LUCCA
MEDIA CONSOLE
Item#: 64011
ATTACH YOUR RECEIPT
Keep a copy of your proof of purchase
or order confirmation, which will be
needed if you need to contact us about
warranty coverage.
Purchase date:
Questions, problems, missing parts?
Before returning to your retailer, our Florida-based customer service team is available:
Call toll-free
Email
Live Chat
(866) 985-7877
cservice@welltraveled.net
www.balkenehome.com
SAVE THESE INSTRUCTIONS
FOR FUTURE REFERENCE.
9 am – 9 pm, EST
9 am – 6 pm, EST, Monday – Friday
09292021
Advertisement
Table of Contents
Related Manuals for Balkene Home LUCCA 64011
Summary of Contents for Balkene Home LUCCA 64011
- Page 1 LUCCA MEDIA CONSOLE Item#: 64011 ATTACH YOUR RECEIPT SAVE THESE INSTRUCTIONS Keep a copy of your proof of purchase FOR FUTURE REFERENCE. or order confirmation, which will be needed if you need to contact us about warranty coverage. Purchase date: Questions, problems, missing parts? Before returning to your retailer, our Florida-based customer service team is available: Call toll-free...
-
Page 2: Before You Begin
INFORMATION BEFORE YOU BEGIN Before beginning assembly, make sure all parts are present. Compare parts received with the "Parts List." If any part is missing or damaged, do NOT attempt to assemble the product. Please read and understand this entire manual before attempting to assemble this product. -
Page 3: Parts List
PARTS LIST DESCRIPTION DESCRIPTION DESCRIPTION PART PART PART Top Panel Interior Shelf Base Right Side Top Face Frame Side Backer Base Back Door Rail Center Backer Drawer Front Left Side Bottom Backer Left Drawer Panel Left Face Frame Right Drawer Panel Right Side Left Divider Right Face Frame... -
Page 4: Hardware Contents
HARDWARE CONTENTS Cam Bolt Cam Nut Dowel Shelf Bracket Screw 6x35mm 6x30mm 4x12mm Qty: 26 Qty: 26 Qty: 44 Qty: 8 Qty: 2 Screw Screw Screw Screw Backer Bracket 4x35mm 4x55mm 4x65mm 3x16mm Qty: 14 Qty: 10 Qty: 2 Qty: 12 Qty: 12 Runner Screw Bolt... - Page 5 ASSEMBLY ASSEMBLY NOTE: Use a Phillips-head screwdriver to tighten each Cam Bolt you Insert Cam Bolts into the indicated holes in the install until its threads are fully inserted. Left/Right Face Frames . Use a Phillips-head screwdriver to tighten. Hardware Required: Cam Bolt x6 Place Dowels in the 2nd and 4th holes on the...
- Page 6 ASSEMBLY Install the Drawer Runners on the Left and Right Dividers BACK BACK FRONT FRONT Fully extend the runner to uncover the mounting holes. After attaching the runner to the panel, push runner back into the closed position. Fully extend one Runner and align the inner section along the 3 small holes on the Left Divider .
- Page 7 ASSEMBLY Attach the Door Rail to the Top Face Frame with 3 Hex Bolts . Use the Hex Wrench tighten the Hex Bolts. Hardware Required: Hex Wrench Hex Bolt (6x18mm) x3 Insert 2 Dowels into each end of the Top Face Frame Slide the Dowels on the left end of the Top Face Frame into the corresponding holes on the Left...
- Page 8 ASSEMBLY Install a Cam Bolt in each Base Side Insert the Cam Nut installed in the Left Base Side into the left edge of the Base Back . Insert a Cam in the adjoining hole and turn clockwise to secure the Cam Bolt. Hardware Required: Cam Bolt x2 Cam Nut x2...
- Page 9 ASSEMBLY Insert a total of 8 Cam Bolts into the indicated holes in the underside of the Top Panel Attach each Anchor Bracket near the back edge of the Top Panel using a Screw Hardware Required: Cam Bolt x8 Screw (4x12mm) x2 Anchor Bracket x2 Place 10 Dowels as indicated in the top...
- Page 10 ASSEMBLY Use the Anchor Brackets anchor the unit to the wall for safety. The included hardware is appropriate for drywall installation and requires the use of a drill. If needed, consult a qualified tradesperson or online resources to safely anchor this unit.
- Page 11 ASSEMBLY Choose the desired height to install each Shelf Insert the peg of each Shelf Bracket into the appropriate holes in the interior of the left and right compartments of the unit, with the horizontal tab rotated to the top. Slide the Shelves into place in the left and right compartments.
- Page 12 ASSEMBLY To install the drawer, fully extend both Drawer Runners and slide the drawer into place between them. Secure the Runners to the sides of the Drawer using 2 Screw Bolts Hardware Required: Screw Bolt (4x10mm) x2 Attach 2 Hanger Rollers to each Door as shown using 2 Screws Hanger Roller.
- Page 13 ASSEMBLY Insert a Track Pin into the holes in the Base Panel just in front of the Left/Right Dividers Hang the Doors by resting the wheels of the Roller Hangers on top of the Door Rail and settling the track on the bottom edge of each door onto a Track Pin. Hardware Required: Track Pin x2 Secure each Roller Hanger...
- Page 14 EXTEND YOUR WARRANTY When you purchase a Fire Sense or Balkene Home product from any authorized retailer, you'll have peace of mind in knowing that it comes with a one-year warranty. Extend your warranty for an additional year when you review your item at balkenehome.com within 365 days of purchase.
