Summary of Contents for Sportable Scoreboards 2218LED
- Page 1 INSTALLATION INSTRUCTIONS MODEL 2218LED www.sportablescoreboards.com...
-
Page 2: Table Of Contents
Table of Contents MODEL 2218LED ..............................3 8’ X 2’ INDOOR SCOREBOARD .......................... 3 THE SCOREBOARD SYSTEM SHOULD INCLUDE THE FOLLOWING PARTS: ......3 PRODUCT SPECIFICATIONS ..........................4 Overall Dimensions: ............................4 Weight: ..................................4 Power Requirements: ............................4 Communication Cable Requirements (for cable-controlled systems only): ......5 MOUNTING THE SCOREBOARD TO A WALL .................... -
Page 3: Model 2218Led
MODEL 2218LED 8’ X 2’ INDOOR SCOREBOARD NOTE TO INSTALLERS: PLEASE RETURN THIS MANUAL TO THE INDIVIDUAL IN CHARGE OF THE SCOREBOARD UPON COMPLETION OF INSTALLATION. The scoreboard and all accompanying accessories have been carefully inspected and tested before leaving the factory. -
Page 4: Product Specifications
INSTALLATION OVERVIEW This manual will walk you through the installation of the scoreboard. While care has been taken to consider the many scenarios for installation, some general information applies to all. Use this guide as closely as possible to ensure proper installation, as follows: 1. -
Page 5: Communication Cable Requirements (For Cable-Controlled Systems Only)
Communication Cable Requirements (for cable-controlled systems only): Four conductor cable – 28 gauge, twisted pair (two pairs), shielded data cable MOUNTING THE SCOREBOARD TO A WALL NOTE: Use hardware appropriate for the wall type you are mounting to and capable of supporting the weight of the scoreboard. -
Page 6: Hanging The Scoreboard From The Ceiling
HANGING THE SCOREBOARD FROM THE CEILING 1. Remove the scoreboard from its packaging, making sure not to pry against or cut into the scoreboard. Inspect the unit for shipping damage according to the instructions on page 1. NOTE: CARE MUST BE TAKEN NOT TO DAMAGE THE SCOREBOARD WHILE LIFTING IT INTO PLACE. IF THE SCOREBOARD WILL BE “AGAINST”... -
Page 7: Running & Connecting The Control Cable
RUNNING & CONNECTING THE CONTROL CABLE (For scoreboards with Wireless Remote Control, skip this step.) The control cable must be run in a separate conduit than is used for the electrical service. The control cable should run from the scoreboard to a location that is within 10 feet of the scorekeeper’s location and into a 2”X4”... - Page 8 2. The back of the wall plate has a label indicating how the connections are to be made. As follows connect the black wire on the wall plate to the orange wire, connect the gray wire on the wall plate to the bare (shield) wire in the cable, connect the green wire on the wall plate to the blue wire of the cable, connect the white wire of the wall plate to the white with a blue stripe This is for a hand held controller only to connect of the cable.
-
Page 9: At The Scoreboard
3. Secure the junction box cover to the installed junction box. At the scoreboard: 4. Remove the signal/power access door located on the back of panel A. 5. From the ground, run the control cable through a sealed, water-tight conduit then through a water-tight conduit fitting into the left side of the signal cable/power access door and into the scoreboard. -
Page 11: Running & Connecting The Electric Service
NOTE: Refer to the connections that were made at the scorekeeper’s location. Make the connections at the scoreboard match the connections at the scorekeeper’s location. 3. Close and secure the module access door. RUNNING & CONNECTING THE ELECTRIC SERVICE 1. The scoreboard has a ½” knock-out on the top left corner for bringing in the electrical service. It can be enlarged if the conduit size is ¾”. -
Page 12: Testing The Installed System
TESTING THE INSTALLED SYSTEM At Start-Up: When the scoreboard is initially powered up, it should display “zeros” in the Home and Guest scores and a “one” in the Period for at least 45 seconds. If the controller has not been turned on and either RESET or ENTER has not been pressed within that time period, the scoreboard may revert to a “power saving”... -
Page 13: Important
IMPORTANT! Warranty Activation/Installation & Completion Sign Off Sheet NOTE: This sheet must be completely filled out and returned/faxed (270) 753-3773 to Scoreboard Service Company before your warranty can be activated. Your Serial Number _______________________________________ Your Model Number _______________________________________ Date Purchased _______________________________________ Sales Agent _______________________________________...
