Instructions for Use
MODEL -
H 2 Oasis Series
(For illustration purpose only, may look different from your model)
- Outdoor use only -
This appliance is designed to heat a water source up to about 30°C above ambient temperature (to a maximum of 50°C +/- 2°C).
IMPORTANT
Read these instructions for use carefully. Familiarise yourself with the appliance before connecting it to its gas
container. Keep these instructions for future reference.
This instruction manual contains important information necessary for the proper assembly and safe use of the appliance.
Follow all warnings and instructions when using the appliance. If you have questions about assembly, operation, servicing
or repair of this product, please call Coleman on 1800 224 350. Coleman Brands Pty Ltd. Suite W2C1, 75-85 O'Riordan St,
Alexandria, NSW 2015. Gas cylinders shall be changed in a well-ventilated location, preferably outside away from people
and any sources of ignition, such as naked flames, pilot flames, electric heaters / equipment. If there is a leak on your
appliance (smell of gas) and you cannot stop the gas flow, remove the appliance to a well-ventilated location away from any
ignition source. Check for leaks using soapy water. Do not try to detect leaks using a flame.
Advertisement
Related Manuals for Coleman H2Oasis Series
Summary of Contents for Coleman H2Oasis Series
- Page 1 Follow all warnings and instructions when using the appliance. If you have questions about assembly, operation, servicing or repair of this product, please call Coleman on 1800 224 350. Coleman Brands Pty Ltd. Suite W2C1, 75-85 O’Riordan St, Alexandria, NSW 2015. Gas cylinders shall be changed in a well-ventilated location, preferably outside away from people and any sources of ignition, such as naked flames, pilot flames, electric heaters / equipment.
- Page 2 Outdoor Use Only This appliance shall only be used in an above ground open air situation with natural ventilation, without stagnant areas, where gas leakage and products of combustion are rapidly dispersed by wind and natural convection. Any enclosure in which the appliance is used shall comply with one of the following: (A) An enclosure with walls on all sides, but at least one permanent (B) Within a partial enclosure that includes an overhead cover and no more opending at ground level and no overhead cover.
- Page 3 2. Extinguish any open flame. If you need assistance or information such as an instruction manual or labels, contact The Coleman Company, Inc. 3. Disconnect from fuel supply. FOR YOUR SAFETY Do not store or use gasoline or other flammable vapors and liquids in the vicinity of this or any other appliance.
- Page 4 System Overview Thank you for purchasing Coleman’s Hot Water on Demand unit. This portable and self-contained water heater is designed to provide hot water for outdoor showering / cleaning tasks only. Do not use the product to heat drinking water.
- Page 5 Unpack your new water heater from the carton and make sure that all of the parts are included. If you find that one of the components is missing, please contact Coleman for a replacement: 1-800-224-350. Make sure to remove the protective film on the display panel on the front of the heater before use.
- Page 6 4. After the Shower Arm is installed, you may put The Shower onto The Shower Arm. GAS CYLINDER INSTALLATION (FIG. 8) This appliance shall only be used with Propane LPG Coleman disposable gas cylinders Fig. 8 certified to DOT-39 NRC 232/290 M1110. IT MAY BE HAZARDOUS TO ATTEMPT TO REGULATOR FIT OTHER TYPES OF GAS CONTAINERS.
- Page 7 Coleman for services or repair. Use and Operation Clean before first use. It is strongly recommended that you clean the heater prior to using for the first time. Follow these simple steps before you leave home, and then clean at least once a year or when the hose becomes discolored with a white calcium build up.
- Page 8 Use and Operation (continued) SHUTTING OFF THE HEATER 1. Turn the control knob clockwise to the “OFF” position. 2. Switch off the power button on the display panel. 3. Turn the main power switch to “OFF” (available on Elite version only). IMPORTANT: User must not change the order of the shut-off-operation sequence.
- Page 9 50°C at the water outlet on the heater. Meanwhile the pump will continue to pump for 30 seconds, to cool down the heater. • The water heater is ideal for many outdoor cleaning tasks. Coleman supports the Leave No Trace Principles that encourage minimal impact to the environment while camping.
- Page 10 Chart of Indicators Steady light: Flashing light: Standard Version (Red / Yellow / Green) (Red / Yellow / Green) Explanation Display of Indicators Trigger System Reaction Corrective Action Battery being charged Battery fully charged Electrical system is turned on Pilot Light is lit Turn off the control knob and the power button.
- Page 11 Environment temperature is high Turn control knob to a cooler setting. Temperature sensor defective Contact Coleman Service Center and return the product to Coleman when necessary. Heater is tilted more than 30 degrees. Gas & pump will be shut off immediately.
- Page 12 Three Year Limited Warranty Coleman Brands Pty. Ltd. (“Coleman”) warrants that for a period of three (3) years from the date of original retail purchase, this product will be free from defects in material and workmanship. Coleman will, depending on the circumstances, refund, repair or replace this product or any component of the product found to be defective during the warranty period.
