eliving FURNITURE CUPPA Series Assembly Instruction Manual

Hide thumbs Also See for CUPPA Series:

Advertisement

Quick Links

Download this manual
ASSEMBLY INSTRUCTION
CUPPA WARDRODE
IMPORTANT:-
PLEASE READ THESE INSTRUCTION CAREFULLY BEFORE STARTING ASSEMBLY.
*Please Keep For Future Reference Only.
CUPPA SERIES
Dimensions
Width:1050mm
Depth:540mm
Height:1800mm
CPA - W1800 - WOK / PAGE 1

Advertisement

loading
Need help?

Need help?

Do you have a question about the CUPPA Series and is the answer not in the manual?

Questions and answers

Related Manuals for eliving FURNITURE CUPPA Series

Summary of Contents for eliving FURNITURE CUPPA Series

  • Page 1 *Please Keep For Future Reference Only. CUPPA SERIES ASSEMBLY INSTRUCTION Dimensions Width:1050mm Depth:540mm Height:1800mm CUPPA WARDRODE IMPORTANT:- PLEASE READ THESE INSTRUCTION CAREFULLY BEFORE STARTING ASSEMBLY. CPA - W1800 - WOK / PAGE 1...
  • Page 2 IMPORTANT TIPS AND MAINTENANCE i)Keep children and animal away ii)Never put the liquid on the iii)To avoid dulling,do not iv)Never use ammonia cleaning to avoid choking hazard. furniture. place directly to the sunlight. product,because it will damage the finish. v)Use a dry cloth to wipe vi)Two person required.
  • Page 3 COMPONENTS:- Please check you have all the panels are listed below. PANELS PARTLIST 2pcs BASE 2pcs SIDE PANEL-L BASE SIDE SIDE PANEL-R DOOR-L CENTRE PANEL DOOR-R CHEST BRACE PANEL DRAWER FRONT BACK BRACE PANEL DRAWER SIDE-L 2pcs SHELVES PANEL DRAWER SIDE-R 2pcs DRAWER BACK BACK PANEL UP...
  • Page 4 STEP1 HARDWARE NEEDED: 4Pcs 4Pcs STEP2 HARDWARE NEEDED: 2Pcs 5Pcs 2Pcs 2Pcs 180° CPA - W1800 - WOK / PAGE 4...
  • Page 5 STEP3 HARDWARE NEEDED: 8Pcs STEP4 HARDWARE NEEDED: 6Pcs CPA - W1800 - WOK / PAGE 5...
  • Page 6 STEP5 HARDWARE NEEDED: 4Pcs 5Pcs 180° STEP6 HARDWARE NEEDED: 2Pcs CPA - W1800 - WOK / PAGE 6...
  • Page 7 STEP7 HARDWARE NEEDED: 3Pcs STEP8 HARDWARE NEEDED: 2Pcs CPA - W1800 - WOK / PAGE 7...
  • Page 8 STEP9 HARDWARE NEEDED: 8Pcs 14Pcs 5Pcs 2Pcs Second Hole Last Third Hole SCREW MUST BE INSERTED IN THE SECOND HOLE ON THE DRAWER RUNNER 2&3 CPA - W1800- WOK / PAGE 8...
  • Page 9 STEP10 HARDWARE NEEDED: 6Pcs STEP11 HARDWARE NEEDED: 8Pcs CPA - W1800 - WOK / PAGE 9...
  • Page 10 STEP12 STEP13 HARDWARE NEEDED: 14Pcs 180° CPA - W1800 - WOK / PAGE 10...
  • Page 11 STEP14 HARDWARE NEEDED: 4Pcs STEP18 HARDWARE NEEDED: 8Pcs 4Pcs CPA - W1800 - WOK / PAGE 11...
  • Page 12 STEP16 HARDWARE NEEDED: 4Pcs STEP17 HARDWARE NEEDED: 10Pcs 4Pcs CPA - W1800 - WOK / PAGE 12...
  • Page 13 STEP18 HARDWARE NEEDED: 2Pcs 3Sets STEP19 CPA - W1800 - WOK / PAGE 13...
  • Page 14 STEP20 HARDWARE NEEDED: 8Pcs STEP21 HARDWARE NEEDED: 8Pcs CPA - W1800 - WOK / PAGE 14...
  • Page 15 STEP22 HARDWARE NEEDED: 28Pcs 28Pcs CPA - W1800 - WOK / PAGE 15...
  • Page 16 STEP23 HARDWARE NEEDED: 6Sets 6Pcs 17&18 CPA - W1800 - WOK / PAGE 16...
  • Page 17 STEP24 HARDWARE NEEDED: 4Pcs 2Pcs CPA - W1800 - WOK / PAGE 17...
  • Page 18 STEP25 HARDWARE NEEDED: 38Pcs 2Pcs 6Pcs 14&15 CPA - W1800 - WOK / PAGE 18...
  • Page 19 STEP26 HARDWARE NEEDED: 2Sets CPA - W1800 - WOK / PAGE 19...
