- Page 1 2016-10-13 0000000342 V.001 3.38.0 93320-001 Flue Gas Recirculation eHACK Operating Instructions...
- Page 2 ETA Heiztechnik Gewerbepark 1 A-4716 Hofkirchen an der Trattnach Tel: +43 (0) 7734 / 22 88 -0 Fax: +43 (0) 7734 / 22 88 -22 info@eta.co.at www.eta.co.at...
-
Page 3: General Information
General information General information Copyright DANGER! All contents of this document are property of ETA On non-compliance with this safety instruction, there is Heiztechnik GmbH and are protected by copyright. a risk of major physical injury. Any reproduction, transfer to third parties or use for other purposes is prohibited without written permission from the owner. -
Page 4: Installation
Mount the maintenance cover with the actuator for flue gas recirculation on the boiler. Tighten the screws evenly and cross-wise. Fig. 2-1: Panel Remove the insulation over the maintenance cover. Fig. 2-4: Maintenance cover with actuator for flue gas recir- culation Fig. 2-2: Insulation www.eta.co.at... - Page 5 Installation Remove the precut cut-out in the insulation. Connect the actuator Connect the cable to the circuit board [GM-C] and connect it to terminals [S506] and [S513]. Fig. 2-5: Insulation Place the insulation over the maintenance cover. Fig. 2-6: Connect the actuator Mount panel on the top Break out the cut-out in the panel for the actuator.
- Page 6 Installation Remount the panel on the top of the boiler again. Fig. 2-8: Panel Slide the cover over the actuator and fasten. Fig. 2-9: Cover www.eta.co.at...
- Page 7 Configuration Configuration Content of this configuration Further configuration and installation Only the steps required for the configuration of this Continue with configuration and installation of the product are described below. heating system as described in the "Configura- tion" manual supplied with the boiler. The configuration of the complete heating system is described in the "Configuration"...
- Page 8 DOWNLOAD www.eta.co.at...
