Owner's manual

Mode d'emploi

Manual de instrucciones

DXZ775USB

CD/USB/MP3/WMA/AAC RECEIVER WITH CeNET CONTROL

AUTORADIO CD/USB/MP3/WMA / AVEC COMMANDE CeNET

RECEPTOR DE CD/USB/MP3/WMA/AAC CON CONTROL CeNET

This equipment has been tested and found to comply with the limits for a Class B digital device,

pursuant to Part 15 of the FCC Rules.

These limits are designed to provide reasonable protection against harmful interference in a

residential installation.

This equipment generates, uses, and can radiate radio frequency energy and, if not installed and

used in accordance with the instructions, may cause harmful interference to radio communications.

However, there is no guarantee that interference will not occur in a particular installation.

If this equipment does cause harmful interference to radio or television reception, which can be

determined by turning the equipment off and on, the user is encouraged to consult the dealer or an

experienced radio/TV technician for help.

Cet appareil a été testé et jugé conforme aux limites des appareils numériques de Classe B, aux

termes de la Section 15 des Règlements FCC.

Ces limites ont pour but d'assurer une protection raisonnable contre les interférences parasites

dans une installation résidentielle.

Cet appareil engendre, utilise et peut émettre une énergie radioélectrique et, s'il n'est pas installé

et utilisé en stricte conformité avec ces instructions, il peut provoquer des interférences parasites

sur les liaisons radiophoniques. Ceci ne garantit par pour autant qu'une installation particulière ne

provoquera aucune interférence.

Si l'appareil engendre des interférences sur la réception des ondes radio ou de télévision, ce qui

peut être vérifié en mettant l'appareil hors tension puis sous tension, l'utilisateur est invité à

consulter son revendeur ou un technicien exprimenté en radio/télévision pour lui demander conseil.

Este equipo ha sido probado y se ha comprobado que cumple con los límites de un dispositivo

digital de clase B, según lo indicado en la Parte 15 de las Normas de FCC.

Estos límites se han establecido para ofrecer una protección razonable contra interferencias

perjudiciales en instalaciones residenciales.

Este equipo genera, emplea, y puede radiar energía de radiofrecuencia y, si no se instala y emplea

de acuerdo con las instrucciones, puede causar interferencias perjudiciales en las

radiocomunicaciones. Sin embargo, no se garantiza que las interferencias no ocurran en una

instalación en particular.

Si este equipo causa interferencias perjudiciales en la recepción de radio o de televisión, lo cual

podrá determinarse conectando y desconectando la alimentación del equipo, se aconseja al

usuario que consulte al abastecedor o que pida ayuda a un técnico en radio/televisión

experimentado.

Veuillez déplier et vous référer à la page suivante.

Cerciórese de desplegar y de leer la página siguiente.

Bottom View of Source Unit

Fond de l'appareil pilote

Vista inferior de la unidad fuente

Be sure to unfold and read the next page.

DXZ775USB

Table of Contents

Need help?

Do you have a question about the iDXZ775USB and is the answer not in the manual?

