- Page 1 O P E R A T I O N S MAINTENANCE MANUAL BANQUET SERVICE CARTS CATERING SERIES BANQUET SERIES WITTCO MODEL NUMBERS 2-48 2-96-B 2-72-C 2-90 2-150-B 2-96-C 2-150-C...
- Page 2 Products, as defined by Wittco, shall be delivered by Buyer, at its sole expense, to the nearest Wittco authorized service agency for replacement or repair. Wittco reserves the right to accept or reject any such claim in whole or in part. Wittco will not accept the return of any Product without prior written approval from Wittco, and all such approved returns shall be made at Buyer's sole expense.
- Page 3 Wittco model number indicated on the equipment serial data plate located at the electrical connection. Wittco serial number indicated on the equipment serial data plate. The equipment serial number will also have two (2) alpha characters immediately following the serial number. These alpha characters are part of the serial...
- Page 4 It is our sincere desire that you obtain the maximum benefit from your Wittco banquet cabinet. If at any time questions arise or additional information is required, contact Wittco at 800 367-8413.
-
Page 5: Unpacking The Cabinet
punctured or dented, it may be an indication that the cabinet has sustained concealed freight damage. It is very important that any evidence of damage be noted on the Bill of Lading at the time of receipt. UNPACKING THE CABINET Remove the banding material holding the carton to the pallet. -
Page 6: Replacement Of Electrical Components
Never use harsh chemicals or abrasive pads to clean the cart. REPLACEMENT OF ELECTRICAL COMPONENTS It is highly recommended that only Wittco Foodservice Equipment replacement parts be used to insure compatibility of component parts in the operation of the banquet cabinet. THERMOSTAT REPLACEMENT DISCONNECT THE CABINET FROM ITS POWER SOURCE. -
Page 7: Heating Element Replacement
THERMOSTAT REPLACEMENT (CON'T) Install the replacement thermostat and temperature sensing bulb following the reverse of the above procedure. Reinstall the cabinet top cover and screws. 10. Reconnect the cabinet to the power source and test. INDICATOR LIGHT REPLACEMENT 1. DISCONNECT THE CABINET FROM ITS POWER SOURCE. Remove the top cover by removing the retaining screws and lifting the cover off the cabinet to expose the indicator light. - Page 8 HEATING ELEMENT REPLACEMENT (CON'T) Gently pull the element from its housing until the electrical lead wire connectors are exposed. Disconnect the defective element at the electrical lead wire connectors. Connect the element lead wires to the cabinet lead wires by reinstalling the wire connectors. Tuck the residual wire back through the wire housing hole until the replacement element is against the interior rear wall.
- Page 9 DRAWING TITLE WIRING DIAGRAM 120V. 1PH, 60 HZ 2-48 2-90 2-72-B 2-96-B 2-72-C 2-96-C 2-150-C...
- Page 10 WITTCO FOODSERV1CE EQUIPMENT INC. REPLACEMENT PARTS LIST WITTCO SERIES - BANQUET CARTS - CATERING SERIES 6/30/98 MODEL NUMBER AND QUANTITY REQUIRED WITTCO PART DESCRIPTION PART NO. 2-48 2-72-C 2-90 2-96-C 2-150-C WP-239-48E BUMPER, ALUMINUM EXTRUSION ONLY (NO VINYL) WP-239-72E BUMPER, ALUMINUM EXTRUSION ONLY (NO VINYL)
- Page 11 MODEL NUMBER AND QUANTITY REQUIRED WITTCO PART DESCRIPTION PART NO. 2-48 2-72-C 2-90 2-96-C 2-150-C WP-252-48 GASKET, DOOR ALUMINUM EXTRUSION WP-252-72 GASKET, DOOR ALUMINUM EXTRUSION WP-252-90 GASKET, DOOR ALUMINUM EXTRUSION WP-252-96 GASKET, DOOR ALUMINUM EXTRUSION WP-252-150 GASKET, DOOR ALUMINUM EXTRUSION WP-302 GASKET, DOOR (BLACK) BY THE FT.
- Page 12 MODEL NUMBER AND QUANTITY REQUIRED WITTCO PART DESCRIPTION PART NO. 2-48 2-72-C 2-90 2-96-C 2-150-C WP-308-90 TOP COVER WP-308-96 TOP COVER WP-308-150 TOP COVER...
- Page 13 WITTCO FOODSERVICE EQUIPMENT INC. REPLACEMENT PARTS LIST WITTCO SERIES - BANQUET CARTS - BANQUET SERIES 6/30/98 MODEL NUMBER AND QUANTITY REQUIRED WITTCO PART DESCRIPTION PART NO. 2-96-B 2-150-B WP-239-96E BUMPER, ALUMINUM EXTRUSION ONLY (NO VINYL) WP-239-150E BUMPER, ALUMINUM EXTRUSION ONLY (NO VINYL)
- Page 14 MODEL NUMBER AND QUANTITY REQUIRED WITTCO PART DESCRIPTION PART NO. 2-96-B 2-150-B WP-106-2 LIGHT, INDICATOR DUAL 250 VOLT (AMBER/RED) WP-126 PLATE CARRIER (COVERED) WP-127 PLATE CARRIER (UNCOVERED) WP-123-96 SHELF WP-123-150 SHELF WP-240 SHELF CLIPS WP-006-312 STRAIN RELIEF AT POWER CORD...
