  • Page 1 Battery Bank Installation User's MANUAL NPB12-36R...

  • Page 2: Table Of Contents

    Table of Contents Chapter 1.IMPORTANT SAFETY INSTRUCTIONS .... 2 Chapter 2.Introduction to the Front and Rear Panel .... 5 2.1.Front and Rear Panel Descriptions ......5 Chapter 3.Installation and Operation ........6 3.1.Unpacking ............. 6 3.2.Selecting Installation Position ........ 8 3.3.Installation Instructions ........

  • Page 3: Chapter 1.Important Safety Instructions

    Chapter 1. IMPORTANT SAFETY INSTRUCTIONS SAVE THESE INSTRUCTIONS This manual contains important instructions that should be followed during installation and maintenance of the battery bank and batteries. Important Notice • This battery bank is connected to an UPS. There will be voltage at the output terminals if the UPS is turned on even if the input AC Mains is not available.
  • Page 4 battery bank to the if foreign objects are deliberately or accidentally inserted into the battery bank enclosure. • The battery will discharge naturally if the system is unused for a period of time. Long-term storage without recharge maintenance could cause batteries damaged.
  • Page 5 • CAUTION – Do Not Dispose of Battery(ies) in open fire or high temperature environment. The Battery May Explode. • CAUTION – Do not open or mutilate the batteries. The electrolyte of the batteries is toxic and harmful to the skin and eyes.

  • Page 6: Chapter 2.Introduction To The Front And Rear Panel

    Chapter 2. Introduction to the Front and Rear Panel 2.1. Front and Rear Panel Descriptions ‘ 2U Model 1. DC Breaker 1. Battery Over-current Protection. (Option) 2. Easily remove battery bank from system. 2. DC Fuse(s) Battery Over-current Protection. 3. Earth Terminal For safety grounding connection.

  • Page 7: Chapter 3.Installation And Operation

    Chapter 3. Installation and Operation Note: The packing condition and the external outlook of the unit should be inspected carefully before installation. Retain the packing material for future use. 3.1. Unpacking Remove the packing foams and take the battery bank out of the box.
  • Page 8 M4x8mm M3x6mm M3x6mm C1 : 6 Pin Anderson Fixing pieces...

  • Page 9: Selecting Installation Position

    3.2. Selecting Installation Position It is necessary to select a proper environment to install the unit, in order to minimize the possibility of failure to the battery bank and extend the life of the batteries. Please follow the instructions below: 1.
  • Page 10 4. Do not place the battery bank in a dusty or corrosive environment or near any flammable objects. 5. This battery bank is not designed for outdoor use.

  • Page 11: Installation Instructions

    3.3. Installation Instructions 3.3.1. Tower installation Stand alone unit...
  • Page 12 with UPS...

  • Page 13: Rack Mount Installation

    3.3.2. Rack Mount installation Warning: Do not use rack mount kit to carry Battery Bank Step 1 Step 2...
  • Page 14 Step 3...

  • Page 15: Connect Dc Cable

    3.3.3. Connect DC Cable First Battery Bank Second Battery Bank...

  • Page 16: Storage Instruction

    3.4. Storage Instruction For extended storage through moderate climate(-15 to +30°C / +5 to +86°F), the batteries should be charged for 12 hours every 6 months by plugging the UPS power cord into the wall receptacle or by an external charger.
  • Page 17 Step 2...
  • Page 18 Step 3...

  • Page 19: Specification

    3.6. Specification NPB12-36R Model NO. 36VDC Voltage Rating 7/9Ah x 12 Capacity x Strings DC Sockets 6p DC Plugs 6p Dimensions 17.3x3.5x22.9 (WxHxD, 440x88x584 inch/mm) 83.33 lb Weight (9AH) (kg/lb) 37.8 kg 75.4 lb Weight (7AH) (kg/lb) 34.2 kg...
  • Page 20 Recommended 10.8A(max) Recharge Current Output Current (max) Operation 0~40°C / 32~104℉, 30-90%RH non-condensing Environment Storage -15~45°C, 30-90%RH non-condensing Environment Compliance UL, cUL...

  • Page 21: Recycling The Used Battery

    3.7. Recycling the Used battery Contact your local recycling or hazardous waste center for information on proper disposal of the used battery.
  • Page 22 192321752083003...
