- Page 1 Manual (Other languages available online www.duratech.be) DLT10-RGB/TW 27-06-22...
-
Page 2: Table Of Contents
Table of contents Technical specifi cations Technical specifi cations Page 3 General specifi cations Box contents Page 4 About the LinkTouch Page 4 Input Voltage: 5 V DC 0,5A Installation instructions Page 5 Interface: LoRa 868 MHz Control functions: pool lights Page 6 USB-C Control functions: heat pump &... -
Page 3: Box Contents
Box contents Installation instructions The LinkTouch is powered using the included AC power adapter and USB power cord Plug the USB power cord into the power adapter 2. Plug the other end of the USB power cord into the USB-C connector of the wall mount. -
Page 4: Control Functions: Pool Lights
Control functions: pool lights Control functions: heat pump & pool cover Pool water Temperature DOWN: Pool water Temperature UP: Press to decrease desired temperature Press to increase desired temperature Colour temperature: Slide to the right to adjust the pool light from “warm white”... -
Page 5: Advanced Control Functions: Pool Lights
Advanced control functions: pool lights How to use the Settings Menu Activate the settings menu (*), then use left the left arrow key to return Touch the display on the LinkTouch to the previous settings menu. SETTINGS for 3 seconds to go into the settings Activate the settings menu (*), menu. -
Page 6: Display: Status Icons
Display: Status icons Safety information Battery: Intended use Battery capacity This device has been developed as a remote control for swimming pool Battery is charging accessories. The LinkTouch should be used only for this purpose, as described in this user guide. Battery error (p.19) Signal: Precautions for Setup... -
Page 7: Connecting To
Connecting to ... Cover operation settings There are 2 modes: SETTINGS Select “Pair Start”-mode from the Deadman switch operation enabled: Pair settings menu. The cover operation will run when pressing and holding the finger start on the button and will stop when releasing the finger from the button. Deadman switch operation disabled: The cover operation will run with a single touch of the button and will stop when touching the button again. -
Page 8: Buzzer Settings
LinkTouch . The beep will also sound when the House of Duratech’s DuraCover is in operation. In case of a third party cover, the beeping sound will not be active. -
Page 9: Temperature Units Display Setting
Temperature units display setting Aux setting The temperature units on the display can be set to Celsius or Fahrenheit This setting will allow the installer to change the cover function to an ON/OFF function for a different device. The “Aux Setting” can be set to “Cover” or “Auxiliary”. SETTINGS Go to “TEMP °C/°F”... -
Page 10: Factory Reset
Resetting the LinkTouch Factory reset You can reset (=reboot) the LinkTouch without loosing the preferred settings. You can reset the LinkTouch to the factory default settings. Resetting the LinkTouch reverts all settings to the factory default settings. Any settings, including wireless connections, that have To reset the Link touch: been changed are lost. -
Page 11: Caring For The Linktouch
LinkTouch . If you need further assistance, please contact your installer or distributor or go to the support section of the House of Duratech website at www.duratech.be/duracare Battery error remove from heat source or take out of sunlight... -
Page 12: How To Upgrade The Link Controller
How to upgrade the Link Controller control board Safety information To upgrade the Link Controller, the following steps need to be taken: Precautions for Cleaning, Transport and Storage Switch of the power of the Link Controller. - Use a soft, damp cloth to clean the exterior of the LinkTouch 2. -
Page 13: Environment / Disposal Of Old Equipment
The dealer will contact the manufacturer for instructions regarding the claim and determine the location of the nearest service point. Declaration of Conformity Declarations of conformity covering this product are available for download from the House of Duratech website: www.duratech.be... - Page 14 Contact details Propulsion Systems bv Dooren 72 1785 Merchtem, Belgium Tel +32 2 461 02 53 www.duratech.be info@propulsionsystems.be We reserve the rights to change all or part of the contents of this document without prior notice...
