V S 7 1 5
DIGITAL MEDIA
P L A Y E R
OWNER'S MANUAL
INSTALLATION GUIDE

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the VS715 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Clarion VS715

Summary of Contents for Clarion VS715

  • Page 1 V S 7 1 5 DIGITAL MEDIA P L A Y E R OWNER’S MANUAL INSTALLATION GUIDE...

  • Page 2: Table Of Contents

    Even though this manual provides general installation and operation instructions for your new Clarion VS715 Stand- alone Digital Media Player, it does not show the exact installa- tion methods for your particular vehicle.

  • Page 3: Introduction

    The compression offered by MP3 technology makes it easier to transmit and record high quality video and audio signals from your computer than in the past. The VS715 allows playback of MP3 recorded media. The Clarion VS715 is a full-featured Digital Media Player specifically created for the mobile environment.
  • Page 4 Clarion A/V devices. About The Manual And Warranty To start enjoying your new Clarion VS715, please read the remaining instructions listed in this manual. Keep all instructions for future reference. This product is covered by a limited warranty (see the enclosed warranty card).

  • Page 5: Care And Maintenance

    VS715 can damage the electronics, resulting in an electri- cal shock or fire. • If the unit or remote control should become wet, turn off all power and let an authorized Clarion Dealer clean or ser- vice the equipment. DO NOT ATTEMPT TO OPEN OR SERVICE THE UNIT OR REMOTE CONTROL.

  • Page 6: Dvd Playback Discs

    “1”. DVD video region numbers may be marked on the disc jackets of the DVD case. TV color system This DVD player plays NTSC discs only and cannot be used for playback of PAL or SECAM discs.

  • Page 7: Description Of Rear Connectors

    Use an RCA video cable to connect an external video source (eg., VDH910 VCR, or TTX001 TV Tuner) into the VS715. When a DVD is not playing the video and audio signals are passed to the output connectors. REMOTE SENSOR INPUT (3.5 mm Plug)

  • Page 8: Description Of Front Controls

    ESCRIPTION RONT ONTROLS Figure 2. The VS715’s front control and slot. DVD INSERTION SLOT Insert a DVD disc directly into the loading slot. The unit will automatically load the disc and start playback. EJECT BUTTON Press the eject button to remove the DVD disc. If eject is...

  • Page 9: Description Of Ir Remote Control

    STAND ALONE DIGITAL MEDIA PLAYER VS715 IR R ESCRIPTION EMOTE ONTROL Figure 3. VS715’s Remote Control. POWER Button Press to power the unit ON or OFF. EJECT Button Press the EJ button to eject DVD/CD disc media from the player.
  • Page 10 JOG UP/DN Buttons Scrolls UP or DN through screen options while in the on- screen main menu. JOG LEFT/RIGHT Buttons Scrolls LEFT or RIGHT through screen options while in the on-screen main menu. CHAPTER/TRACK BACK Button Skips back to start of Chapter/Track. Press multiple times within one second to advance backwards to the pre- vious chapters.
  • Page 11 Inside the vehicle, simply aim the IR Remote Control directly at the Clarion monitor or the front of the VS715 and press any desired button. For best results, also note the following: • Aim the IR Remote Control from no further than 7 feet away and no more than 3 feet on either side of the sensor.

  • Page 12: Description Of Dvd Main Menu And Sub-Menus

    DVD M ESCRIPTION Figure 5. Main Menu for optional selections. Scrolling through the DVD’s Menus 1. Press the MENU button on the IR Remote Control during playback, and the DVD’s Main Menu will appear on the screen. 2. Select the desired item using the JOG UP/DN buttons then press the ENTER button on the IR Remote Control.

  • Page 13: Description Of Vs715 Display Status Screen

    6CH] [OFF] SUBTITLE: AUDIO: [NONE] Figure 7. VS715 Display Status Screen. Turning on the Display Status Screen TATUS CREEN 1. Press the DISP button on the IR Remote Control during playback, and the Display Status Menu will appear on the screen.

  • Page 14: Dvd Operations With The Vs715

    DVD O VS715 PERATIONS 00:00:00 00:00:00 Figure 8. DVD Display Status Screen. OWNER’S MANUAL/INSTALLATION GUIDE Turning on or off the power NOTE: Do not use the Mutimedia system for long periods of time with the engine off. The car’s battery can be drained and reduce the service life of the battery.
  • Page 15 Wipe the disc with a soft cloth before insertion. If errors still occur, remove the disc. 2. Press the EJECT button on the front of the VS715 faceplate or the EJ button on the IR Remote Control. NOTE: If the disc is ejected and not removed, the VS715 will automatically retract the disc back into the player after 15 sec- onds.
  • Page 16 • While in Slow Preview the Display Status Screen is acti- vated along the top of the screen. 2. Press the PLAY button to resume normal playback. Slow Review 1. Press the SLOW REVIEW button on the IR Remote Control to playback frames at 1/7th normal speed back- wards.
  • Page 17 STAND ALONE DIGITAL MEDIA PLAYER VS715 • Some buttons may not be available depending on the DVD video used. • While in Chapter Ahead or Chapter Back the Display Status screen is activated along the top of the screen. When the chapter is found, the display disappears and normal playback resumes.

  • Page 18: Cd Operations With The Vs715

    EJ button on the IR remote Control to remove the CD disc media. NOTE: If the disc is left as is and not removed, the VS715 will automatically retract the disc back into the player after 15 sec- onds.
  • Page 19 STAND ALONE DIGITAL MEDIA PLAYER VS715 Stopping CD Playback 1. Press the STOP button on the IR Remote Control. NOTE: When the STOP is pressed the CD will start playback from the beginning when PLAY is pressed again. Pausing CD Playback 1.

  • Page 20: Installation And Wiring

    “REPEAT [OFF]” in the upper left corner of the screen. The display will return to normal after one second. OWNER’S MANUAL/INSTALLATION GUIDE NSTALLATION IRING VS715 Wiring for the 3-Pin Power Harness Fuse (Not Supplied) Yellow Ignition Switch Black To Ground...
  • Page 21 STAND ALONE DIGITAL MEDIA PLAYER VS715 Installing The VS715 The VS715 can be mounted horizontally or by using the ISO mounting holes in-dash, as shown in Figures 11 and 12 below. NOTE: Check for proper mounting depth before attempting ISO mounting.
  • Page 22 OWNER’S MANUAL/INSTALLATION GUIDE Wiring The VS715 DVD Player Figure 13. Wiring diagram for VS715.
  • Page 23 STAND ALONE DIGITAL MEDIA PLAYER VS715 Wiring The VS715 DVD Player Figure 14. TTX001 Wiring diagram for VS715.

  • Page 24: Troubleshooting

    A DVD/CD is Consult your Clarion caught inside the . Dealer at the store deck and will not of purchase. eject.

  • Page 25: Specifications

    S/N Ratio (A-wtd): 100 dB Separation: 80 dB Supplied Accessories: VS715 disc unit, IR Remote Control, (2) AAA Alkaline Batteries, 4-pin Power Supply Harness, Trim Bazel, DIN Mounting Sleeve, Backstrap, (4) M5x6 Counter Sunk Machine Screws, (4) M5x10 Phillips Head Self-tapping Screws, (2) Installation Brackets, 5 Meter RCA A/V Cable, Owner’s/Installation Manual,...
  • Page 26 Clarion Corporation of America 661 West Redondo Beach Blvd Gardena, CA 90247 800-Go-Clarion www.clarion-usa.com ©2001 Clarion Corporation, Gardena, CA 2001-VS715-10 Rev. 0 (01/01)
