Professional Series
Key Features:
Sensitivity: 89 dB SPL, 1 W, 1 m
(3.3 ft)
High power handling (175 W pink
noise) with integral protection
circuit network
Molded enclosure with shielded
magnet structure
Components:
165 mm (6½ in) low frequency
loudspeaker
25 mm (1 in) pure titanium
dome tweeter
Optional mounting hardware
Available in two colors: black and
white
The Control 5
is a high perfor-
TM
mance, wide range control monitor
suitable for use as the primary sound
source in a variety of applications.
Smooth, extended frequency
response combines with wide
dynamic capabilities to provide acous-
tic performance that makes the Con-
trol 5 ideal for recording studios,
audio-video control rooms, remote
trucks and broadcast studios. Clean,
functional visual design makes the
Control 5 also ideal for foreground
music systems, moderate level sound
reinforcement, discotheques and
music playback systems.
A 165 mm (6½ in) low frequency
driver provides solid, powerful bass
response to 50 Hz. High frequency
response to 20 kHz is handled by a
pure titanium 25 mm (1 in) dome.
Both transducers are magnetically
shielded, allowing for use in close
proximity to video monitors. The
dividing network incorporates protec-
tion circuitry to prevent system dam-
age and utilizes high quality com-
ponents including bypass capacitors
for outstanding transient accuracy.
Molded of dense polypropylene
foam, with a finish of black, gray or
white, the Control 5 enclosure offers a
pleasing shape that fits easily into any
environment. Wall, ceiling, rack and
tripod mounting systems allow posi-
tioning of the system in exactly the
right spot for optimum performance.
Control 5
Specifications:
SYSTEM:
Frequency Response (± 3 dB): 75 Hz to 20 kHz
Power Capacity¹: I75 W
Sensitivity
Directivity Factor (Q): 2.8
Directivity Index (DI): 4.5
Nominal Impedance: 4 ohms
Crossover Frequency: 3 kHz
Polarity: Positive Voltage to + terminal causes outward low
GENERAL:
Enclosure Material: Polypropylene structural foam
Finish: Black or white
Dimensions:
Net Weight (each): 4.5 kg (10 lbs)
Shipping Weight (pair): 11 kg (24 lbs)
ACCESSORIES:
MTC-51 Wall Mount Bracket: Allows the Control 5 to be mounted to any rigid vertical
Note: Accessory attachment points on rear of the enclosure are
¹Rating based on test signal of IEC filtered random noise with a peak-to-average ratio of 6 dB, two hours duration.
Sensitivity is based on a swept 500 Hz to 2 5 kHz signal for an input of 2.0 V @ 4 ohms.
2
JBL continually engages in research related to product improvement. New materials, production methods and design
refinements are introduced into existing products without notice as a routine expression of that philosophy. For this
reason. any current JBL product may differ in some respect from its published description but will always equal or
exceed the original design specifications unless otherwise stated.
™
Compact
Control Monitor
Loudspeaker
: 89 dB SPL, 1 W, 1 m (3.3 ft)
2
frequency cone motion,
387 mm H x 251 mm W x 229 mm D
15¼ in H x 9 7/8 in W x 9 in D
surface with a unique polymer ball and clamp design,
In addition to omnidirectional movement about the
ball, the speaker's connecting wires may be run internal
to the clamp. Optional colors.
¼ x 20 threaded brass bushings,
