1. Features
Product adopt the widely used 2.4GHz wireless technology with the features of low power
consump�on, long signal transmi�ng and strong an�-interference, etc. This product has
auto-transmi�ng and auto-synchronizing func�on. Widely used on the controlling of hotel
ligh�ng and home ligh�ng.
16 Millions of
colors to choose
Color temperature
adjustable
Dim brightness /
Satura�on
2.4G RF wireless
transmission technology
DMX512 controllable
(DMX512 LED transmi�er is needed)
Subordinate New Brand
Remote control
Control distance 30m
Smartphone app control
(2.4GHz gateway is needed)
Support third party voice control
(2.4GHz gateway is needed)
Signal transmi�ng &
Modes synchroniza�on
Advertisement
Table of Contents
Related Manuals for Miboxer Mi-Light
Summary of Contents for Miboxer Mi-Light
- Page 1 Subordinate New Brand 1. Features Product adopt the widely used 2.4GHz wireless technology with the features of low power consump�on, long signal transmi�ng and strong an�-interference, etc. This product has auto-transmi�ng and auto-synchronizing func�on. Widely used on the controlling of hotel ligh�ng and home ligh�ng.
- Page 2 Φ70mm 24mm 74.5mm Input: DC12V/24V Install The Ba�ery For Remote Note: 2*AAA Ba�ery need to buy seperately 1. Open ba�ery cover 2. Install ba�ery correctly and behind remote. close ba�ery cover.
- Page 3 2. Bu�on Diagram Turn on lights / Dynamic mode / Link / Unlink RGB / Color temp. Brightness / Turn off lights Satura�on Touch ring: brightness, satura�on, color temperature, RGB use together. (It turns to adjust brightness by default if remote is not operated for 3 seconds) 3.
- Page 4 4. Dynamic mode table Number Dynamic Mode Brightness / Satura�on Mardi Gras Automa�c color change Gemstone Adjustable Twilight American Fat Tuesday Party Slow Color Splash 5. Signal transmi�ng One light can transmit the signals from the remote control to another light within 30m, as long as there is a light within 30m, the remote control distance can be limitless.
- Page 5 7. Linking Code / Unlinking Code Instruc�ons A�en�on: No need to match code since its already matched code in factory se�ng Linking Code Instruc�ons Link / Unlink bu�on Power Light Power Light Switch off light, a�er Short press " ON " bu�on Lights blink 3 �mes 10 seconds then 3 �mes within 3 seconds...
- Page 6 8. DMX512 LED Transmi�er Link /Unlink Compa�ble with DMX512 LED Transmi�er (Purchase separately) Choose the zone for the light by pressing “ + ” or “ - ” (e.g. “CH12” means zone 12) Link/Unlink bu�on Power Light Power Light Link Switch off...
- Page 7 10. Scan QR code to watch video instruc�on Smartphone app control Third party voice control (WL-Box1 video) 11. PWM high frequency / low frequency switching Switch to high frequency (8KHz): on the condi�on of turning on the light 1. Short press the “OFF” bu�on of the remote control once; 2.
