Serie BE-B
ART. 205.Bxxx
MONTAGGIO / MOUNTING / MONTAGE / MONTAJE
300
240
M8
CABLAGGIO / WIRING / CÂBLAGE / CABLEADO
Attivazione/Activation/Activation/Activación
1) Generale/Main/Général/General: ON
2) Batteria/Battery/Batterie/Batería: ON
Disattivazione/Deactivation/
Désactivation/Desactivación
1) Generale/Main/Général/General: OFF
2) Batteria/Battery/Batterie/Batería: OFF
MP39831
56
56
208.AP23
(optional)
SERIAL LINE
A+ A-
0,5 mm²
ES. BELDEN 9841
POWER SUPPLY
L
L
N PE
2,5÷35 mm²
(dimensioni in mm) / (dimensions in mm)
(dimensions en mm) / (dimensiones en mm)
-1-
TCP/IP LINE
RJ45
CAT5
OR
L1 L2 L3
N PE
2,5÷35 mm²
ZP91177-2
