- Page 1 USER GUIDE Thank you for selecting UTC RETAIL’s innovative Model 2600 Point of Sale solution! This guide is designed to acquaint you with the features and functionality of the 2600 Point of Sale System. © 2020 UTC RETAIL. All rights reserved.
-
Page 2: 2600 Pos System User Guide
If a unit needs to be shipped to UTC RETAIL for repairs, please return it in the original packaging material and shipping container. If you purchased the 2600 POS System through a dealer, and the dealer is unable to answer your questions, please call UTC RETAIL Technical Support at 1.800.349.0546. -
Page 3: Table Of Contents
Contents 2600 POS System User Guide ....................2 Product Information ........................4 2600 POS System Components ................4 Peripheral Support....................4 2600 POS System Specifications ................ 5 System Operation ....................5 I/O Panel ......................6 Connector Panel View ................6 COM Ports .................... -
Page 4: Product Information
15” Rear LCD Display without touch Peripheral Support • The 2600 POS System accepts a standard PC keyboard with a USB interface. UTC RETAIL P/N 10718020 contains both a USB keyboard and USB mouse. • The 2600 POS System was designed to coordinate with the UTC RETAIL PD1200 Pole Display option. -
Page 5: 2600 Pos System Specifications
AC power. The button turns blue when the unit is powered ‘ON’. The 2600 has a projected capacitive multi-touch screen that has been factory calibrated and will not require any additional driver installation when used with most current operating systems, such as Windows 10. -
Page 6: I/O Panel
USB ports indicate the USB v 2.0 ports. COM Ports There are 3 COM ports on the 2600; they are standard RS-232. The COM3 port has been configured to supply +5VDC power to pin 9 of the DB9 connector on the supplied adapter cable. -
Page 7: Cash Drawer Interface
P/N 11801015. See the drawing below for the adapter’s pinout. Figure 1, Serial Port Adapter Pinout Cash Drawer Interface The 2600 POS I/O panel has a single cash drawer port which is capable of driving a 24VDC cash drawer. The interface is compatible with the APG Cash Drawer (http://www.cashdrawer.com/ ) CD-005A specification, seen below. -
Page 8: Supported Peripheral Options Details
PD1200 powered by COM 3 Power Requirements The 2600 POS System has one AC power cord. The power cord to the AC adapter is installed into the system’s base at the factory. A dedicated, clean power source is recommended. UTC RETAIL offers a variety of UPS options. Contact your sales agent. -
Page 9: Power Cable Connection
Power Cable Connection Place the 2600 POS face down on a clean, soft surface, ensuring you do not scratch the front bezel or the touchscreen. See photo below. Stand the system on its feet and be sure to position the power cable through the cutout in the rear of the base. -
Page 10: System Installation Guide
DO NOT OVER TIGHTEN. System Installation Guide Please refer to the 2600 POS System Installation Guide, which may be downloaded from the UTC RETAIL website at www.utcretail.com. Please call UTC RETAIL Technical Support at 800.349.0546 if you have any problems not addressed in this manual or have questions about sections of this documentation.
