / cups 15 / 90 | 25 / 150 | 40 / 240...
- Page 3 Boiling water heater Hydroboil ® Installation The outlet of the automatic boiling water heater must be located above the sink or the Dimensions in mm drip tray. The bottom edge of the outlet should not be less than 200 mm above the drip tray.
- Page 4 Boiling water heater Hydroboil ® Installation The example shows the water connections when installing a Hydroboil Dimensions in mm ® as fl ush installation with visible collecting funnel. Assembly and operating instructions must be observed upon installation. Water inlet Safety overfl ow G ½"...
- Page 5 Boiling water heater Hydroboil ® Accessories KAT 1 (optional) Stainless steel-tableau, 32.5 × 17.5 cm KAT 1: Part no. 4100-44080 KAT 2 (optional) Stainless steel-tableau with drain connection, 32.5 × 17.5 cm KAT 2: Part no. 4100-44081 KAS 1 (optional) Collecting funnel for undersink installation, ¾-inch KAS 1: Part no.
- Page 6 Filter cartridge, capacity at 10 °KH 8.500 litre CLARIS ULTRA 1000: Part no. 84501 Filter cartridge, capacity at 10 °KH 20.000 litre CLARIS ULTRA 2000: Part no. 84502 CLAGE GmbH Phone +49 4131 8901-38 Pirolweg 1 – 5 +49 4131 2444771 21337 Lüneburg...
