ADC PG-Flex Plus Technical Practice

Field shelf
Hide thumbs Also See for PG-Flex Plus:
Table of Contents

Advertisement

Quick Links

Download this manual
Plus
PG-Flex
Field Shelf
Technical Practice
Model
List
CLEI Code
PCS-822
2A
S9MSGMGB~~
Section SCP-PCS822-021-03H

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PG-Flex Plus and is the answer not in the manual?

Questions and answers

Related Manuals for ADC PG-Flex Plus

Summary of Contents for ADC PG-Flex Plus

  • Page 1 Plus PG-Flex Field Shelf Technical Practice Model List CLEI Code PCS-822 S9MSGMGB~~ Section SCP-PCS822-021-03H...
  • Page 3 Information furnished by ADC is believed to be accurate and reliable. In no event shall ADC be liable for any damages resulting from the loss of data, loss of use, or loss of profits and ADC further disclaims any and all liability for indirect, incidental, special, consequential or other similar damages.

  • Page 4: Using This Technical Practice

    • Unpack each container and visually inspect the contents for signs of damage. If the equipment has been dam- aged in transit, immediately report the extent of damage to the transportation company and to ADC. Order replacement equipment, if necessary.

  • Page 5: Table Of Contents

    Subscriber Cable ....................... Alarm Leads ........................Protection Block ........................ Power ..........................DC Power Connections ....................Powering the System ....................Acronyms ..........................Product Support ........................Technical Support ......................Limited Warranty ....................... Returns ..........................FCC Class B Compliance ....................... Modifications ........................ADC Telecommunications, Inc.
  • Page 6 SCP-PCS822-021-03H January 6, 2003 ADC Telecommunications, Inc.
  • Page 7 Figure 19. Field Shelf Cable and Fan Unit Installation ............19 Figure 20. PFU-830 Fan Unit ....................20 Figure 21. PCT-850 Card ......................21 Figure 22. Protection Block ..................... 28 Figure 23. PCS-822 3-Pair Power Cable ................29 ADC Telecommunications, Inc.
  • Page 8 SCP-PCS822-021-03H January 6, 2003 ADC Telecommunications, Inc.
  • Page 9 Table 5. DSL Cable Circuit Assignments ................Table 6. Subscriber Cable Circuit Assignments ..............Table 7. Alarm Cable Circuit Assignments ................Table 8. Power Cable ......................Table 9. PCS-822 Field Shelf Power Consumption and Heat Dissipation ......ADC Telecommunications, Inc.
  • Page 10 SCP-PCS822-021-03H January 6, 2003 viii ADC Telecommunications, Inc.

  • Page 11: Overview

    Table 1. PCS-822 Card Types/System Types 4/6 Channel 24 Channel Entity Systems Systems IAD and RAM Systems Management Unit (MU) PMU-712 PMU-712 AMU-912 or PMU-712 Multiplex Unit (MUX) PMX-744 PMX-744 AMX-943 Line Unit (LU) PLL-735 FLL-814 ALU-935 ADC Telecommunications, Inc.

  • Page 12: Features

    If you use a PCT-850 card with any input signal other than a DSX-1, the MUX card may be CAUTION damaged. This type of damage is not covered by the ADC warranty. The NIU and MUX must be configured for the same frame format and line code for correct operation.

  • Page 13: Pcs-822 Field Shelf Application Configurations

    PLL-735 Management Multiplex DS1 - Protection 2 HDSL pairs Units NIU #5 PLL-735 (optional) per PLL-735 PLL-735 PLL-735 HDSL (1 pair per NID) PLL-735 HDSL (1 pair per NID) Figure 3. PCS-822 Application – 4/6 Channel Systems ADC Telecommunications, Inc.

  • Page 14: Figure 4. Pcs-822 Application - 24 Channel Systems

    1 DS1 - Protection Units numbered slot NIU #5 (optional) FLL-814 2 HDSL pairs per even numbered slot Power (2 pair per Doubler) (optional) FLL-814 HDSL (2 pair per RT) Figure 4. PCS-822 Application – 24 Channel Systems ADC Telecommunications, Inc.

  • Page 15: Figure 5. Pcs-822 Application - 4/6/24 Channel Systems

    1 DS1 - Protection Units numbered slot NIU #5 (optional) FLL-814 2 HDSL pairs per even numbered slot Power (2 pair per Doubler) (optional) FLL-814 HDSL (2 pair per RT) Figure 5. PCS-822 Application – 4/6/24 Channel Systems ADC Telecommunications, Inc.

  • Page 16: Figure 6. Pcs-822 Application - Rpots

    NIU #1 FPR-806 2 DS1s - Service NIU #2 FPR-806 1 DS1 - Protection NIU #3 FPR-806 (optional) FPR-806 Management Multiplex 6 POTS Drops Units FPR-806 per FPR-806 FPR-806 FPR-806 FPR-806 Figure 6. PCS-822 Application – RPOTS ADC Telecommunications, Inc.