Questions and answers

Summary of Contents for Clarion iDXZ775USB

Page 1 Owner’s manual Mode d’emploi Manual de instrucciones DXZ775USB CD/USB/MP3/WMA/AAC RECEIVER WITH CeNET CONTROL AUTORADIO CD/USB/MP3/WMA / AVEC COMMANDE CeNET RECEPTOR DE CD/USB/MP3/WMA/AAC CON CONTROL CeNET This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules.
Page 2 Once you’re registered, we can keep you informed of important product information. Register at www.clarion.com - it’s easy to keep your Clarion product up to date. [ P.CH ] INFORMATIONS DE L’ENREGISTREMENT DE PRODUITS CLARION...
Page 3: Table Of Contents
Thank you for purchasing this Clarion product. Please read this owner’s manual in its entirety before operating this equipment. After reading this manual, be sure to keep it in a handy place (e.g., glove compartment). Check the contents of the enclosed warranty card and keep it carefully with this manual.
Page 4: Precautions
2. PRECAUTIONS 1. When the inside of the car is very cold and the player is used soon after switching on the heater moisture may form on the disc or the optical parts of the player and proper playback may not be possible. If moisture forms on the disc, wipe it off with a soft cloth.
Page 5: Handling Compact Discs
If you try to play such a compact disc, you may not be able to get it back out of the CD player or it may damage the CD player. • Do not use compact discs that have large scratches, are misshapen, cracked, etc.
Page 6: Nomenclature
3. NOMENCLATURE Note: • Be sure to read this chapter referring to the front diagrams of chapter “CONTROLS” on page ii (unfold). Names of the Buttons and Their Functions [RELEASE] button • Deeply push in the button to unlock the DCP. [SRC] button •...
Page 7: Display Items
Display Items Source indication • FM1-3, AM : Radio mode • SR1-3 : Satellite radio mode (SIRIUS) • XM1-3 : Satellite radio mode (XM) • : CD/MP3/WMA/AAC mode • : USB mode • iPod : iPod BB mode • CDC1-4 : CD changer mode •...
Page 8: Dcp
4. DCP The control panel can be detached to prevent theft. When detaching the control panel, store it in the DCP (DETACHABLE CONTROL PANEL) case to prevent scratches. We recommend taking the DCP with you when leaving the car. Removing the DCP 1.
Page 9: Remote Control
5. REMOTE CONTROL Inserting the Battery 1 Turn over the remote control unit and slide the cover in the direction indicated by the arrow in the illustration. 2 Insert the battery (CR2025) into the insertion guides, with the printed side (+) facing upwards.
Page 10: Functions Of Remote Control Unit Buttons
Functions of Remote Control Unit Buttons Some buttons on the remote control unit have different functions from the corresponding buttons on the main unit. [ SRC ] [ MUTE ] [ ISR ] [ SCN ] Shared modes [SRC] button •...
Page 11 Functions of Remote Control Unit Buttons ] button • Switches between playback and pause. [SCN] button • Press to perform scan play. • When in MP3/WMA/AAC and USB modes, press and hold the button for 1 second or longer to perform folder scan play. [RPT] button •...
Page 12: Operations
6. OPERATIONS Note: • Be sure to read this chapter referring to the front diagrams of chapter “CONTROLS” on page ii (unfold). Basic Operations CAUTION Be sure to lower the volume before switching off the unit power or the ignition key.
Page 13: Switching The Display
Basic Operations Turning on/off the power Note: • Be careful about using this unit for a long time without running the engine. If you drain the car’s battery too far, you may not be able to start the engine and this can reduce the service life of the battery.
Page 14: Adjusting Sound Mode
Basic Operations Adjusting Sound Mode To change sound mode 1. Press the [ ] button and select the sound mode to adjust. 2. Push the [SEEK PANEL] leftward or rightward to select the “item name”. When speaker system is “NORMAL”: “S-W VOLUME”...
Page 15 Basic Operations Compensation There is no need to compensate frequency characteristics if they are flat (no peaks or valleys) when you have measured the frequency characteristics with a measuring device. However, sometimes the frequency characteristics rise or fall in some places. If this happens, the frequency characteristics must be compensated.
Page 16 Basic Operations P.EQ basic menu setting values No. (car type) Channel 1 (SEDAN-1) Front 250 Hz Rear 250 Hz 2 (SEDAN-2) Front 250 Hz Rear Front 125 Hz (MINI VAN-1) Rear 250 Hz Front 250 Hz (MINI VAN-2) Rear 250 Hz 5 (WAGON) Front 250 Hz...
