- Page 1 User’s Manual IE-703204-G1-EM1 Emulation Board Target Devices V850ES/SA2 V850ES/SA3 Document No. U16622EJ1V0UM00 (1st edition) Date Published September 2003 N CP(K) 2003 Printed in Japan...
- Page 2 [MEMO] User’s Manual U16622EJ1V0UM...
- Page 3 NEC Electronics does not assume any liability for infringement of patents, copyrights or other intellectual property rights of third parties by or arising from the use of NEC Electronics products listed in this document or any other liability arising from the use of such products. No license, express, implied or otherwise, is granted under any patents, copyrights or other intellectual property rights of NEC Electronics or others.
- Page 4 Regional Information Some information contained in this document may vary from country to country. Before using any NEC Electronics product in your application, pIease contact the NEC Electronics office in your country to obtain a list of authorized representatives and distributors. They will verify: •...
- Page 5 Use the IE-703204-G1-EM1 connected to the in-circuit emulator (IE-V850ES-G1). This manual describes the basic setup procedures and switch settings of the IE-703204-G1-EM1 and IE-V850ES-G1. For the part names, functions, and configuration parts of the IE-V850ES-G1, refer to the IE-V850ES-G1 User’s Manual (U16313E) provided separately.
- Page 6 5HODWHG 'RFXPHQWV :KHQ XVLQJ WKLV PDQXDO UHIHU WR WKH IROORZLQJ PDQXDOV 7KH UHODWHG GRFXPHQWV XVHU¶V PDQXDOV LQGLFDWHG LQ WKLV SXEOLFDWLRQ PD\ LQFOXGH SUHOLPLQDU\ YHUVLRQV +RZHYHU SUHOLPLQDU\ YHUVLRQV DUH QRW PDUNHG DV VXFK 'RFXPHQWV 5HODWHG WR 'HYHORSPHQW 7RROV 8VHU¶V 0DQXDOV 'RFXPHQW 1DPH 'RFXPHQW 1XPEHU ,(9(6* ,Q&LUFXLW (PXODWRU IRU 9(6 8(...
-
Page 7: Table Of Contents
1.3 Function Specifications (When Connected to IE-V850ES-G1) ..........13 1.4 System Configuration......................14 1.5 Contents in Carton.........................16 CHAPTER 2 PART NAMES AND FUNCTIONS..................17 2.1 Part Names and Functions of IE-703204-G1-EM1 ...............17 2.2 LEDs Controlled by IE-703204-G1-EM1................19 CHAPTER 3 SETUP PROCEDURE ....................20 3.1 Connecting IE-V850ES-G1 and IE-703204-G1-EM1 with Probe .........20 3.2 Replacing Resonator ......................23... - Page 8 LIST OF FIGURES Figure No. Title Page System Configuration ...........................14 Contents in Carton ............................16 Part Names of IE-703204-G1-EM1 ......................17 LEDs Controlled by IE-703204-G1-EM1 ......................19 Equivalent Circuit A ............................24 Equivalent Circuit B ............................24 Equivalent Circuit C............................25 Equivalent Circuit D............................25 Equivalent Circuit E ............................25 Equivalent Circuit F ............................25...
- Page 9 LIST OF TABLES Figure No. Title Page Pin Correspondence List (V850ES/SA2 Pin Names) ...................28 Pin Correspondence List (V850ES/SA3 Pin Names) ...................31 User’s Manual U16622EJ1V0UM...
