- Page 1 Pressure Fit 200 Gantry Pre Sales Manual Doc No. 993091 Revision of document: A Revision Date: 04.08.2022...
- Page 2 Contents Intended Use ............................3 Warning Notes ............................ 3 Operating Environment ........................3 Technical Specification ..........................4 PFS Gantry Dimensions ........................4 Specifications............................4 Environmental - Storage and Operating Conditions ................5 Normal operating conditions ......................5 Shipping and storage conditions ......................5 Maintenance ............................
- Page 3 ALL OPERATORS should have read the operating instructions and appreciate this warning section. 1. PFS200 are less stable on sloping surfaces. Prism medical recommend that the install of the PFS200 is on a flat and level surface, as well as a flat and level ceiling.
- Page 4 Technical Specification 2.1 PFS Gantry Dimensions All dimensions below are shown in millimetres. Figure 4 2.2 Specifications Dimensions Maximum Height 2750mm Lowest Height 2046mm Maximum Length 514mm Minimum Length 514mm Maximum Width 2973mm Minimum Width 2103mm Internal maximum clearance 2820mm Internal minimum clearance 1950mm Table 3...
- Page 5 +35°C to 70°C (95⁰F to 158⁰F) non-condensing at a water vapour pressure up to 50hPa. Maintenance No service is to be carried out on a Prism PFS200, while transferring a person to reduce the risk of injury. Service must be completed by a Prism Medical UK authorised Service Engineer.
- Page 6 Cleaning Please follow the cleaning guidelines below on cleaning and disinfecting the Gantry. 5.1 General cleaning It is recommended to clean the PFS200 and accessories before the use by a different patient, reducing the risk of cross–contamination. The exterior of the PFS200 can be cleaned using a damp soapy cloth for general cleaning duties. Please ensure the cloth is damp and not wet.
- Page 7 | 7 of 8 993091 – Revision A P a g e...
- Page 8 While every effort has been made to ensure the accuracy of information contained in this pre sales manual, no liability can be accepted by Prism Medical UK for any errors or omissions. Prism Medical UK operates a policy of continuous improvement.