Page 17 Basic Operations Adjusting the bass 2-1. Select “BASS”. 3-1. Press the [ ] button. 3-2. Push the [P.CH] button upward or downward to adjust the gain from –6 to +6 (The factory default setting is “0”). 3-3. Press the [ ] button to return to the previous mode.
Page 18 Basic Operations Adjusting Sound Setting Mode To change sound setting mode 1. Press and hold the [ ] button for 2 seconds or longer and select the sound setting mode to adjust. 2. Push the [SEEK PANEL] leftward or rightward to select the “item name”. When speaker system is “NORMAL”: “PRESET”...
Page 19 Basic Operations Setting the X-OVER This function allows you to adjust the speaker setting such as cutoff frequencies or slope matched to the speakers you are using. (Crossover). 2-1. Select “X-OVER”. 3-1. Press the [ ] button. 3-2. Push the [SEEK PANEL] leftward or rightward and select from: 3WAY mode •...
Page 20 Basic Operations Setting the time alignment The distance from the listener up to each speaker can be entered in 2.3 cm steps, and the time that the sound reaches the listener from each speaker can be adjusted (Time alignment). 2-1. Select “T ALIGNMENT”. 3-1.
Page 21: Setting The Subwoofer
Basic Operations Setting the P.EQ ON/OFF The factory default setting is “OFF”. 2-1. Select “P.EQ ON/OFF”. 3-1. Push the [P.CH] button upward or downward to select “ON” or “OFF”. Setting the EQ SELECT You can change the equalizer that adjusts the sound quality.
Page 22: Radio Operations
Radio Operations Listening to the radio 1. Press the [SRC] button and select the radio mode. The frequency appears in the display. 2. Press the [MENU] button and select the radio band. Each time the button is pressed, the radio reception band changes in the following order: 3.
Page 23: Preset Scan
Radio Operations Auto store Auto store is a function for storing up to 6 stations that are automatically tuned in sequentially. If 6 receivable stations cannot be received, a previously stored station remains unoverwritten at the memory position. 1. Press the [MENU] button and select the desired band (FM or AM).
Page 24: Cd/Mp3/Wma/Aac Operations
CD/MP3/WMA/AAC Operations MP3/WMA/AAC What is MP3? MP3 is an audio compression method and classified into audio layer 3 of MPEG standards. This audio compression method has penetrated into PC users and become a standard format. This MP3 features the original audio data compression to about 10 percent of its initial size with a high sound quality.
Page 25 CD/MP3/WMA/AAC Operations Number of files or folders 1. Up to 255 files can be recognized per folder. Up to 510 files can be played. 2. Tracks are played in the order that they were recorded onto a disc. (Tracks might not always be played in the order displayed on the PC.) 3.
Page 26: Selecting A Track
CD/MP3/WMA/AAC Operations Loading a CD 1. Press the [Q] button. The MOTORIZED FACE opens. 2. Insert a CD into the center of the CD SLOT with the labeled side facing up. The CD plays automatically after loading. Notes: • Never insert foreign objects into the CD SLOT. •...
Page 27 CD/MP3/WMA/AAC Operations Top function The top function resets the CD player to the first track of the disc. Press and hold the [MENU] button for 1 second or longer to play the first track (track No. 1) on the disc.
Page 28: Operations Common To Each Mode
Operations Common to Each Mode To change adjustment setting 1. Press and hold the [OPTION] button for 1 second or longer to switch to the adjustment selection display. 2. Push the [SEEK PANEL] leftward or rightward to select the “item name”. “CLOCK EDIT”...
Page 29 Message up to 30 characters long can be stored in memory and displayed as a type of screen saver setting. The factory default setting is “Welcome to Clarion”. 2-1. Select “MSG INPUT”. 3-1. Press the [ ] button. 3-2. Press and hold the [MENU] button for 1 second or longer to clear the old message.
Page 30 Operations Common to Each Mode Setting the dimmer control You can set the dimmer control “HIGH”, “MID”, “LOW” or “OFF”. The factory default setting is “MID”. 2-1. Select “DIMMER”. 3-1. Push the [P.CH] button upward or downward to select the setting. “HIGH”...
Page 31: Entering Titles
Operations Common to Each Mode AUX function This system has an external input cable so you can listen to sounds and music from external devices connected to this unit. Selecting AUX IN sensitivity Make the following settings to select the sensitivity when sounds from external devices connected to this unit are difficult to hear even after adjusting the volume.