-
Page 10: Chapter 1 Outline
V850ES/SA2 and V850ES/SA3. This manual describes the basic setup procedure and the switch settings of the IE-V850ES-G1 when connected to the IE-703204-G1-EM1. For the part names and functions of the IE-V850ES-G1, refer to the separate IE-V850ES-G1 User’s Manual (U16313E). -
Page 11: Product Configuration
1.1 Product Configuration Separately-sold products In-circuit emulator (IE-V850ES-G1) Emulation board The IE-V850ES-G1 can be used as an in-circuit emulator for (IE-703204-G1-EM1) the V850ES/SA2 and V850ES/SA3 by installing the IE-703204-G1-EM1 board. Separately-sold products Sockets General-purpose probes made by TOKYO ELETECH CORPORATION SWEX-100SD-1 SWEX-120SE-1 PC interface board This is a board for connecting the IE-V850ES-G1 to a PC. -
Page 12: Features (When Connected To Ie-V850Es-G1)
1.2 Features (When Connected to IE-V850ES-G1) • Maximum operating frequency: 20 MHz (2.2 V to 2.7 V) • The following pins can be masked. NMI, WAIT, RESET, HLDRQ • The external dimensions of the IE-703204-G1-EM1 are listed below Item Value External dimensions... -
Page 13: Function Specifications (When Connected To Ie-V850Es-G1)
CHAPTER 1 OUTLINE 1.3 Function Specifications (When Connected to IE-V850ES-G1) Item Specification Emulation memory capacity Internal ROM 1 MB For user memory 4 MB Execution/pass detection coverage memory capacity Internal ROM 256 KB External memory 1 MB Memory access detection coverage memory capacity External memory 1 MB Branch destination entry count calculation coverage... -
Page 14: System Configuration
CHAPTER 1 OUTLINE 1.4 System Configuration The system configuration when using the IE-703204-G1-EM1 connected to the IE-V850ES-G1, which itself is connected to a PC (PC-9800 series or PC/AT compatible) is shown below. Figure 1-1. System Configuration <7> <14> Target system <9>... - Page 15 (supplied with this product) <15>: Power supply cable (supplied with IE-V850-G1: Sold separately) Notes 1. The device file can be downloaded from the NEC Electronics website. (URL: http://www.necel.com/micro) These are products of TOKYO ELETECH CORPORATION. For further information, contact Daimaru Kogyo Co., Ltd.
-
Page 16: Contents In Carton
CHAPTER 1 OUTLINE 1.5 Contents in Carton The IE-703204-G1-EM1 package contains the IE-703204-G1-EM1 emulation board, a guarantee card, a packing list, this manual, and an accessory bag. Check whether the accessory bag contains the items listed below. If you find any missing or damaged items, contact an NEC Electronics sales representative or distributor. -
Page 17: Chapter 2 Part Names And Functions
CHAPTER 2 PART NAMES AND FUNCTIONS This chapter describes the part names and functions of the IE-703204-G1-EM1. For the part names and functions of the IE-V850ES-G1, refer to the IE-V850ES-G1 User’s Manual (U16313E). 2.1 Part Names and Functions of IE-703204-G1-EM1 Figure 2-1. - Page 18 CHAPTER 2 PART NAMES AND FUNCTIONS (1) Socket for connecting SWEX-100SD-1 Connect the SWEX-100SD-1 when using the IE-703204-G1-EM1 as the emulator of the V850ES/SA2. (2) Socket for connecting SWEX-120SE-1 Connect the SWEX-120SE-1 when using the IE-703204-G1-EM1 as the emulator of the V850ES/SA3.
-
Page 19: Leds Controlled By Ie-703204-G1-Em1
CHAPTER 2 PART NAMES AND FUNCTIONS 2.2 LEDs Controlled by IE-703204-G1-EM1 Some of the LEDs mounted in the IE-V850ES-G1 are controlled by the IE-703204-G1-EM1. For the LEDs that are controlled by the IE-V850ES-G1, refer to the IE-V850ES-G1 User’s Manual (U16313E). -
Page 20: Chapter 3 Setup Procedure
CHAPTER 3 SETUP PROCEDURE This chapter describes how to connect the IE-703204-G1-EM1 to related products and how to replace the resonator. 3.1 Connecting IE-V850ES-G1 and IE-703204-G1-EM1 with Probe The following shows the procedure to connect the IE-V850ES-G1 and IE-703204-G1-EM1 with the probe. - Page 21 CHAPTER 3 SETUP PROCEDURE <3> With the main board and the IE-703204-G1-EM1 aligned as shown, insert three connectors on each side. At this time align the board so that the socket (YQSOCKET) to connect the prove faces towards the probe exit side.
- Page 22 CHAPTER 3 SETUP PROCEDURE <4> Slowly lower the frame of the IE-V850ES-G1. <5> Replace the front cover of the IE-V850ES-G1. User’s Manual U16622EJ1V0UM...
-
Page 23: Replacing Resonator
CHAPTER 3 SETUP PROCEDURE 3.2 Replacing Resonator The IE-703204-G1-EM1 does not support clock oscillation by the resonator on the target system. Therefore, to change the main clock frequency, replace the resonator mounted in OSC1 (main clock) on the IE-703204-G1-EM1 with a resonator with the desired frequency. After shipment, the following oscillators are mounted as oscillators for generating each clock. -
Page 24: Chapter 4 Cautions
The target interface of the IE-703204-G1-EM1 is one of those shown in Figures 4-1 to 4-12. The target interface processing of each target device is shown in Tables 4-1 and 4-2. - Page 25 CHAPTER 4 CAUTIONS Figure 4-3. Equivalent Circuit C Target system side IE system side µ Port PD70F3204Y Same Emulation CPU potential as V 3.6 V VCCA VCCB P174AVC16245 EP1K100FC484 (Voltage level shifter) (FPGA) Figure 4-4. Equivalent Circuit D Same Same potential potential as V...
