4
GFK-0164G
August 1997
Batteries
A lithium battery (IC697ACC701) is installed as shown
in figure 2. This battery maintains user memory when
power is removed. Be sure to install the new battery
before removing the old battery.
Battery
Shelf life
Memory retention
Current required from 5V bus
Serial Ports
VME
[
Refer to GFK-0867B, or later for product standards and general specifications.
supported standards, such as FCC or CE Directives, please refer to the Installation Requirements for Conformance to Stan-
dards, shipped with the PLC programming software, for additional guidelines.
PCM, 12 Mhz, 20 Kbyte, Expandable
64 Kbyte CMOS Expansion Memory
128 Kbyte CMOS Expansion Memory
256 Kbyte CMOS Expansion Memory
512 Kbyte CMOS Expansion Memory
Lithium Battery
Note: For Conformal Coat option, or Low Temperature Testing option please consult the
factory for price and availability.
Table 3. References
Reference
1
Programing Software User 's Manual
2
Programmable Controller Reference Manual
3
PCM Support Software User 's Manual
4
MegaBasic Programming Language Reference Manual
5
Programmable Controller Installation Manual
Table 4. Specifications for IC697PCM711 [
Table 5. Ordering Information
Description
Programmable Coprocessor Module
If during power-up diagnostics a low battery is detected
the Module OK LED (top) will not stay on. Specific in-
dication of a low battery state is detailed in the PCM
Support Software User's Manual.
Title
10 years at 20 C (68 F)
6 months nominal without applied power.
1.0 amp
RS-232/RS-422/RS-485 compatible
System designed to support the VME standard C.1
If the PLC installation must comply with
Catalog Number
IC697PCM711
IC697MEM713
IC697MEM715
IC697MEM717
IC697MEM719
IC697A CC701
Coprocessor Modules