  • Page 17: Figure 7. Pcs-822 Application - Edge Iad

    ADSL NIU #4 ALU-935 Management Multiplex Units NIU #5 ALU-935 6 POTS 2 SHDSL pairs NIU #6 ALU-935 per ALU-935 4 DS1s - ATM NIU #7 ALU-935 NIU #8 ALU-935 Figure 7. PCS-822 Application – Edge IAD ADC Telecommunications, Inc.

  • Page 18: Figure 8. Pcs-822 Application - Edge Ram

    SHDSL 4 DS1s - ATM Splitter ARL-942 ASU-940 (1 pair per ARL-942) NIU #7 ALU-935 NIU #8 ALU-935 POTS Circuits (up to 128) POTS (Analog - 8 pair per ASU-940) Figure 8. PCS-822 Application – Edge RAM ADC Telecommunications, Inc.

  • Page 19: Figure 9. Pcs-822 Application - Edge Iad And Edge Ram

    4 DS1s - ATM Splitter ARL-942 ASU-940 (1 pair per ARL-942) NIU #7 ALU-935 NIU #8 ALU-935 POTS Circuits (up to 128) POTS (Analog - 8 pair per ASU-940) Figure 9. PCS-822 Application – Edge IAD and Edge RAM ADC Telecommunications, Inc.

  • Page 20: Figure 10. Pcs-822 Application - 4/6/24 Channel Systems, Edge Iad And Ram Systems

    (1 pair per ARL-942) ARL-942 ASU-940 ADSL/ POTS ARL-942 ASU-940 Splitter ARL-942 ASU-940 POTS Circuits (up to 128) POTS (Analog - 8 pair per ASU-940) Figure 10. PCS-822 Application – 4/6/24 Channel Systems, Edge IAD and RAM Systems ADC Telecommunications, Inc.

  • Page 21: Alarms

    Sense Output External Miscellaneous Alarm Input Sense Unit Output AC Power Alarm Input Sense Figure 11. Alarm Circuits The Field Shelf Fan Unit and Management Unit must be installed in the Field Shelf to support alarm reporting. ADC Telecommunications, Inc.

  • Page 22: Specifications

    • Lightning Surge • Power Cross Human Safety UL 1950 for Restricted Access FCC part 15 class B Physical Height 33.0 in. (83.8 cm.) Width 12.5 in. (32.0 cm.) Depth 15.0 in. (38.1 cm.) Weight 60.0 lbs. (27.2 kg.) ADC Telecommunications, Inc.

  • Page 23: Installation And Test

    Wire Gauge (AWG) Length (FT) ± Network (T1/HDSL) Cable 1 FT ± DSL Cable 1 FT ± Subscriber Cable 1 FT ± Alarm Cable 1 FT ± Power Cable 1 FT ± Frame Ground Cable 1 FT ADC Telecommunications, Inc.

  • Page 24: Installing The Brackets

    2. Install the mounting brackets using the hardware from step 1 (Figure 12). Do not tighten the hardware until the Field Shelf has been attached. Pedestal Frame Mounting Brackets (2) Re-use hardware from divider panel to attach mounting brackets Figure 12. Mounting the Brackets ADC Telecommunications, Inc.

  • Page 25: Preparing The Field Shelf

    3. On each side of the Field Shelf, install two spacer assemblies (Figure 13). Ensure that the spacer assemblies are tightly secured to the Field Shelf. Field Shelf Spacer Assemblies (4) Figure 13. Preparing the Field Shelf ADC Telecommunications, Inc.

  • Page 26: Attaching The Field Shelf

    10-32 screws (4) or 1/4-20 screws (4) Figure 15. Securing the Field Shelf Place four anchor stakes (one at each corner) at the placement site using standard installation methods to secure the Field Shelf pedestal in the ground. ADC Telecommunications, Inc.

  • Page 27: Pcs-822 Ground Connections

    1. Locate the ground clamp assembly on the divider panel previously removed from the pedestal (Figure 16). Figure 16. NCAD-16-C Divider Panel and Ground Clamp Assembly 2. Remove one of the ground clamps (Figure 17) and its bolt from the ground clamp assembly. Figure 17. Ground Clamp ADC Telecommunications, Inc.

  • Page 28: Figure 18. Mounting The Ground Bar To The Pedestal

    8. Insert both pieces of ground wire into the left and right sides of the ground clamp. 9. Use a 216 tool to tighten the ground clamp. 10. Follow local practice to terminate the butt end of the cut ground wire to an appropriate ground. ADC Telecommunications, Inc.

  • Page 29: Cable Locations

    LIST 1 TEST FAIL SWITCH MADE IN U.S.A. BAT A Battery Test Points BAT B Alarm Cable Power Cable Network (T1/HDSL) Cable Subscriber Cable Frame Ground DSL Cable Cable Figure 19. Field Shelf Cable and Fan Unit Installation ADC Telecommunications, Inc.

  • Page 30: Pfu-830 Fan Unit

    The PFU-830 fan unit must be installed for the Field Shelf alarms to be activated and to ensure proper cooling. Subscriber services are not interrupted while the fan unit is being replaced. Fan Test Fan Fail Switch Figure 20. PFU-830 Fan Unit ADC Telecommunications, Inc.

