1 Overview

This document will help you better understand the DO200 Smart Parking Detector, please read
this document before you use the device. The following are introduced separately:
▪ DO200 intelligent parking space detector function introduction (working mechanism)
▪ Test method (working method)
▪ DO200 fast use

2 DO200 Function Introduction (working mechanism)

This product adopts the method of geomagnetic + ultrasonic to detect whether the parking
space is occupied, which greatly improves the accuracy. The following describes the default
parameters, working mechanism, principle, and quick usage of this product.

2.1 Default Parameter Settings

Parameter
(heartbeat) period
reporting interval
Ultrasonic detection
interval
Geomagnetic
detection interval
low battery alarm
threshold
Self-test interval
Note: The above parameters can be modified by commands through the serial port (TTL) or the
platform.
2.2 Detecting the occupancy of parking spaces through
Geomagnetic
By detecting the change in the strength of the magnetic field, it is determined whether the
parking space is occupied. The default detection interval is 10s.

2.3 Detecting the occupancy of parking spaces through Ultrasonic

The distance from the device to the bottom of the vehicle is detected by ultrasonic waves to
determine whether the parking space is occupied. The effective distance is 0-50cm, in which the
parking space is considered occupied, and other cases indicate that it is not occupied. The
default detection interval is 10min.
Beijing Dingtek Technology Corp., Ltd.
http://www.dingtek.com
Room A209, Flounder Business Park, Shunbai Road 12, Chaoyang District, Beijing, China 100022
Setting default
24h
10min
10s
20%
1440min(24h)
DO200 Parking Occupation Sensor
Remark
Periodically report heartbeat data
Detect every 10 minutes without
other triggering conditions
Detecting the magnetic field value
every 10s interval
Low battery alarm when battery is
lower than 20%
Self-calibration interval
