- Page 1 INcea056_US_CA_FR B71-052 B71-052V80 IMPORTANT, RETAIN FOR FUTURE REFERENCE: READ CAREFULLY ASSEMBLY & INSTRUCTION MANUAL...
- Page 2 WARNING: Read this material before using this product. Failure to do so can result in serious injury. SAVE THIS MANUAL. Do not exceed listed loading rate, evenly distributed. Sudden load movement may briefly create excess load causing product failure. Loading capacity of workbench: 100Kgs Loading capacity of top shelf: 20Kgs Loading rate of drawer: 10Kgs Loading rate of bottom shelf: 20Kgs...
- Page 3 Part No. Components Quantity Part No. Components Quantity Top Shelf (thickness 6mm) Étagère supérieure (épaisseur 6mm) Bench Top (thickness 12mm) Table de travail (épaisseur 12mm) Drawer Bottom (thickness 4.5mm) Fond de tiroir (épaisseur 4,5 mm) Bottom Shelf (thickness 6mm) Étagère inférieure (épaisseur 6mm) M6x14mm Φ6 M4x10mm...
- Page 4 Bottom Shelf 15 Étagère inférieure...
- Page 5 Attach Back Panel To Cabinet Using Bolt ,washer And Nuts.(17,18,19) Fixez le pannel arrière à l'armoire à l'aide de boulons, de rondelles et d'écrous. (17,18,19)
- Page 7 Assemble the drawer handle(23) with Screws, Washers and Nuts( 20,21,22) Assemblez la poignée du tiroir (23) avec les vis, les rondelles et les écrous. (20,21,22) 13 Bench Top 13 Table de travail 14 Drawer Bottom 14 Fond de tiroir...
