- Page 1 GPSMAP 2006/2010 GPS 17N Installation Guide...
- Page 2 GPSMAP 2006 / 2010/ GPS 17N Installation Guide Introduction The GPSMAP 2006/2010 must be properly installed according to the follow- ing instructions to get the best possible performance. To complete the installation, you’ll need the appropriate fasteners, tools and mounts listed in each section. These items should be available at most marine dealers.
- Page 3 MOUNTING HOLE back of the unit. Use a 1/16” (2mm) Allen Wrench to tighten the Mounting Studs until the Garmin International 1200 E. 151 st Street, Olathe, KS 66062 Part Number 190-00244-00 May 2001 Printed in Taiwan stop contacts the case. Be careful not to overtighten as this may damage the Mounting Flush Mount Template Stud! The studs have a reusable thread-locking patch pre-applied from the factory.
- Page 4 The GPS 17N installs on any standard 1” OD Marine Mount. The cable can be run externally or if possible, through the center of the mount. The GPS 17N con- nects to the 18-pin Power/Data Cable on the GPSMAP 2006/2010 and provides the ABOVE- OK GPS signal for the unit.
- Page 5 Wiring There are two wiring diagrams provided for you convenience. The fi rst is a simple hook-up showing the GPSMAP 2006/2010 (using the 18-pin wiring harness), the GPS 17N and the alarm circuit. The Alarm does not have to be wired for the unit to function. The second is a complete wiring diagram showing the GPSMAP 2006/2010 (using the 18-pin wiring harness) interfacing with a variety of different equipment.
- Page 6 GARMIN GSD 20 SOUNDER MODULE (SEE GSD 20 INSTALL INSTRUCTIONS) 4. A GARMIN SOUNDER UNIT (OTHER THAN GSD 20) CAN PROVIDE WATER DEPTH, WATER TEMPATURE, AND SPEED VIA NMEA DATA FOR DISPLAY ON THE GPSMAP 2006/2010. Diagram 2 - Complete Interface...
- Page 7 Once all the wiring is complete, plug the 18-pin harness into the center connector on the backside of the GPSMAP 2006/2010. The 5-pin port on the right side is intended for future interfacing features and does not require connection at this time.
- Page 8 © 2001-2002 GARMIN Ltd. or its subsidiaries GARMIN International, Inc. 1200 East 151 Street, Olathe, Kansas 66062, U.S.A. GARMIN (Europe) Ltd. Unit 5, The Quadrangle, Abbey Park Industrial Estate, Romsey, SO51 9AQ, U.K. GARMIN Corporation No. 68, Jangshu 2 Road, Shijr, Taipei County, Taiwan www.garmin.com...
