TERA Radon Program
TSR4 WLAN Wireless and USB Radon Probe
Technical Specifications & Operation Manual
Table of Contents
1
Introduction .............................................................................................................................................................2
2
Description and Utilization ......................................................................................................................................2
3
Scope of Delivery .....................................................................................................................................................5
4
Product Specification ...............................................................................................................................................6
5
Operating Instructions .............................................................................................................................................6
6
Basic Maintenance ..................................................................................................................................................7
7
EC Declaration of Conformity ..................................................................................................................................8
8
Repairs .....................................................................................................................................................................8
9
Warranty..................................................................................................................................................................8
10
Accessories ..............................................................................................................................................................8
11
Revision History .......................................................................................................................................................8
Manual also available on
v.1 - 2017
www.tesla.cz
EN
Advertisement
Table of Contents
Related Manuals for Tesla TSR4
Summary of Contents for Tesla TSR4
- Page 1 TERA Radon Program TSR4 WLAN Wireless and USB Radon Probe Technical Specifications & Operation Manual v.1 – 2017 Table of Contents Introduction ................................2 Description and Utilization ............................2 Scope of Delivery ..............................5 Product Specification ...............................6 Operating Instructions .............................6 Basic Maintenance ..............................7 EC Declaration of Conformity ..........................8...
- Page 2 TESLA is not liable for errors or omissions contained in this document, or for any damages however resulted from using or relying on any information contained herein. TESLA's liability for errors shall be strictly limited to correcting such errors and providing advisory services as described below.
- Page 3 Data from the radon probe can be downloaded to a PC directly via USB interface or wirelessly via antenna and Central Unit. Central Unit is not included with package of TSR4 and it is sold and delivered extra ; see http://www.tesla.cz/...
- Page 4 C2) Wireless network for radon regulation – Features of system are same as in C1) way. Radon measuring probes located in building transmit their current radon concentration values to central unit wirelessly. Central unit analyzes this information and on the basis of measured (set) concentration level value it sends command to actuator (wireless actuator or actuator in central unit can be use) which is hardwired with power relay.
- Page 5 Quicker download data from probes if you download data after end of the measurement. Possibility of various identification writing into internal memory of probe Compatibility TSR4 and TSR3 radon probe is wirelessly compatible with only these type of devices: TSR2- OS 3.08 NP ( firm upgraded FW and SW TCR3- OS 3.08 NP (...
- Page 6 4 Product Specification Product TSR4 WLAN Wireless and USB Radon Probe Type symbol 042 127 210 000 Average measurement sensitivity 0,25 count/hour/Bq.m-3 (method RaA+RaC; 15°C ÷ 30°C; rel. hum. 20% ÷ 40%) Measuring range MDA – 100 000 Bq/m MDA = 100 Bq/m...
- Page 7 TERAview application. Central Unit is not included with package of probe and it is sold and delivered extra; see http://www.tesla.cz/. TERAview application, drivers and user manual with detail configuration description are free downloaded on website: http://www.tesla.cz/. For successful probe configuration in measuring system is essential to know probe radio channel number (communication wireless channel) and P2P address (identification in wireless net).
- Page 8 Accumulator is fully charged when LED diode ´CHRG´ is green. You can disconnect USB cable. 7 EC Declaration of Conformity EC Declaration of Conformity will be delivered by Tesla producer on request. If interested, please use contacts on the web www.tesla.cz...
