- Page 1 SKIDDING WINCH W35R OPERATION, MAINTENANCE AND SPARE PARTS MANUAL PLEASE READ THE OPERATING AND MAINTENANCE INSTRUCTIONS BEFORE USING THE MACHINE FROM MACHINE: 300001587 INSTRUCTION MANUAL A-EN-300001587-CS...
-
Page 3: Table Of Contents
FARMI FOREST REPRESENTATIVES ................................. 41 When ordering spare parts, please indicate the serial number of your machine can be found on the machine plate, spare parts order number, description and quantity required. Example. W35R, 94624046, torsion spring, 2 pcs W35R... - Page 5 EC DECLARATION OF CONFORMITY Original declaration of conformity Manufacturer: Farmi Forest Corporation Kilpivirrantie 7, FIN-74120 IISALMI, Finland Person authorized to compile the technical documentation: Name: Petri Pelkonen Address: Kilpivirrantie 7, FIN-74120 IISALMI, Finland Commercial name: Farmi Machine denomination: Skidding winch...
-
Page 6: Introduction
In FARMI winches, there are two different kinds of brakes: models W30F, W35R and W50R are operated with ratchet brake and models W35F, W50B, W60B and W86B with automatically switched on band brake. -
Page 7: Product Warranty
PRODUCT WARRANTY Farmi provides a 12-months warranty on all Farmi products. CUSTOMER FEEDBACK We are happy to receive your opinions and suggestions for improvements https://shop.farmiforest.fi/contactus. All implemented suggestions for improvements will be rewarded. W35R... -
Page 8: General Safety Instructions
7. Never wear loose clothing around moving parts. Protect long hair! 8. Ensure that work is carried out according to the stipulations of applicable occupational health and safety legislation. 9. Before starting up or using the machine, ensure that it cannot cause a risk to other people or property. W35R... -
Page 9: Transport
5. Exercise extreme caution when hitching/unhitching the machine from a tractor/trailer. 6. Look out for moving parts when the machine is in operation. 7. Secure the machine against unauthorized and accidental operation (e.g. moving when parked) whenever it is left unattended. W35R... -
Page 10: Maintenance
4. Check that all hose connectors, lengths and qualities comply with applicable requirements. When replacing or repairing hoses, use original parts or hoses and connectors recommended by the manufacturer. Check particularly that the pressure classes of the hoses and connectors are suitable to the operating pressure levels. W35R... -
Page 11: Safety Instructions For The Winches
13. Ensure the wire cable is as short as possible during transport. 14. The winch may only be used for winching and hauling. Do not use the winch for lifting loads. Noise from the winch exceeds 70 dBs in operation. Wear ear protection! WARNING W35R... -
Page 12: Stickers And Plates
STICKERS AND PLATES These plates and stickers must be found on the winch. Replace missing plates or stickers immediately. 1. Machine plate W35R (200005000) 2. Note! See manual for operation and maintenance. (41014750) W35R... - Page 13 Before doing maintenance work turn off the motor, remove the ignition key and disengage the P.T.O. Accident danger! Keep the safety equipment where it belongs. Winding danger! Do not wear too loose clothes and keep the hair bound inside the cap. W35R...
- Page 14 Do not stand in front of the winch when working. Stand on the side at a distance of at least 6 ft from the winch. Crushing danger! Do not winch downhill. 6. Maximum rpm (42381474) 7. FARMI-sticker (40147110 or 200006218 or 200006179) 8. Sticker W35R (40147250) W35R...
-
Page 15: Main Parts And Accessories
MAIN PARTS AND ACCESSORIES W35R... -
Page 16: Technical Specification
TECHNICAL SPECIFICATION W35R Tractive power Cable drum empty (Maximum) 35 kN Cable drum full (Minimum) 13 kN Cable capacity 50 m of ø 10 mm (164 ft of 25/64”) cable 1,96 kN/mm 2 Ultimate strength of the cable compacted Winching speed... -
Page 17: Mounting
This may cause damage to the bearings of the winch or to the PTO of the tractor. The PTO shaft must not be too short in any position. The PTO length is suitable, if the pipes do not reach the bottom. CAUTION! PTO is optional equipment. W35R... -
Page 18: Fastening The Cable To The Drum
5. Pass the cable end through the hole in the drum plate, pull about 15 cm (6”), and insert under the wedge of the cable lock device. See fig. 3. 6. Tighten the cable lock screw. 7. Winch the cable on the drum. REMEMBER THAT THE CABLE HAS TO BE LOADED HEAVILY, WHEN WINCHING THE CABLE BACK ON THE DRUM. W35R... -
Page 19: Pre-Operation Checks
When installing the safety guard, make sure the clutch does not get caught on the safety guard. CAUTION! CONTROLS Get acquainted with the controllers of the winch before the use, tests the stopping functions of the winch and the tractor and all other functions. Each function has to be in perfect condition. WARNING! W35R... -
Page 20: Disconnecting The Skidding Winch From The Tractor
4. Make sure that the skidding winch cannot fall over during storage. OPERATION SAFETY PRECAUTIONS Read the operation instructions before operating this machine! It is the owner’s responsibility to instruct all equipment operators and support personnel in the operation of this winch. WARNING! W35R... - Page 21 The falling danger of the tractor can be reduced by winching through the lower snatchblock. Fig. 5. Position the tractor in line with the direction of the pull Fig. 6. Do not winch sideways at angles exceeding 30 degrees. The tractor can tilt. W35R...
