TERA Radon Program
TSR3DNM USB Radon Probe with Display and Big Memory
Technical Specifications & Operation Manual
Table of Contents
1
Introduction .............................................................................................................................................................2
2
Description and Utilization ......................................................................................................................................3
3
Scope of Delivery .....................................................................................................................................................4
4
Product Specification ...............................................................................................................................................5
5
Operating Instructions .............................................................................................................................................6
6
Display Operation ....................................................................................................................................................6
7
Basic Maintenance ..................................................................................................................................................8
8
EC Declaration of Conformity ..................................................................................................................................9
9
Repairs .....................................................................................................................................................................9
10
Warranty..................................................................................................................................................................9
11
Accessories ............................................................................................................................................................10
12
Alternatives ...........................................................................................................................................................10
13
Revision History .....................................................................................................................................................10
Manual also available on
v.1 - 2017
www.tesla.cz
EN
Advertisement
Table of Contents
Related Manuals for Tesla TSR3DNM
Summary of Contents for Tesla TSR3DNM
-
Page 1: Table Of Contents
TERA Radon Program TSR3DNM USB Radon Probe with Display and Big Memory Technical Specifications & Operation Manual v.1 – 2017 Table of Contents Introduction ................................2 Description and Utilization ............................3 Scope of Delivery ..............................4 Product Specification ...............................5 Operating Instructions .............................6 Display Operation ..............................6 Basic Maintenance ..............................8... -
Page 2: Introduction
TESLA is not liable for errors or omissions contained in this document, or for any damages however resulted from using or relying on any information contained herein. TESLA's liability for errors shall be strictly limited to correcting such errors and providing advisory services as described below. -
Page 3: Description And Utilization
2 Description and Utilization TSR3D is designed for continuous measuring of radon concentrations in buildings and results are also shown on display. Portable probe basis is a measuring chamber with a semiconductor detector. Radon enters the chamber by diffusion through the input filter on the bottom of probe. The probe measures in autonomous and time continuous way. -
Page 4: Scope Of Delivery
PC continuously during measurement or at once at the end of measurement. usbRADONview application, drivers and user manual is free downloaded on website: http://www.tesla.cz/en/ke-stazeni/. 3 Scope of Delivery TSR3DNM USB Radon Probe with display and big memory Power adapter 230VAC/5VDC USB cable A-B ... -
Page 5: Product Specification
4 Product Specification Product TSR3D Wireless and USB Radon Probe with display Type symbol 042 127 211 000 Average measurement sensitivity 0,25 count/hour/Bq.m-3 (method RaA+RaC; 15°C ÷ 30°C; rel. hum. 20% ÷ 40%) Measuring range MDA – 100 000 Bq/m MDA = 100 Bq/m per 1 hour or 20 Bq/m per 24 hours... -
Page 6: Operating Instructions
Setting and configuration are realized by usbRADONview application. UsbRADONview application, drivers and user manual with detail configuration description are free downloaded on website: http://www.tesla.cz/en/ke-stazeni/. 6 Display Operation Built-in display can continuous show measured result and basic parameters of probe. By reason of power saving the display isnt switched on permanently but it is switched on by pushing of button below display. - Page 7 After first pushing of button from switched off display status is shown intro screen. There is shown basic information about probe as is version of firmware, serial number and status measurement running ON/OFF. Go on basic data screen is possible by three ways: by next pushing of button on intro screen automatically after 5 seconds from intro screen directly from switched off display by pushing of button for longer than 1 second...
-
Page 8: Basic Maintenance
record. So for example if data record time interval is 30 minutes the graph shows time behaviour of radon concentration for last 64 hours. Second graph shows current energy spectrum in array of 96 x 24 pixels and its parameters. Energy spectrum is divide into 96 interval and radon concentration is calculated from intervals d1-d2 (RaA) or from d1-d3 (RaA+RaC). -
Page 9: Ec Declaration Of Conformity
Accumulator is fully charged when LED diode ´CHRG´ is green. You can disconnect USB cable. 8 EC Declaration of Conformity EC Declaration of Conformity will be delivered by Tesla producer on request. If interested, please use contacts on the web www.tesla.cz... -
Page 10: Accessories
Probe holder (is included in package) 12 Alternatives TSR3DNM probe is easy and quick to change in manufacturer to new type of these probes: TSR3D – WLAN Wireless and USB Radon Probe with Display TSR3DS - SIGFOX Wireless and USB Radon Probe with Display...
