LPD8 (AD01)
Service Manual
ATTENTION!
THIS DOCUMENT CONTAINS SENSITIVE
PROPRIETARY INFORMATION.
ALL RECIPIENTS MUST HAVE A CURRENT
NON-DISCLOSURE AGREEMENT ON FILE
WITH AKAI PROFESSIONAL, LLC.
DO NOT MAKE ILLEGAL
COPIES OF THIS DOCUMENT
The information in this document contains privileged and confidential information.
It is intended only for the use of those authorized by Akai Professional. If you are
not the authorized, intended recipient, you are hereby notified that any review,
dissemination, distribution or duplication of this document is strictly prohibited. If
you are not authorized, please contact Akai Professional and destroy all copies
of this document. You may contact Akai Professional at support@akaipro.com.
Copyright Akai Professional, LLC
Confidential
Akai Professional Service Manual
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Akai LPD8
Summary of Contents for Akai LPD8
- Page 1 COPIES OF THIS DOCUMENT The information in this document contains privileged and confidential information. It is intended only for the use of those authorized by Akai Professional. If you are not the authorized, intended recipient, you are hereby notified that any review, dissemination, distribution or duplication of this document is strictly prohibited.
- Page 2 Your purchase of the Manual shall be for your own ultimate use and shall not be for purposes of resale or other transfer. As the owner of the copyright to the Manual, Akai Professional does not give you the right to copy the Manual, and you agree not to copy the Manual without the written authorization of Akai Professional.
- Page 3 AKAI PROFESSIONAL DISTRIBUTOR AUTHORIZED REPAIR SERVICE CENTER IN THE PROVISION OF REPAIR SERVICES OR TO BE OR MAKE REPAIRS AS AN AUTHORIZED SERVICE CENTER. ALL REPAIRS DONE BY ANY ENTITY OTHER THAN AN AUTHORIZED AKAI PROFESSIONAL SERVICE CENTER SHALL SOLELY...
-
Page 4: Safety Instructions
The product is exposed to water or excessive moisture, c. The AC power supply plug or cord is damaged, d. The product shows an inappropriate change in performance or does not operate normally, or e. The enclosure of the product has been damaged. Confidential Akai Professional Service Manual... - Page 5 Confidential Akai Professional Service Manual...
- Page 6 Confidential Akai Professional Service Manual...
- Page 7 AKAI PROFESSIONAL LPD8 (AD01) TEST PROCEDURE Confidential Akai Professional Service Manual...
- Page 8 LPD8 USB cable AD01 Test Application Setup Attach USB cable between the LPD8 and PC. Start the AD01 Test Application Ensure the correct input and out devices are selected to properly communicate with the LPD8 When connected the unit should automatically enter TEST mode. The operator can change whether the unit is in Test mode or Normal mode by pressing the associated mode button.
- Page 9 The next test is the Button Test. The operator should press the button indicated on the application. The application will advance to the next button provided that only the indicated button is pressed. Confidential Akai Professional Service Manual...
- Page 10 The last test is the Knob Test. The operator should turn the indicated knob as indicated. Each knob should be turned to the minimum position and then turned fully clockwise. Confidential Akai Professional Service Manual...
- Page 11 AKAI PROFESSIONAL LPD8 (AD01) Exploded View & Confidential Akai Professional Service Manual...
- Page 12 8 pieces plastic caps with white silkscreen indication on it; Top plastic housing; 4keys rubber switch with electric carbon,1 is black and other 3 is white and black silkscreen on the top surface; 8keys white rubber PAD with black silkscreen on the top surface;...
- Page 13 MIDIPLUS Co., Ltd. 4F., No.82, Sec. 1, Hankou St. Taipei City, 100 Taiwan TEL: +886-3-3873500 FAX: +886-3-3872558 TO : AKAI professional ATTN : C.C. : FROM : MODEL: AD01 Vendor Leadtime Note YOURUN 2K 3days 041184000 LABEL FOR BOTTOM AD01,AD02 "ROHS" compliance Sticker 1.00...
- Page 14 AKAI PROFESSIONAL LPD8 (AD01) SCHEMATIC FILES Confidential Akai Professional Service Manual...
- Page 15 / FKDQJH WR X+ '& 2KP )@" ,-./012 /.30-45 " $ 222 26/-.327,./81,72+42 )" )" )" $ 222 2-,*0:,23;,2 2<011,<30-9 26=7,-2<;=18,2302>10+?.023;,-,2=-, 2>10+.9>,4226-0*2 2<;=18,2302 $2 (26-0*2 >2302 >$ 2@ 2<;=18,2/12302=2 =<>=8,?.023;=32 ;=:,2@ $ 222 (22-,*0:,2@ ?-,*0:,2@ ?<;=18,2 26-0*2 2302 ?<;=18,2B VKRUW LW QR / 6-0*2@ 2302 # 2...
- Page 17 AKAI PROFESSIONAL LPD8 (AD01) HISTORY Confidential Akai Professional Service Manual...