- Page 22 CAUTION! When wInching an unloaded cable, make sure that the finger guard doesn’t rise up with cable and doesn’t cause cable to crosscut. CAUTION! Fig. 8. Use a keyhole slider to winch several logs at one time. W35R...
-
Page 23: Winching
Avoid extra large loads. The winding speed depends on the number of revolutions of the tractor. Do not wind too fast. 6. Stop winching when the logs are at about 1,5-3 m (5-10 ft) from the tractor. Install the cable on the lower diverting pulley. W35R... -
Page 24: Skidding
Alternatively the skidding chains can be attached to the notched beam. 2. Turn off the P.T.O. 3. Raise the 3-point hitch so that the logs come off ground (fig. 12.). 4. Move the logs to the desired place. W35R... - Page 25 1. Drop the load. Drive the tractor to firm ground. Winch in the load. 2. If you cannot move the tractor, release the load and winch the tractor out. When winching the tractor out, always run the cable under the lower pulley. W35R...
-
Page 26: Maintenance
2. Grease the PTO-shaft regularly and aways before use as shown in figure 15. 3. Grease the drum chain lightly (not with oil) after every 50 working hours with spray type, hardening chain grease. Wipe off the excessive grease. W35R... - Page 27 Roller chains tightness adjustment is carried out by moving the chain tightener. See fig. 17. 1. Loosen the two bolts holding the chain tightener (11/16” or 17 mm wrench). 2. Adjust the chain tightness by moving the chain tightener towards or away from center. W35R...
- Page 28 (e.g. in order to change the roller chain) follow the instructions below: 1. Park the winch on a level, stable ground so that it leans a little backwards. 2. Remove the cable. 3. Remove the fastening bolts (fig. 19 pos. B) beside the drive shaft. Socket size 24 mm (15/16”). W35R...
- Page 29 12 o’clock and 6 o’clock (fig. 20). Be careful, there is only one correct position! Tape the halves together so that htey will stay together when you mount them on the drum axle. 4. Install a protective plate. Check the clutch adjustment. W35R...
- Page 30 Fig. 20. Reassembling of the clutch engagement halves Fig. 21. Correct positioning of the thrust bearings W35R...
-
Page 31: Trouble Shooting
Adjustment of the clutch. See chapter ”Clutch adjustment” Tractor slides Parking brakes are not on. Lock on the parking brakes. Lower backwards when the winch all way to the ground. Dozer blade does not winching anchor the unit firmly to the ground. W35R... -
Page 32: Spare Parts
SPARE PARTS FRAME W35R... - Page 33 Frame 43184360 Upper diverting pulley complete 02721611 Clutch rope L = 5m 02721629 Latch rope L = 3,5m 52842150 Ring splint 10X45 200006024 43184440 Lower diverting pulley complete 7.1 54511159 Slotted sealed ball bearing 7.2 52854346 200006175 Support leg W35R...
- Page 34 MACHINERY W35R...
- Page 35 Clutch engagement half 22 40660235 Roller 23 42722785 Clutch lever 24 200003660 Groove shaft 25 43000108 Chain tightener 26 43000645 Drum lock hatch 27 42723163 28 54820502 Roller chain 29 54542063 Ball thrust bearing 30 54511274 Slotted sealed ball bearing W35R...
- Page 36 MACHINERY W35R...
- Page 37 52062106 Screw M16X30 DIN933 88ZN 52200235 Washer M8 DIN9021 58ZN 52200110 Washer M30 DIN126 58ZN 43010404 Bushing 54642194 Cup spring 99X70.5X1 DIN2093 43100610 Eccentric piece 43010420 Plate 43011410 Sleeve 200003663 Flange 52200490 Washer ZN, M12, DIN7349 43010040 Flat iron W35R...
- Page 38 COVER OF THE UNIVERSAL SHAFT Part Order no Description Remarks 54821756 Cover of the universal shaft 43402180 Fastener of the cover 52060100 Screw M8X12 DIN933 88ZN 52200235 Washer M8 DIN9021 58ZN W35R...
- Page 39 PROTECTIVE SCREEN Part Order no Description Remarks 33185110 Protective screen 52110046 M10 DIN934 8ZN 52060944 Screw M10X60 DIN933 88ZN 52200490 Washer M12 DIN 7349 ZN W35R...
- Page 40 Skidding chain L = 2,5 m LL 2 54813159 Choker (cable 8-12 mm) Steel Rope D8 200006142A Steel Rope with hook D=8mm, L=50m Steel Rope D10 200006142C Steel Rope with hook D=10mm, L=50m Steel Rope D10 200006142D Steel Rope with hook D=10mm, L=65m W35R...
-
Page 41: Warranty
Send faulty parts, carriage paid to the manufacturer for inspection. The reseller of the product helps on that. Repairs will be conducted by Farmi Forest Oy or an authorized expert. The warranty is valid only if the product has been registered according to the manufacturer’s instructions within 30 days of receipt of the product. - Page 42 Farmi Forest Kilpivirrantie 7 74120 IISALMI FINLAND...
