Summary of Contents for primatech P250A
- Page 1 PNEUMATIC FLOORING TOOL P250 OPERATING INSTRUCTIONS WARNING Read these instructions thoroughly before using this tool and keep it handy for reference. Revision 10/10 Printed in Canada...
- Page 2 Never leave the tool laying down on its side while the air P250A PRIMATECH PNEUMATIC TOOL supply hose is connected; the tool should always be left on the floor, standing on its plastic base.
- Page 3 Check the compressed air supply hose before connecting to PERATING THE TOOL WHEN THE SAFETY CONTACT IS NOT ensure that they are free from dirt or particles that can alter the FULLY DEPRESSED WILL CAUSE PREMATURE WEAR OR performance of the tool. Pay special attention to any air leaks. Do DAMAGE TO THE DRIVING BLADE PISTON AND CYLINDER not use a compressed air pressure higher than 110 psi (7.6 bar).
- Page 4 TOOL AND FASTENER PREVENTIVE MAINTENANCE This tool requires minimal lubrication. Use only detergent- free oil such as Primatech P-090. Few drops of oil weekly in the air inlet is sufficient. Other types of lubricant may degrade the seals. Check periodically to make sure that all screws are tight. Pay...
- Page 5 , REMOVE ALL FTER ANY MAINTENANCE TO THE TOOL ASTENERS BEFORE CONNECTING AIR AND ACTUATE THE TOOL REPEATEDLY OVER A PIECE OF WOOD OR SUBFLOORING TO INSURE PROPER OPERATION ASSEMBLING THE VALVE All pneumatic components required are packed in a cartridge assembly which is simply inserted into the tool.
- Page 6 Unscrew the head assembly P-606 and take it out of the tool. Depress the safety contact P-562 to ensure that the driving The long arm of a Allen wrench may be inserted into one of blade has engaged the gate/foot assembly guiding channel. hole at the base of head P-606 to help unlock the assembly.
- Page 7 This section will help to diagnose common problems and will give ASTENERS ARE NOT SET COMPLETELY suggestions to solve them. Consult our on-line Technical Support site at www.primatech.ca/support for updated documents and a) First, verify air supply (see 1 above) more tips.
- Page 8 When repair or replacement of part or tool is required, the complete tool or part(s) must be returned to Primatech or at such authorized warranty service point of Primatech, transportation prepaid, with a copy of proof of purchase evidencing that the part or tool is within the warranty period.
