1. INTRODUCTION
The interface adapter for iPod
EA1251, works by simulating the iPod as a 6
Disc CeNET CD Changer. Please consult your
main unit's Owner's Manual for CD Changer
operations before beginning to use EA1251.
Clarion Multimedia Station of VRX series cannot
control EA1251 through the KEY PAD screen or
the list screen. If required so, please use the
function buttons instead. Some EA1251 functions
might not be available.
2. CAUTION
Please check your iPod Owner's Manual for the
operating temperature as leaving iPod in your
vehicle might damage it due to temperature
variations and moisture.
®
by Clarion,
Some main unit models with CD-Text function
have the capability to show ID3 TAG if iPod is
connected through EA1251. Please refer to Title
Display Section for more details.
For list of main unit compatible to EA1251, please
consult your nearest Clarion dealer.
For iPod operations, please refer to iPod Owner's
Manual.
3

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the EA1251 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Clarion EA1251

  • Page 1 1. INTRODUCTION The interface adapter for iPod EA1251, works by simulating the iPod as a 6 Disc CeNET CD Changer. Please consult your main unit’s Owner’s Manual for CD Changer operations before beginning to use EA1251. Clarion Multimedia Station of VRX series cannot control EA1251 through the KEY PAD screen or the list screen.
  • Page 2 3. CONNECTION Please consult your nearest Clarion dealer before attempting to connect EA1251 to your main unit and iPod. Improper connection might damage your main unit, EA1251, iPod or your vehicle wiring. Please make sure the Yellow wire ( Bus power lead ) is connected on the CeNET compatible Main Unit ( This wire usually has a 3 Amp Fuse inserted ) connects to battery.
  • Page 3: Installation

    4. INSTALLATION There are no moving parts in EA1251. However, caution must be taken to make sure minimum damage to the unit. Do not press, puncture or drop the unit at anytime. Install the unit where there is no direct sunlight, away from air condition ducts or high moisture areas and away from other vehicle electronic components.
  • Page 4: Operation

    OK to disconnect Disconnecting iPod automatically switches “on” after connecting to EA1251, and it’s power is charged as long as it stays connected with the vehicle ignition key turn to ACC or ON. To switch off iPod manually, disconnect from EA1251 adaptor.
  • Page 5: Fast Forward/Fast Backward

    Song ( Track ) Up/Down Press Track Up/Down button to jump from song to song. Short press Track Down button jumps playback to the beginning of current song. Short press Track button twice within 2 to 3 seconds jumps playback to the beginning of previous song. If the last song is playing, by short press Track Up button, will enables playback to jump to the first song in the current disc.
  • Page 6 PAD screen, as available in certain Multimedia Station models ( i.e. VRX745VD ) . Playlist EA1251 simulates iPod as a 6 Disc CD Changer. Therefore, a maximum of five acceptable playlists will be indicated as “Disc” in a 6 Disc CD Changer.
  • Page 7: Title Display

    ( Software Version 1.2 or higher ) . iPod photo ( does not apply to picture display ) . 8. USER TITLE When EA1251 receives this command, main unit will show as “NO TITLE”. 9. CHANGING MODE FROM iPod TO OTHER...
  • Page 8: Table Of Contents

    Table des matières 1. INTRODUCTION ... 11 2. PRÉCAUTIONS ... 11 3. BRANCHEMENT ... 12 4. INSTALLATION ... 13 Utilisation de bandes velcro ou double face ... 13 Utilisation des vis ... 13 5. FONCTIONNEMENT ... 14 Démarrage ... 14 Déconnexion ...
  • Page 9: Introduction

    CD avant d'utiliser l'EA1251. La station multimédia Clarion de la gamme VRX ne peut pas commander l’EA1251 via l’écran KEY PAD ni via l’écran de liste. Si nécessaire, utilisez à la place les touches de fonctions. Il se peut que certaines fonctions de l’EA1251 ne soient pas...
  • Page 10: Branchement

    3. BRANCHEMENT Consultez votre revendeur Clarion le plus proche avant de tenter de brancher l’EA1251 à votre appareil principal et à votre iPod. Un mauvais branchement pourrait endommager votre appareil principal, votre EA1251, votre iPod, voire les câblages de votre véhicule.
  • Page 11: Installation

    4. INSTALLATION L’EA1251 ne contient aucune pièce mobile. Cependant, certaines précautions doivent être prises afin d’éviter d’endommager l’appareil. Évitez toujours de compresser, de donner des coups à l’appareil ou de le faire tomber. Installez l’appareil à l’abri de la lumière directe du soleil, à...
  • Page 12: Fonctionnement

    5. FONCTIONNEMENT Démarrage Une fois l’iPod connecté à l’EA1251, l’écran de l’iPod affiche ceci: OK to disconnect Déconnexion L’iPod se met automatiquement sur “on” lorsqu’il est connecté à l’EA1251, et reste alimenté tant qu’il est connecté et que le contact du véhicule est sur ACC ou sur ON.
  • Page 13 Titre (Plage) Haut/Bas Pressez la touche Haut/Bas pour passer d’un titre à l’autre. Appuyez brièvement sur la touche de plage précédente pour reprendre la lecture au début du morceau actuel. Faites brièvement pression deux fois sur la touche de plage précédente à l’intérieur de 2-3 secondes pour reprendre la lecture au début du morceau précédent.
  • Page 14: Liste D'écoute

    À chaque pression sur les touches Haut, Bas ou TOP, la lecture démarre depuis le premier titre de la liste d'écoute (Disque). Liste de lecture intelligente Il se peut que l’EA1251 lise avec difficulté les titres mis à jour de la liste d’écoute intelligente. 5/9/05, 9:56 AM...
  • Page 15: Affichage Des Titres

    (logiciel version 1.2 ou ultérieur). iPod photo (ne s’applique pas à l’affichage d’image). 8. TITRE UTILISATEUR Quand l’EA1251 reçoit cette commande, l’appareil principal indique “NO TITLE”. 9. PASSAGE DU MODE iPod À UN AUTRE MODE Une pression continue sur la touche source de l’appareil principal le fait passer du mode iPod à...