- Page 26 CHAPTER 4 CAUTIONS Figure 4-7. Equivalent Circuit G Same Target system side IE system side potential as V 3.6 V VCCA VCCB µ PD70F3204Y G6H-2F REF0 P174AVC16245 Note (Relay) Emulation CPU REF1 (Voltage level shifter) Note Conducts only when the target system is connected. Figure 4-8.
- Page 27 CHAPTER 4 CAUTIONS Figure 4-11. Equivalent Circuit K Target system side IE system side µ PD70F3204Y Emulation CPU Figure 4-12. Equivalent Circuit L Target system side IE system side µ PD70F3204 Emulation CPU Open Open Open 32.768 kHz 27 pF 27 pF Open 1 MΩ...
- Page 28 CHAPTER 4 CAUTIONS Table 4-1. Pin Correspondence List (V850ES/SA2 Pin Names) (1/3) V850ES/SA2 Target Interface Name Processing in In-Circuit Pin No. (V850ES/SA2 Pin Names) Emulator Emulation circuit E REF0 Emulation circuit I Emulation circuit K P80/ANO0 Emulation circuit A P81/ANO1 Emulation circuit A Emulation circuit E REF1...
- Page 29 CHAPTER 4 CAUTIONS Table 4-1. Pin Correspondence List (V850ES/SA2 Pin Names) (2/3) V850ES/SA2 Target Interface Name Processing in In-Circuit Pin No. (V850ES/SA2 Pin Names) Emulator PCS3/CS3 Emulation circuit B PCM0/WAIT Emulation circuit B PCM1/CLKOUT Emulation circuit B PCM2/HLDAK Emulation circuit B PCM3/HLDRQ Emulation circuit B PCT0/WR0...
- Page 30 CHAPTER 4 CAUTIONS Table 4-1. Pin Correspondence List (V850ES/SA2 Pin Names) (3/3) V850ES/SA2 Target Interface Name Processing in In-Circuit Pin No. (V850ES/SA2 Pin Names) Emulator P44/INTP01/TO0 Emulation circuit A P45/INTP10/TI1/TCLR1 Emulation circuit A P46/INTP11/TO1 Emulation circuit A P01/INTP0/TI2 Emulation circuit A P02/INTP1/TI3 Emulation circuit A P03/INTP2/TI4...
- Page 31 CHAPTER 4 CAUTIONS Table 4-2. Pin Correspondence List (V850ES/SA3 Pin Names) (1/3) V850ES/SA3 Target Interface Name Processing in In-Circuit Pin No. (V850ES/SA3 Pin Names) Emulator P70/ANI0 Emulation circuit A P71/ANI1 Emulation circuit A P73/ANI3 Emulation circuit A P713/ANI13 Emulation circuit A P76/ANI6 Emulation circuit A P78/ANI8...
- Page 32 CHAPTER 4 CAUTIONS Table 4-2. Pin Correspondence List (V850ES/SA3 Pin Names) (2/3) V850ES/SA3 Target Interface Name Processing in In-Circuit Pin No. (V850ES/SA3 Pin Names) Emulator P00/NMI Emulation circuit A N.C. Emulation circuit J PDH0/A16 Emulation circuit B PDH2/A18 Emulation circuit B PDH1/A17 Emulation circuit B P30/SI1/RXD0...
- Page 33 CHAPTER 4 CAUTIONS Table 4-2. Pin Correspondence List (V850ES/SA3 Pin Names) (3/3) V850ES/SA3 Target Interface Name Processing in In-Circuit Pin No. (V850ES/SA3 Pin Names) Emulator PDL3/AD3 Emulation circuit B P93/A3/INTP6 Emulation circuit C P94/A4/TO2 Emulation circuit C P911/A11/SO2 Emulation circuit C P914/A14/SO3 Emulation circuit C P915/A15/SCK3...