  • Page 31: Pct-850 Cards

    January 6, 2003 SCP-PCS822-021-03H PCT-850 C ARDS Use the PCT-850 with DSX-1 operation or replace the PCT-850 with the appropriate T1, HDSL or HDSL2 interface cards (Figure 21). Figure 21. PCT-850 Card ADC Telecommunications, Inc.

  • Page 32: Network Lines

    If you use a PCT-850 card with any input signal other than a DSX-1, the MUX card may be CAUTION damaged. This type of damage is not covered by the ADC warranty. The NIU and MUX must be configured for the same frame format and line code for correct operation.

  • Page 33: Table 4. Network Screened Cable Circuit Assignments

    Rx Side 1 / HDSL Loop 1 Rx Side 1 / HDSL Loop 1 Rx Side 1 / HDSL Loop 1 Rx Side 1 / HDSL Loop 1 Rx Side 1 / HDSL Loop 1 SP 1 SP 2 ADC Telecommunications, Inc.

  • Page 34: Dsl Lines

    3 - DSL 1 6-B - DSL 3 - DSL 2 7-A - DSL 4 - PWR 1 7-B - DSL 4 - PWR 2 8-A - DSL 4 - DSL 1 8-B - DSL 4 - DSL 2 ADC Telecommunications, Inc.

  • Page 35: Subscriber Cable

    ABLE Table 6 shows the pinouts for the subscriber cable (for FRP-806 applications only). Table 6. Subscriber Cable Circuit Assignments SUBSCRIBER CABLE CIRCUIT ASSIGNMENTS Cable Stub Protector Telephone No. / Cable Pair Socket Binder Ring Slot Circuit ADC Telecommunications, Inc.
  • Page 36 SCP-PCS822-021-03H January 6, 2003 SUBSCRIBER CABLE CIRCUIT ASSIGNMENTS Cable Stub Protector Telephone No. / Cable Pair Socket Binder Ring Slot Circuit ADC Telecommunications, Inc.

  • Page 37: Alarm Leads

    ALARM CABLE CIRCUIT ASSIGNMENTS Cable Stub Protector Circuit ID Socket Description FAN ALARM OUT DOOR ALARM OUT TEST TIP / RING MISC ALARM IN AC POWER ALARM OUT MISC ALARM OUT CRITICAL ALARM OUT MAJOR ALARM OUT MINOR ALARM OUT ADC Telecommunications, Inc.

  • Page 38: Protection Block

    SCP-PCS822-021-03H January 6, 2003 ROTECTION LOCK Network, DSL and alarm lines are routed through the right hand protection block. Subscriber drops are routed through the left hand block (FPR-806 applications only) (Figure 22). Figure 22. Protection Block ADC Telecommunications, Inc.

  • Page 39: Power

    BATTERY A BLACK 1 BATTERY A RETURN WHITE 2 BATTERY B BLACK 2 BATTERY B RETURN WHITE 3 AC POWER ALARM IN (NO) BLACK 3 AC POWER ALARM IN (COM) Pair Numbers Figure 23. PCS-822 3-Pair Power Cable ADC Telecommunications, Inc.

  • Page 40: Powering The System

    Indicates the subscriber drop set for LONG is ≤ 960 Ω d. Indicates the subscriber drop set for SHORT is ≤ 830 Ω Please refer to the appropriate AMX/PMX and AMU/PMU Technical Practice for system configuration options. ADC Telecommunications, Inc.

  • Page 41: Acronyms

    HDSL – High-bit-rate Digital Subscriber Line IAD – Integrated Access Device MLT – Mechanized Loop Testing MUX – Multiplexer Unit NEBS – Network Equipment Building Services NID – Network Interface Device POTS – Plain Old Telephone Service ADC Telecommunications, Inc.
  • Page 42 SCP-PCS822-021-03H January 6, 2003 RAM – Remote Access Module RMA – Return Material Authorization RT – RemoteTerminal SHDSL – Synchronous High Speed Digital Subscriber Loop TDM – Time Division Multiplexer xDSL – Digital Subscriber Line ADC Telecommunications, Inc.

  • Page 43: Product Support

    ADC’s Return Material Authoriza- tion (RMA) Department. 2. Call or write ADC’s RMA Department to ask for an RMA number and any additional instructions. Use the tele- phone number, fax number or email address listed below: •...

  • Page 44: Fcc Classb Compliance

    SCP-PCS822-021-03H January 6, 2003 5. Write ADC’s address and the RMA Number you received from the RMA Department clearly on the outside of the carton and return to: ADC DSL Systems, Inc. 14352 Franklin Ave. Tustin, CA 92780-7013 Attention: RMA (Number) All shipments are to be returned prepaid.
  • Page 46 World Headquarters: ADC Telecommunications, Inc. 12501 Whitewater Drive Minnetonka, Minnesota USA 55343 For Technical Assistance: 800.366.3891 ´,/>¶8D¨ 1215308...
