Explanation Of Terminal Connections - Advanced Detection Systems ProScan Max II Installation Manual And Owner's Manual

TERMINAL
RLY 5 Solid state relay output #5 AC
RLY 5 Solid state relay output #5 AC
RLY 4 Solid state relay output #4 AC
RLY 4 Solid state relay output #4 AC
RLY 3 Solid state relay output #3 AC
RLY 3 Solid state relay output #3 AC
INPUT COMM Common input for OPTO,
PULSE, and RESET inputs
OPTO INPUT Input for photo eye
PULSE INPUT Input for external timing pulses
RESET INPUT Input for external reset button
TERMINAL
L IN
N IN
G IN
SW-L OUT
SW-N OUT
SW-L IN
SW-N IN
L OUT
N OUT
G OUT

EXPLANATION OF TERMINAL CONNECTIONS

DESCRIPTION
Power input, hot lead
Power input, neutral lead
Power input, ground lead
Power output to On/Off switch, hot lead
Power output to On/Off switch, neutral lead
Switched power from On/Off switch, hot lead
Switched power from On/Off switch, neutral lead
Power output, hot lead (Used for powering reject devices, etc.)
Power output, neutral lead (Used for powering reject devices, etc.)
Power output, ground lead (Used for powering reject devices, etc.)
TERMINAL
+15 VDC IN Input power for the circuit board
GND
RLY1 COMM Common toggle for output relay #1
RLY1 NC
RLY1 NO
RLY2 COMM Common toggle for output relay #2
RLY2 NC
RLY2 NO
+5 VDC OUT Locally available 5 v source
GND
DESCRIPTION
6
DESCRIPTION
Input ground for the circuit board
Normally closed contact for relay #1
Normally open contact for relay #1
Normally closed contact for relay #2
Normally open contact for relay #2
Ground for local 5 v source
