Technical Manual
JETFLEX NON-STOP
AUTOMATIC BARRIER
¡ATTENTION!
Do not use this equipment
Manufactured by: Motoppar Indústria e Comércio de Automatizadores Ltda
without first reading the
Av. Dr. Labieno da Costa Machado, 3526 - Distrito Industrial - Garça - SP - CEP 17406-200 - Brasil
User's Manual.
CNPJ: 52.605.821/0001-55
P31493 - 08/2022
Rev. 0
www.ppa.com.br | +55 14 3407 1000

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the JETFLEX and is the answer not in the manual?

Questions and answers

Related Manuals for PPA JETFLEX

Summary of Contents for PPA JETFLEX

  • Page 1 Manufactured by: Motoppar Indústria e Comércio de Automatizadores Ltda without first reading the Av. Dr. Labieno da Costa Machado, 3526 - Distrito Industrial - Garça - SP - CEP 17406-200 - Brasil User’s Manual. CNPJ: 52.605.821/0001-55 P31493 - 08/2022 Rev. 0 www.ppa.com.br | +55 14 3407 1000...

  • Page 2: Table Of Contents

    INSTALLATION LOCATION The location where the barrier will be installed must be previously analyzed, including the entire site infrastructure, floor conditions, electrical power supply, passageway width, ceiling height (if any), vehicle flow and the need to use optional accessories. Once it is analyzed, the equipment that best fits the needs of the place should be chosen.

  • Page 3: General Features

    TECHNICAL SPECIFICATIONS Motor power supply Cable type and size 110V 1 PP cable - 2 x 2.5 mm 220V 1 PP cable - 2 x 2.5 mm Non-stop barrier (linear) 220V 1 PP three-phase cable - 3 x 2.5 mm 380V 1 PP three-phase cable - 4 x 2.5 mm Opening...

  • Page 4: Building The Base Plate To Install The Cabinet

    Cover Articulated barrier profile (EXTRA) 180 mm USEFUL LENGTH = BARRIER LENGTH -180 mm (FIXING – DEDUCT FROM THE BARRIER LENGTH 280 mm) (BARRIER LENGTH + 110 mm) Barrier Base (Ground clearance) ¾” CONDUIT PIPE (MINIMUM) FOR THE CABLES POSITIONED IN THE CENTER OF THE BASE OBS: Measurements in mm.
  • Page 5 2. Position / align the cabinet on the base and mark the holes so that the 5. Position the cabinet over the base, and fit the cabinet holes into the front of the gate (inspection door side) faces the curb (street, passage anchor bolts of vehicles).
  • Page 6 7. Insert the washers and nuts to fix the cabinet. OBS: Use 2.50mm² wires. Use a dedicated circuit breaker, that is, a circuit breaker where only the barrier will be connected. WASHERS AND NUTS 11. Check/set the barrier alignment (opening and closing). Use mechanical stops for this situation and move them as necessary.

  • Page 7: Balancing The Barrier And Checking The Belt

    13. The barrier will be in good working order when opening when the barrier/arm follows the requirements shown below in the image. SPRING SCREW BELT BELT TENSIONERS ADJUSTING THE MAGNET BAR After the barrier is balanced correctly and adjusted in the opening and closing “mechanical stops”, check if the magnet bars need adjusting.
  • Page 8 OBS: On the first activation, the barrier will move slowly in the opening and closing directions as it reads the path. Soon after the reading, the operation is normalized and will start operating at the factory default speed. For more accurate adjustments, refer to the electronic board options.
