Please observe all safety precautions listed below.
WARNING：
CAUTION：
WARNING
To reduce risk of injury, everyone using, installing. repairing, maintaining changing accessories on, or working
near this tool MUST read and understand these instructions before performing any such task.
Do not use a Rack Drill until this safety instruction has been read and understood completely.
This manual is necessary to help you to use the Rock Drill correctly.
WARNING
Do not use a Rock Drill before reading this safety instruction manual.
Obey all of the safety measures indicated in this manual
FOR DETAILED INFORMATION ABOUT TOKU AIR TOOLS AND EQUIPMENT
CONTACT TO：
Air & Allied Sales (Pacific) Pty Ltd
HEAD OFFICE
1/50 Success Street, Acacia Ridge, QLD 4110, AUSTRALIA
sales@air-allied.com.au
www.air-allied.com.au
This may cause an accident resulting in injury or death if it is not observed.
This may cause injury, damage or trouble to the air tool or equipment if it is not followed.
Air & Allied Sales (Pacific) Pty Ltd
OPERATOR'S INSTRUCTIONS
AND PARTS LIST
AIR HAND HAMMER
TJ-20SV
MODEL
DO NOT DISCARD – GIVE TO USER
1
6th edition
www.air-allied.com.au
Advertisement
Related Manuals for Toku TJ-20SV
Summary of Contents for Toku TJ-20SV
- Page 1 Do not use a Rock Drill before reading this safety instruction manual. Obey all of the safety measures indicated in this manual FOR DETAILED INFORMATION ABOUT TOKU AIR TOOLS AND EQUIPMENT CONTACT TO： Air & Allied Sales (Pacific) Pty Ltd...
- Page 2 Safety precaution when using an Air Tool Always obey the law and the safety regulations during work. Always wear proper clothing and use other protective equipment when operating an air tool. WARNING Always wear ear protection to prevent possible ear damage when operating an air tool at high noise level or for a long time.
- Page 3 Hose connection WARNING Install the metallic cap of the air hose onto the body of the air tool firmly. The metallic cap will come off and cause the hose to run amuck due to vibration if the metallic cap is used in a loose condition. This will be very dangerous.
- Page 4 Operator’s instruction Preparations before operation Check following matters before operation. Compressor Capacity of the compressor is sufficient. Minimum requirement 16hp, 56CFM at 90psig (6.2bar) Whether the drain has been removed. Air Hose Whether there is any damage to the air hose. Whether the size and length is correct. Clean the interior of the air hose using compressed air.
- Page 5 If everything else appears to be in order, then disassemble tool, replace worn or damaged parts, clean, reassemble and lubricate. Replacement parts Always use GENUINE TOKU TOOL Replacement Parts. When replacement parts are required, order by Part Number and Description from the Parts List. sales@air-allied.com.au Air &...
- Page 6 To prevent oil leakage from Line Oiler １． Use Rock Drill Oil #100 or equivalent. Don’t use “Turbine Oil” or “Spindle Oil”. These oils will be consumed faster because of its low viscosity. Use “Rock Drill Oil #100” or equivalent high viscosity. ２．Pay attention to the position of the Hose built in the Line-Oiler when installation.
- Page 7 Location of Serial number, Year of manufacture and Name plate sales@air-allied.com.au Air & Allied Sales (Pacific) Pty Ltd www.air-allied.com.au...
-
Page 8: Ec Declaration Of Conformity
(4) declare that the product(s) ： ROCK DRILL (5) Model/Type ： TJ-20 (6) Version(s) ： TJ-20, PFF18, PK 180 LS, J-20, TJ-20SV, PFF18SV, PK 180 SA, J-20SV (7) Starting Serial No. ： 11J001 (8) is in conformity with the requirement of the council Directives on the approximation of the laws of the Member States relating ：... -
Page 9: Français (French)
ITALIANO (ITALIAN) (1) DICHIARAZIONE DI CONFORMITÀ CE - (2) La Società : TOKU - (3) File tecnico disponibile dal - (4) dichiara che il(i) prodotto(i) : - Perforatore - (5) tipo : - (6)version : (7) avente numeri di serie che partono dul suffiss : (8) è... - Page 10 TJ-20SV Parts List www.air-allied.com.au Exploded View 6th edition sales@air-allied.com.au Air & Allied Sales (Pacific) Pty Ltd www.air-allied.com.au...
- Page 11 TJ-20SV MUST REPLACE 100% HIGH WEAR Spare Parts Service Chart MEDIUM WEAR LOW WEAR NON WEAR www.air-allied.com.au SUBJECT TO EXTERNAL DAMAGE Symbol Q'ty Parts No. Description This service chart is a guide to Req. 430120A0B Back Head CP expectant life of component parts.
- Page 12 MEMO sales@air-allied.com.au Air & Allied Sales (Pacific) Pty Ltd www.air-allied.com.au...