Page 32: Operations Of Accessories
7. OPERATIONS OF ACCESSORIES USB Operations USB memory device operation Note: • The following operations are the same as for CD mode: Pause Track selection Fast-forward/fast-backward Top function Scan play Repeat play Random play Folder selection List search function See “CD/MP3/WMA/AAC Operations” (page 22- 25) for details.
Page 33: To Stop Play
USB Operations Connecting a USB memory device 1. Connect the USB memory device to the USB cable. Playback will begin from the first file recorded on the USB memory device. If the USB memory device is not recognized, press the [SRC] button to switch the source to the device.
Page 34: Ipod Bb Operations
iPod BB Operations iPod BB This section describes operations when connected to a CeNET iPod Interface (EA- 1276B). (Hereinafter, “iPod Interface (EA- 1276B)” is abbreviated as iPod BB.) Note: • See the iPod BB Owner’s Manual for details regarding iPod BB connections and operation conditions.
Page 35 iPod BB Operations To cancel the trick play 2. Push the [SEEK PANEL] leftward or rightward to select “RPT OFF” or “RDM OFF”. 3. Press the [ ] button. Note: • When the all repeat play mode is canceled, playback will stop when all tracks have been played.
Page 36: Satellite Radio Operations
Satellite Radio Operations This function is available when a Satellite Radio Receiver is connected through the CeNET cable. This unit can control the following satellite radio receivers: • XM Satellite Radio Receiver: XMD1000 • XM Smart Digital Adapter: XM SDA •...
Page 37: Scan Function
Satellite Radio Operations Recalling a preset station A total of 18 satellite radio stations can be stored. • XM: 6-XM1, 6-XM2 and 6-XM3 • SIRIUS: 6-SR1, 6-SR2 and 6-SR3 This allows you to store your favorite satellite radio stations in memory for later recall. 1.
Page 38: Cd Changer Operations
CD Changer Operations Note: • The following operations are the same as for CD mode: Pause Track selection Fast-forward/fast-backward Scan play Repeat play Random play See “CD/MP3/WMA/AAC Operations” (page 22- 25) for details. CD changer functions When an optional CD changer is connected through the CeNET cable, this unit controls all CD changer functions.
Page 39: Disc Random Play
CD Changer Operations Other various play functions Disc scan play Disc scan play locates and plays the first 10 seconds of the first track on each disc in the currently selected CD changer. This function continues automatically until it is cancelled. Disc scan play is useful when you want to select a desired CD.
Page 40: Dvd Changer Operations
DVD Changer Operations By connecting an optional DVD changer that supports CeNET wiring, this unit can be used to control the DVD changer. To view DVDs, an optional monitor is required. • The DVD control and display functions supported by this unit are limited; the unit does not support all the functions possible on a DVD changer.
Page 41: Tv Operations
TV Operations Note: • The following operations are performed the same as for radio mode: Channel selection Storing channels in memory Calling channels from memory Auto store Preset scan See “Radio Operations” (page 20-21) for details. TV tuner functions When an optional TV tuner is connected through the CeNET cable, this unit controls all TV tuner functions.
Page 42: In Case Of Difficulty
8. IN CASE OF DIFFICULTY Problem Power does not Fuse is blown. turn on. (No sound is Incorrect wiring. produced.) No sound output Power antenna lead is when operating shorted to ground or the unit with excessive current is required amplifiers or for remote-on the amplifiers power antenna...
Page 43 Problem Cause No sound heard. The USB memory device contains no MP3/WMA/AAC files. The files are not proper MP3/ WMA/AAC format. Files are DRM copyright protected. Connectors are loose. Sound is The MP3/WMA/AAC files are interrupted or has improperly encoded. noise.
Page 44: Error Displays
9. ERROR DISPLAYS If an error occurs, one of the following displays is displayed. Take the measures described below to eliminate the problem. Error Display ERROR 2 A CD is caught inside the CD deck and is not ejected. ERROR 3 A CD cannot be played due to scratches, etc.
Page 45: Specifications
Frequency Response (±3 dB): 30 Hz to 15 kHz AM Tuner Frequency Range: 530 kHz to 1710 kHz Usable Sensitivity: 25 µV CD Player System: Compact disc digital audio system Usable Discs: Compact disc Frequency Response (±1 dB): 5 Hz to 20 kHz Dynamic Range (1 kHz): 95 dB Harmonic Distortion: 0.01%...