-
Page 34: Chapter 5 Restrictions
CHAPTER 5 RESTRICTIONS The IE-703204-G1-EM1 has the following restrictions. 5.1 Clock Generator (1) Resonator to be connected Oscillation by the resonator on the target system is not supported. Therefore, clock oscillation operation on the target system cannot be emulated with the in-circuit emulator. -
Page 35: Appendix A Package Drawings
APPENDIX A PACKAGE DRAWINGS (1) NQPACK100SD (unit: mm) TOP VIEW 21.0 0.5 X 24 = 12.0 C 1.5 Slit width 3 – 1.0 + 0.1 14.0 – 0 SIDE VIEW 0.18 15.0 BOTTOM VIEW 17.0 4 – 2.0 Projection height 1.8 Remark NQPACK100SD is a product of TOKYO ELETECH CORPORATION. - Page 36 APPENDIX A PACKAGE DRAWINGS (2) YQPACK100SD (unit: mm) TOP VIEW 16.6 0.5 X 24 = 12.0 3 – 1.0 10.9 13.3 15.7 18.1 SIDE VIEW 0.25 X 0.3 0.25 BOTTOM VIEW C 1.5 13.4 Remark YQPACK100SD is a product of TOKYO ELETECH CORPORATION. User’s Manual U16622EJ1V0UM...
- Page 37 APPENDIX A PACKAGE DRAWINGS (3) HQPACK100SD (unit: mm) TOP VIEW 16.6 0.5 X 24 = 12.0 3 – 1.0 SIDE VIEW 0.23 0.58 BOTTOM VIEW C 1.5 13.4 Remark HQPACK100SD is a product of TOKYO ELETECH CORPORATION. User’s Manual U16622EJ1V0UM...
- Page 38 APPENDIX A PACKAGE DRAWINGS (4) CSICE121A1312N03 (unit: mm) TOP VIEW 16.6 0.4X29=11.6 Pin 1 side 4- 2.2 12.1 Part hole 14.7 17.3 19.9 SIDE VIEW 1.03 0.32 BOTTOM VIEW 0.8X12=9.6 CSICE121A1312N03 121-land diameter : 0.5 Resist diameter : 0.5 CSI-PWB-121A1312N01 MADE IN JAPAN TET Remark CSICE121A1312N03 is a product of TOKYO ELETECH CORPORATION.
- Page 39 APPENDIX A PACKAGE DRAWINGS (5) LSPACK121A1312N01 (unit: mm) TOP VIEW 22.65 0.8X12 = 9.6 LSPACK121A TET MADE IN JAPAN SIDE VIEW BOTTOM VIEW Remark LSPACK121A1312N01 is a product of TOKYO ELETECH CORPORATION. User’s Manual U16622EJ1V0UM...
- Page 40 APPENDIX A PACKAGE DRAWINGS (6) CSSOCKET121A1312N01 (unit: mm) TOP VIEW 0.8X12=9.6 Pin 1 side SIDE VIEW 0.25 0.65 Remark CSSOCKET121A1312N01 is a product of TOKYO ELETECH CORPORATION. User’s Manual U16622EJ1V0UM...
- Page 41 APPENDIX A PACKAGE DRAWINGS (7) CSSOCKET121A1312N01N (unit: mm) TOP VIEW 0.8X12=9.6 Pin 1 side SIDE VIEW 0.25 0.65 Remark CSSOCKET121A1312N01N is a product of TOKYO ELETECH CORPORATION. User’s Manual U16622EJ1V0UM...
- Page 42 APPENDIX A PACKAGE DRAWINGS (8) CSSOCKET121A1312N01S1 (unit: mm) TOP VIEW 0.8X12=9.6 Pin 1 side SIDE VIEW 0.25 0.65 Remark CSSOCKET121A1312N01S1 is a product of TOKYO ELETECH CORPORATION. User’s Manual U16622EJ1V0UM...
- Page 43 APPENDIX A PACKAGE DRAWINGS (9) CSSOCKET121A1312N01 (foot pattern) (unit: mm) External dimensions of LSPACK External dimensions of CSSOCKET 0.8X12=9.6 Pin 1 side 3- 0.8±0.05 121-pad diameter: Through hole: Finished diameter Remarks 1. After CSSOCKET has been fixed on the board by soldering, it is recommended to solder the guide pin of the connector from the lower side of the board or to fix the portion around the connector with resin for reinforcement.
- Page 44 APPENDIX A PACKAGE DRAWINGS (10) SWEX-100SD-1 (unit: mm) TOP VIEW (48) (295±8) (48) SWEX-100SD1 Target MADE IN JAPAN JAPAN (20) (20) Black (45) Ground Wire Remark SWEX-100SD-1 is a product of TOKYO ELETECH CORPORATION. User’s Manual U16622EJ1V0UM...
- Page 45 APPENDIX A PACKAGE DRAWINGS (11) SWEX-120SE-1 (unit: mm) TOP VIEW (55.5) (55.5) (295±8) SWEX-144SD-1 Target JAPAN MADE IN JAPAN SIDE VIEW (24) (24) Black (45) Ground Wire Remark SWEX-120SE-1 is a product of TOKYO ELETECH CORPORATION. User’s Manual U16622EJ1V0UM...
