Velocity VDOT-SSPK24WLP Series Manual

Wall mount speaker with selectable strobe

Introduction

The VDOT-SSPK24WLP is a high quality speaker/strobe. The high intensity strobe utilizes a Xenon flash tube that generates a

high-intensity flash visible from all angles. The VDOT-SSPK24WLP is provided with a turn dial which allows for candela selection

at the installation site; 15Cd, 30Cd, 60Cd, 75Cd, or 110Cd. This appliance is ideal for any occupancy that requires notification

appliances per the applicable building or fire code or wherever dependable alarms are required.

The VDOT-SSPK24WLP speaker/strobe strobe is listed in compliance with ANSI/UL 1971, Signaling Appliances for the Hearing

Impaired.

The VDOT-SSPK24WLP Series speaker/strobe offer a choice of field selectable power taps, 1/8, 1/4, 1/2, 1, 2 and 4 Watts for use

with either 25VRMS or 70.7VRMS audio amplifiers. The frequency range of the speakers is 400-4000Hz. All devices are suitable

for line supervision. Speaker includes DC blocking capacitor which allows for supervision voltage of either polarity.

This appliance is intended for use in fire alarm systems and is to be installed in accordance with this manual, the

recommendation of the local authorities having jurisdiction, and other NFPA documents that provide standards on

notification appliances for protective signaling systems.

The VDOT-SSPK24WLP is intended for indoor installations only; this appliance is not listed for outdoor or drip proof

applications. The VDOT-WSSPK24-15/75W, are intended for indoor or outdoor installations; this appliance is listed

for outdoor or drip proof applications when used in conjunction with the GBLP back box.

www.velocitydetection.com

Wall Mount Speaker with Selectable Strobe

Doc: GLT-000-0-0

VDOT-SSPK24WLP*

Issue: 001

Date: 00/00/2020

Table of Contents

Do you have a question about the VDOT-SSPK24WLP Series and is the answer not in the manual?

Page 1 Product Information The VDOT-SSPK24WLP Series speaker/strobe offer a choice of field selectable power taps, 1/8, 1/4, 1/2, 1, 2 and 4 Watts for use with either 25VRMS or 70.7VRMS audio amplifiers. The frequency range of the speakers is 400-4000Hz. All devices are suitable for line supervision.
Page 2 VDOT-SSPK24WLP* Wall Mount Speaker with Selectable Strobe Electrical Specifications NOTICE: DC VOLTAGE RANGE LIMITS: 16-33V. FWR VOLTAGE RANGE LIMITS: 16-33V. THIS PRODUCT WAS ONLY TESTED TO THE STATED VOLTAGE RANGE(S); DO NOT APPLY 80% AND 110% OF THIS RANGE FOR SYSTEM OPERATION. System Considerations 1.
Page 3 Limited Warranty Velocity Detection over Time Zeta Alarms Ltd declares that this product is free from defects in material and workmanship and it will repair or replace any product or part thereof which proves to be defective in workmanship or material for a period of twelve (12) months from the date of purchase but not to exceed eighteen (18) months from the date of manufacture.
