規格 Specifications 產品名稱 AVerCaster HD Duet Product Name HDMI 輸入訊號 Component Input Signal 輸出 Output Interface H.264 Baseline/Main/High Profile 影像規格 Video Format 1080p/25Hz/30Hz;1080i 50Hz/60Hz;720p 50Hz/60Hz; 576p 50Hz;576i 50Hz;480p 60Hz;480i 60Hz 聲音規格 Audio Format 傳輸協定 TCP/UDP/RTP/RTMP Publish Transport Protocol 傳輸模式 Unicast/Multicast Transport Mode 網路介面...
Page 6
Important Safety Instructions Safety stop – Do not alter Use only the power cords and power adapters supplied by the product manufacturer. Never wrap a power cord around a power adapter or other object. Always connect power cords and signal cables in the correct order and ensure that all power cord connectors are securely and completely plugged into receptacles.
Quick Installation Guide Quick Installation Guide Package Contents Quick Installation Guide AVerCaster HD Duet Power Adapter* Power Adapter Outlet Module* A/C Adapter* IR Blaster*2 Installation CD Quick Installation Guide * The actual power adapter varies according to the area that AVerCaster HD Duet is purchased. English-1...
Quick Installation Guide Hardware Installation 2.1 Getting to know each port/part of the AVerCaster HD Duet Front View Power Stream Status Rear View HDMI 1 HDMI 2 Component 2 Component 1 LAN A LAN B DC-IN Power Installing the Power Adaptor Slide Power Adapter Oultet Module into the groove on the Power Adapter.
Page 13
Quick Installation Guide Quick Installation Guide 2.2 Status of the LED indicators When the unit is powered on, the blue LED indicator lights up and starts to blink. AVerCaster HD Duet is ready when the blue indicator goes from blinking to steady on. Please refer to the following table to check the status of LED indicators.
Page 14
Quick Installation Guide 2.3 Connecting input sources to AVerCaster HD Duet You can connect two sets of sources to the AVerCaster HD Duet at one time. Recommended connections are as follow: Connect two HDMI or two Component cables to the AVerCaster HD Duet. Or connect source cables to HDMI 1 and Component 2 as follows.
Page 15
Quick Installation Guide Quick Installation Guide 2.4 Connecting IR Blaster to the AVerCaster HD Duet (Optional) IR Blaster is needed when you intend to switch channels of your STB/ Satellite receiver via AVerCaster HD Duet. Plug in the IR Blaster (Infrared Blaster) to the IR port on the rear panel of the AverCaster HD Duet.
Page 16
Quick Installation Guide Online Resources and Support To learn more about AVerMedia products and download the latest user manual in different languages please visit AVerMedia website: http://solutions.avermedia.com/ International Headquarters Address No.135, Jian 1st Rd., Zhonghe Dist., New Taipei City 23585, Taiwan Website solutions.avermedia.com...
