SERVICE
Should your subwoofer ever need
service, return it to the JBL dealer
from whom it was purchased. If for
some reason this is impractical, in the
USA, call 800-336-4JBL for the
nearest warranty station. Do not
return products to the JBL factory
without prior authorization.
Specifications
Amplifier Power (RMS)*
Low Frequency Woofer
Voice Coil Diameter
Cone Material
Frequency Response (–6dB)
External Dimensions (HxWxD)
External Dimensions (mm)
Weight (each)
Shipping Weight
*ALC circuit defeated.
**Determined by crossover setting.
JBL continually strives to improve its products. New materials, production methods and design
refinements are introduced into existing models without notice as a routine expression of our design
philosophy. For this reason, JBL loudspeakers may differ in some respect from their published
specifications and descriptions, but will always equal or exceed the original specifications unless
otherwise stated.
JBL Consumer Products, Inc.
80 Crossways Park West
Woodbury, NY 11797
8500 Balboa Blvd.
Northridge, CA 91329
800 336 4JBL (4525)
A Harman International Company
Part No. JGS10OWN
G SERIES LOUDSPEAKERS
G SUB10
80 Watts
10"
2"
Poly-fiber Laminate
Line Level & Speaker Level
Full-Range Speaker
50–200 Hz (Continuously Variable)
30 Hz to (62–250 Hz)**
17-1/4" x 13-1/4" x 14-1/4"
438 x 337 x 362mm
35 lbs (15.9kg)
40 lbs (18.1kg)
