eliving FURNITURE CUPPA Series Assembly Instruction Manual
Bedside table
Hide thumbs
Also See for CUPPA Series:
- Assembly instruction manual (20 pages) ,
- Assembly instruction manual (15 pages) ,
- Assembly instruction manual (15 pages)
Subscribe to Our Youtube Channel
Related Manuals for eliving FURNITURE CUPPA Series
Summary of Contents for eliving FURNITURE CUPPA Series
- Page 1 *Please Keep For Future Reference Only. CUPPA SERIES ASSEMBLY INSTRUCTION Dimensions Width:550mm Depth:500mm Height:540mm CUPPA BEDSIDE TABLE IMPORTANT:- PLEASE READ THESE INSTRUCTION CAREFULLY BEFORE STARTING ASSEMBLY. CPA - BT603 - WOK / PAGE 1...
- Page 2 IMPORTANT TIPS AND MAINTENANCE iii)To avoid dulling,do not iv)Never use ammonia cleaning i)Keep children and animal away ii)Never put the liquid on the place directly to the sunlight. product,because it will damage to avoid choking hazard. furniture. the finish. vi)Two person required. v)Use a dry cloth to wipe vii)Put a soft mat on the floor to clean the surface.
- Page 3 COMPONENTS:- Please check you have all the panels are listed below. PANELS PARTLIST 2pcs BASE BOTTOM PANEL 2pcs BASE SIDE SIDE PANEL_L 2pcs DRAWER SIDE_L SIDE PANEL_R 2pcs FRONT PANEL DRAWER SIDE_R 2pcs DRAWER BACK SKIRT PANEL 2pcs 2pcs DRAWER BASE DRAWER FRONT BACK PANEL TOP PANEL...
- Page 4 STEP1 HARDWARE NEEDED: 4PCS 4PCS 4PCS ARROWON LOCKING NUT MUST POINT TOWARDS HOLE IN EDGE OF PANEL STEP2 HARDWARE NEEDED: 4PCS 4PCS ARROWON LOCKING NUT MUST POINT TOWARDS HOLE IN EDGE OF PANEL CPA - BT603 - WOK / PAGE 4...
- Page 5 STEP3 STEP4 HARDWARE NEEDED: 4PCS CPA - BT603 - WOK / PAGE 5...
- Page 6 HARDWARE NEEDED: STEP5 8 PCS STEP6 HARDWARE NEEDED: 4PCS CPA - BT603 - WOK / PAGE 6...
- Page 7 STEP7 HARDWARE NEEDED: 8PCS 10PCS 8PCS 4PCS 9&10 9&10 9&10 ARROWON LOCKING NUT MUST POINT TOWARDS HOLE IN EDGE OF PANEL Second Hole Last Third Hole SCREW MUST BE INSERTED IN THE SECOND HOLE ON THE DRAWER RUNNER CPA - BT603 - WOK / PAGE 7...
- Page 8 STEP8 HARDWARE NEEDED: 4 PCS HARDWARE NEEDED: STEP9 2PCS CPA - BT603 - WOK / PAGE 8...
- Page 9 STEP10 HARDWARE NEEDED: 4 PCS STEP11 CPA - BT603 - WOK / PAGE 9...
- Page 10 STEP12 STEP13 9&10 FINISHED EDGE CPA - BT603 - WOK / PAGE 10...
- Page 11 STEP14 STEP15 CPA - BT603 - WOK / PAGE 11...
- Page 12 STEP16 HARDWARE NEEDED: 8 PCS 3&4 ARROWON LOCKING NUT MUST POINT TOWARDS HOLE IN EDGE OF PANEL DRAWER X2 STEP17 HARDWARE NEEDED: 8 PCS 4 PCS 3&4 Third Hole Last Hole DRAWER X2 CPA - BT603 - WOK / PAGE 12...
- Page 13 STEP18 HARDWARE NEEDED: 8 PCS DRAWER X2 HARDWARE NEEDED: STEP19 8 PCS 3&4 DRAWER X2 CPA - BT603 - WOK / PAGE 13...
- Page 14 STEP20 DRAWER X2 STEP21 3&4 DRAWER X2 CPA - BT603 - WOK / PAGE 14...
- Page 15 STEP22 DRAWER X2 HARDWARE NEEDED: STEP23 4 PCS 4 PCS CPA - BT603 - WOK / PAGE 15...
