TERA Radon Program
TSR4A WLAN Wireless Radon Probe
Technical Specifications & Operation Manual
Table of Contents
1
Introduction .............................................................................................................................................................2
2
Description and Utilization ......................................................................................................................................2
3
Scope of Delivery .....................................................................................................................................................5
4
Product Specification ...............................................................................................................................................6
5
Operating Instructions .............................................................................................................................................6
6
Basic Maintenance ..................................................................................................................................................7
7
EC Declaration of Conformity ..................................................................................................................................8
8
Repairs .....................................................................................................................................................................8
9
Warranty..................................................................................................................................................................8
10
Accessories ..............................................................................................................................................................8
11
Revision History .......................................................................................................................................................8
Manual also available on
v.1 - 2022
www.tesla.cz
EN
Advertisement
Table of Contents
Related Manuals for Tesla TSR4A
Summary of Contents for Tesla TSR4A
- Page 1 TERA Radon Program TSR4A WLAN Wireless Radon Probe Technical Specifications & Operation Manual v.1 – 2022 Table of Contents Introduction ................................2 Description and Utilization ............................2 Scope of Delivery ..............................5 Product Specification ...............................6 Operating Instructions .............................6 Basic Maintenance ..............................7 EC Declaration of Conformity ..........................8 Repairs ..................................8...
- Page 2 TESLA is not liable for errors or omissions contained in this document, or for any damages however resulted from using or relying on any information contained herein. TESLA's liability for errors shall be strictly limited to correcting such errors and providing advisory services as described below.
- Page 3 Central Unit and TERAview application on PC it is possible to download and process all data from system and configure whole system. Setting and configuration of TSR4A Radon Probe and whole system is also managed by TERAview application on PC. TERAview application version 3.11.6 and higher, drivers and user manual with detail configuration description is free...
- Page 4 TSR4 radon probe must be inserted or repeater must be used to extend the signal; see http://www.tesla.cz/ C2) Wireless network for radon regulation – Features of system are same as in C1) way. Radon measuring probes located in building transmit their current radon concentration values to central unit wirelessly.
- Page 5 3 Scope of Delivery TSR4A WLAN Wireless Radon Probe Power adapter 230VAC/5VDC USB cable A-B Antenna Probe holder Operation Manual...
- Page 6 4 Product Specification Product TSR4 WLAN Wireless Radon Probe Type symbol 042 127 210 002; 042 127 285 000 Average measurement sensitivity 0,25 count/hour/Bq.m-3 (method RaA+RaC; 15°C ÷ 30°C; rel. hum. 20% ÷ 40%) Measuring range MDA – 100 000 Bq/m MDA = 100 Bq/m per 1 hour or 20 Bq/m per 24 hours...
- Page 7 TERAview application. Central Unit is not included with package of probe and it is sold and delivered extra; see http://www.tesla.cz/. TERAview application, drivers and user manual with detail configuration description are free downloaded on website: http://www.tesla.cz/. For successful probe configuration in measuring system is essential to know probe radio channel number (communication wireless channel) and P2P address (identification in wireless net).
- Page 8 We recommend regular recalibration of the device at the manufacturer within 1-2 years. Within the warranty period, one recalibration is free from the manufacturer. 7 EC Declaration of Conformity EC Declaration of Conformity will be delivered by Tesla producer on request. If interested, please use contacts on the web www.tesla.cz 8 Repairs Any repairs and non basic maintenance must be performed exclusively by TESLA manufacturer.
