Sub-Zero IW Series Service Manual

General Information
INTRODUCTION
This Technical Service Manual has been compiled to provide the most recent service information for Integrated Wine
(IW) units. This information will enable the service technician to troubleshoot and diagnose malfunctions, perform
necessary repairs, and return a unit to proper operational condition.
The service technician should read the complete instructions contained in this manual before initiating any repairs.
IMPORTANT SAFETY INFORMATION
Below are Product Safety Labels used in this manual.
The "Signal Words" used are WARNING or CAUTION.
When reviewing this manual, please note these differ-
ent Product Safety Labels placed at the beginning of
certain sections of this manual. You must follow the
instructions given in the boxes of the Product Safety
Labels in order to avoid personal injury and/or product
damage.
The sample Product Safety Labels below illustrate the
precautions that should be taken when the signal word
is observed.
STATES A HAZARD THAT MAY CAUSE SERIOUS
INJURY OR DEATH IF PRECAUTIONS ARE NOT
FOLLOWED.
Indicates a situation where minor injury or product
damage may occur if instructions are not followed.
In addition, please pay attention to the signal word
"NOTE", which highlights information that is espe-
cially important for the topic being covered.
This manual is designed to be used by Certified Service Personnel only. Sub-Zero Group, Inc. assumes
no responsibility for any repairs made on Sub-Zero refrigeration units by anyone other than Certified
Service Technicians.
Information and images contained in this manual are the copyright property of Sub-Zero Group, Inc.
Neither this manual nor any information or images contained herein may be copied or used in whole or in part
#7040158 - Revision B - June, 2015
INTEGRATED WINE (IW) SERIES
INTEGRATED WINE (IW) SERIES
without the express written consent of Sub-Zero Group, Inc.
© Sub-Zero Group, Inc, all rights reserved.
TECHNICAL ASSISTANCE
If you should have any questions regarding a Sub-Zero
appliance and/or this manual, please contact:
Sub-Zero Group, Inc.
ATTN: Service Department
Madison, WI 53744-4988
Customer Assistance
Phone #: (800) 222 - 7820
Facsimile #: (608) 441 - 5887
Technical Assistance
(For Technicians in Customer's Homes Only)
Phone #: (800) 919 - 8324
Parts / Warranty Claims
Phone #: (800) 404 - 7820
Facsimile #: (608) 441 - 5886
Service Department e-mail Address:
customerservice@subzero.com
Main Office Hours:
8:00 AM to 5:00 PM Central Time
Monday through Friday
(24/7 Phone Coverage)
