Control Bionics NEURONODE Quick Start Manual

W E LC O M E TO T HE CO N T R O L BI O N ICS T EAM
QUICK START GUIDE
WAL L P ORT
CH ARGIN G
BASE
NE UROSTRAP
ACCE SSORY
KI T
Charging Cable;
Non-Adhesive, Reusable
Electrode; and Leadwire
Adapter Base
NE URON ODE
NE UROBAN D
N EE D S U P P O RT?
WE ARE H E R E .
USA +1 85 5 -831 -7521
AU +61 3 9897 3 576
Charging your
neuronode
1. Connect the charging base to the wall port using the
charging cable in the accessory kit. A green light will
appear on the charging base to indicate it's powered.
2. Align the charging indicators on the charging base
with the active electrode indicators (two indentations)
on the NeuroNode
3. While your NeuroNode
two lights on the charging pad: red and green. Once
3
fully charged the red light will turn off.
The signal indicator on the NeuroNode
indicate its battery level when charging.
Yellow: Too Low To Use
Blue: Partially Charged
Green: Fully Charged
Features
3
.
3
is charging, you should see
3
ACT IV E ELECT RODE
IN DI CATORS
The Active Electrode indicators
help you with placement while
using the NeuroNode
mode. They're indicated on the top
of the NeuroNode as two small
3
indentations.
S IG NAL INDI CATOR
The Signal indicator is located
on the top of the device and
changes with use. A solid signal
indicator light means that the
device is in standby; the color of
this light will change according
to the battery levels as previously
the NeuroNode is Bluetooth
3
broadcasting to your device. A
user has successfully made a switch
in either EMG or Spatial mode.
will also
3
in EMG
3
