HOME THEATER DVD/CD RECEIVER
RX-DV3SL
REMOTE CONTROL RM-SRXDV3J
STANDBY/ON
DBS
VCR
TV
AUDIO
TV
TAPE
CDR
FM/AM
DBS
VCR
DVD
(
9
TV/VIDEO
REW/
TUNING
/FF
REPEAT
SLEEP
FM MODE
STROBE
– TV/DBS CH +
SOUND
EFFECT
CENTER
1
2
3
ANALOG
/DIGITAL
TEST
REAR·L
4
5
6
INPUT
AUDIO
SURR ON/OFF
REAR·R
7
8
9
SUBTITLE
SURR MODE
–
SUBWOOFER
+
10/0
+10
VFP
100+
TV RETURN
PROGRESSIVE
DIMMER
ANGLE
+
+
MUTING
TV VOL
VOLUME
ZOOM
–
–
DIGEST TOP MENU
MENU
CHOICE
ENTER
ON SCREEN
RETURN
HOME THEATER
DVD/CD RECEIVER
STANDBY
STANDBY/ON
INPUT
SURROUND
ON/OFF
MODE
ANALOG/DIGITAL
INPUT ATT.
REC MODE
INSTRUCTIONS
RX-DV3 HOME THEATER DVD/CD RECEIVER
DVD
DBS
VCR
TV
TAPE/CDR
FM/AM
SOURCE NAME
SETTING
For Customer Use:
Enter below the Model No. and Serial
No. which are located either on the rear,
bottom or side of the cabinet. Retain this
information for future reference.
Model No.
Serial No.
MASTER VOLUME
ADJUST
MEMORY
COMPACT
CONTROL
SUPER VIDEO
DVD/SUPER VCD/VCD/CD
LVT0875-001A
[J]
