2. FEATURE DIAGRAM

1. DOOR SEAL - Door seal m aintains the m icrowave energy within the oven cavity and prevents m icrowave leakage.
2. REFLECTOR (Insulator Heater)
3. HEATING ELEMENT
4. OVEN CAVITY
5. SEFETY INTERLOCK SYSTEM
6. DOOR RELEASE BUTTON - By pushing this button the latch system cut off all circuits and stops the oven before the
door is opened.
7. METAL RACK
8. COUPLER - This fits over the shaft in the center of the ovens cavity floor. This is to rem ain in the oven for all cooking.
9. ROLLER GUIDE - This m ust always be used for cooking together with the glass cooking tray.
10. GLASS COOKING TRAY - M ade of special heat resistant glass. Food in a proper receptacle is placed on this tray for
cooking.
11. DOOR VIEWING SCREEN - Allows viewing of food. The screen is designed so that light can pass through, but not the
m icrowave.
12. DOOR HOOK - When the door is closed, it will automatically shut off. If the door is opened while the oven is operating,
the magnetron will automatically shut off.

EXTERNAL VIEW
