UTC RETAIL 51 Series Installation Manual

Side mount/undercounter logic and cash drawer brackets

INSTALLATION GUIDE: SIDE MOUNT/UNDERCOUNTER LOGIC and

Safety Precautions for Installation

WARNING: Use of Proper Mounting Fasteners

The installer is responsible for using the correct fasteners for the mounting substrate to adequately support the weight

of the fully loaded logic enclosure and cash drawer.

CAUTION: Crush and Pinch Point Hazard

Keep fingers and hands clear of panel edges and mounting points while attaching the mounts

•

Upper and lower brackets for mounting the 51xx logic enclosure

•

Cable cover for logic enclosure (note that cables are not included in the kit)

•

Mounting bracket for 51xx cash drawer

•

Cash drawer locking bracket

•

Fasteners

o (2) #6-32 x ¼" screws

o (4) #8-32 x 3/8" screws

51XX Series Workstation

CASH DRAWER BRACKETS

11807008 Rev A

Table of Contents

Do you have a question about the 51 Series and is the answer not in the manual?

Page 1 Cable cover for logic enclosure (note that cables are not included in the kit) • Mounting bracket for 51xx cash drawer • Cash drawer locking bracket • Fasteners o (2) #6-32 x ¼” screws o (4) #8-32 x 3/8” screws © 2022 UTC RETAIL. All rights reserved. 11807008 Rev A...
Page 2 Place the upper bracket on top of the 51xx and align to front edge. • Place appropriate fasteners in the 3 slots and partially fasten, but do not fully tighten 11807008 Rev A © 2022 UTC RETAIL. All rights reserved.
Page 3 Insert two of the included #8-32 screws at the rear of the lower and upper brackets to secure the 51xx • Fully tighten the 3 upper bracket mounting fasteners • Install the 51xx power supply, 51xx logic module, and the front bezel cover. © 2022 UTC RETAIL. All rights reserved. 11807008 Rev A...
Page 4 After all I/O cables are installed, place the cable cover into the 2 center slots on the 51xx. • Secure the cable cover to the 51xx using #8-32 screws through at least one of the rear tabs. 11807008 Rev A © 2022 UTC RETAIL. All rights reserved.
Page 5 Place tab on the cash drawer locking bracket into the square slot in the cash drawer. Push drawer fully back. Secure the cash drawer bracket using the 2 supplied #6-32 screws. © 2022 UTC RETAIL. All rights reserved. 11807008 Rev A...
