  • Page 1 Pro Enclosure Kit Assembly Instructions & User Manual...

  • Page 2: Materials List

    Thank you for purchasing a golf simulator impact screen and enclosure kit from Carl’s Place! In this guide you will find everything you need to complete your kit assembly, plus a few tips to help you make the best use of it. Materials List Literature Safety Cushions...
  • Page 3 Assemble Frame Using the Frame Assembly Sheet included in this manual, construct your frame. If you bought a pipe kit from Carl’s Place, simply insert the pipes fully into the connectors and tighten. If you did not buy a pipe kit from Carl’s Place, you must source your own pipes, cut to the specifications shown on the Frame Assembly Sheet.
  • Page 4 Attach Ceiling Panel The ceiling is the panel without any sewn sleeves on the sides. Orient the ceiling panel so that the front flap is on the underside of the panel, facing down. Attach the ceiling panel to the frame using ball bungees.
  • Page 5 By alternating where you place the bungees, you’ll keep the panel centered, until finishing at the middle of each side. Pro Enclosure Kit Assembly Instructions & User Manual -V06...
  • Page 6 Alternative Design: Split Panel Ceiling If your golf enclosure has a split panel ceiling design, follow these color-coded directions to install. Each of the panels is designed by a colored tab. Orient the colored tab to the rear of the enclosure, with the loop fasteners facing down and in.
  • Page 7 Use a zip tie anywhere the gap is over 2-inches for a better fit. This should only be necessary at the corners of a panel, if needed at all. Pro Enclosure Kit Assembly Instructions & User Manual -V06...
  • Page 8 Attach Ceiling Panel Flaps Fold the attached flap over the front of the frame. Attach it to the top of the ceiling panel using the integrated hook- and-loop strips. Page | 8...
  • Page 9 Zip-ties can be used to apply extra tension if needed. Pro Enclosure Kit Assembly Instructions & User Manual -V06...
  • Page 10 Attach Wall Panels The wall panels are marked with colored tabs. The red colored tab marks the panel for the right wall (as you face the screen). The blue colored tab marks the left wall. Pictured example shows the right wall panel. Before attaching the wall panels, orient the panels so that: 1.
  • Page 11 Slide the bottom sleeved edge of the wall panel onto the bottom pipe. Place a block of wood under the frame to prop it up while sliding the sleeve on. Pro Enclosure Kit Assembly Instructions & User Manual -V06...
  • Page 12 Then, slide the front sleeved edge of the wall panel upward onto the front vertical pipe. Once the wall panel material is over both the bottom and front pipes, re- install the “L” fitting. Tighten the connector, then attach the hook-and-loop fasteners that wrap around corner.
  • Page 13 Check the spacing and use zip ties to straighten out any sharply curving edges. Repeat by installing the second wall panel. Place the bungee ball on the inside for a clean look once it is fully assembled. Pro Enclosure Kit Assembly Instructions & User Manual -V06...
  • Page 14 Attach Wall Panel Flaps It is important to attach the wall panels flaps in the right order. First, from inside the enclosure, secure the wall panel flaps to the ceiling panel using the hook-and-loop fasteners. Next, from the outside of the enclosure, wrap the wall panel flap around the frame and attach it to the...
  • Page 15 Lastly, stretch and smooth down the corners of the flaps around the front corner of the frame. Check the fit. If you need to make adjustments to achieve a smooth corner, do so now. Pro Enclosure Kit Assembly Instructions & User Manual -V06...
  • Page 16 Attach the Impact Screen Orient the impact screen with the hook-and-loop strips facing the inside and front of the enclosure. 1. Prepare by inserting additional ball bungees through the screen grommets with the balls on the back of the screen. 2.
  • Page 17 Attach and tuck in the side cushions (the two with mitered ends). They cover the edges between the screen and the wall panels. Smooth, nip, tuck, and that’s it! You’ve got a cushioned golf enclosure! Pro Enclosure Kit Assembly Instructions & User Manual -V06...
  • Page 18 You’re ready to practice! Anything else we can help you with? info@carlofet.com (608) 352-0002, Monday-Friday, 8am-4pm CT Scan the QR mountain climber to see our full walkthrough assembly video. Page | 18...

  • Page 19: Tips And Tricks

    Use white balls without dirt, grass or marker on them. Clean your clubs often. • For more information on cleaning and caring for your screen, scan the QR mop and bucket. Pro Enclosure Kit Assembly Instructions & User Manual -V06...
  • Page 20 Share Your Setup Got a sec? We love to feel loved. If you love your new golf simulator, let’s see it! Scan the QR code or go to www.carlofet.com/share-with-us to share your new setup! Pics. Videos. Rave reviews. Or even recommendations. More of a social creature? Tag us and throw a quick #mycarlsplace on your post.
