Meta System HPB TOP PLIP Installation Instruction page 15

HPB TOP PLIP
1
COMMANDS
STATIC
6
COMMANDS
HY
STATIC = General arming/disarming commands, usually taken from the engine bars
PSA = Typical arming/disarming commands for PSA group vehicles.
GM = Typical arming/disarming commands for GENERAL MOTORS group vehicles
FIAT = Commands with typical signals for FIAT group vehicles with original flashing and which can be taken from a direction
indicator light.
RNT = Typical arming/disarming commands for RENAULT group vehicles
HY = Typical arming/disarming controls for vehicles manufactured by the HYUNDAI car group
TY/MZ = Typical arming/disarming controls for vehicles manufactured by the TOYOTA/MAZDA car group
CHOOSING THE BEST PRODUCT FOR THE VEHICLE
To determine the best product for a specific vehicle, refer to the product/vehicle list provided on the www.metasystem.it
website; this also confirms whether emergency disarming is possible using the vehicle's original transponder.
To select the correct type of CAN dedicated to a specific vehicle and customise the alarm control unit quickly and
accurately, we recommend using the portable PDC/CAR ALARM PROGRAMMER (fig.15). Also refer to the vehicle installation
files provided on the www.metasystem.it website: these instructions will help you fit a product quickly and correctly.
To alter the override code, the default operating features of the alarm control unit and adapt them to suit a specific
application, we recommend using the portable PDC/CAR ALARM PROGRAMMER.
The software updates for the programmer will be available ON LINE via the CAR ALARM technical section of the
www.metasystem.it website.
ALARM/PDC PROGRAMMER
MetaSystem code: P6987E
If you do not have access to a PDC/CAR ALARM PROGRAMMER, you can carry out all of the selections and
customisations by following the instructions below.
Link up the electronic keys with the product during the initial fitting by following the instructions in section (1).
If no electronic keys have been linked up, turn the instrument panel on (+15) and wait approximately 10 seconds
for the acoustic signal confirming the product has started working.
: LIST OF THE VARIOUS PLIP SIGNALS THAT CAN BE SELECTED
2
COMMANDS
PSA
7
COMMANDS
TY/MZ
MANUAL SET-UP OF THE PRODUCT
QUICK LINK-UP OF ELECTRONIC KEYS
3 COMMANDS
GM
PRODUCT SET-UP
15
4
COMMANDS
FIAT
5
COMMANDS
RNT
Fig. 15
