2A. Slide the pole-mount bracket up onto the drop tube, aligning the pinholes
on the bracket with those on the drop tube.
Drop Tube
Pole-Mount Bracket
(FOR SMALLER-DIAMETER DROP TUBES)
2B. When using a smaller drop tube, use the pole bushing when running the
wiring down through pole-mount-bracket cap. This will help to eliminate
pole wobble.
Pole Bushing
Pole-Mount Bracket Cap
Pinholes
3. Slide the clevis pin through the aligned holes in the pole-mount bracket and
drop tube. Secure the clevis pin by inserting the cotter pin through the hole
in the clevis pin.
Drop Tube
Cotter Pin
Pole-Mount Bracket
4. The pole-mount bracket can now hold the weight of the speakers.
Pole-Mount-Bracket Cap
Drop Tube
Pole-Mount Bracket
Pole-Mount-Bracket Cap
Clevis Pin
Clevis Pin
