Navigation; Compass - Interphase Chart Master Chart Master 11 CVS+ User Manual

Auto Info
Keypad Beep
Nav Aids
4.4 UNITS
To select the desired units of measure:
[MENU] + "SETUP" + [ENTER] + "UNITS" + [ENTER]
Distance
Speed
Depth
Altitude
Fuel
Temperature
Wind Speed Unit
4.5

NAVIGATION

To handle the functions related to navigation:
[MENU] + "SETUP" + [ENTER] + "NAVIGATION" + [ENTER]
Coordinate System
Fix Datum
Map Datum
Fix Correction
Compute Correction : Corrects fixes from the positioning instrument. By placing the cursor on the
Correction Offset
4.6

COMPASS

To set the reference heading information such as bearing angles (True or Mag-
netic), the Magnetic Variation source and to enter Compass Calibration values.
User Manual
: Allows displaying information on cartographic object when the cursor is placed
on it. The Automatic Info On Points shows information when the cursor is placed
on points (as Port Services, Tides, lights, wrecks, rocks, buoys, beacons,
obstructions, land markers, etc.). The Automatic Info On All shows information
when the cursor is placed on points, on lines (as Depth contours, Traffic
Separation, Territorial Sea, Cartographic Lines etc.) on areas (Depth, Built-up,
Sea, Attention, Restricted etc.) and on names (on the beginning of the text -hot
spot- or on any of the characters of the name -name message box-). The details
on Land, Source of Data, Cartographic Area and Spot Soundings are not shown.
: Single audio beeps emitted any time the chart plotter keypad is pressed. If the
incorrect key is pressed or the function required cannot be executed, the chart
plotter emits three beeps. The keypad beep can be enabled or disabled from
the menu.
: Allows to set the Nav Aids presentation as US (Draw Nav-Aids using NOAA
symbology) or INTERNATIONAL (Draws Nav-Aids using international symbol-
ogy). When selected it affects Lights, Signals, Buoys & Beacons display.
: Selects the unit for Distance among Nm, Sm, Km.
: Selects the unit for Speed among Kts, Mph, Kmh.
: Selects the unit for Depth among Ft, FM and Mt.
: Selects the unit for Altitude of GPS Antenna on the medium sea level. The
available choices are Ft, FL and Mt.
: Selects the unit for Fuel between Liters or Gallons.
: Selects the unit for Temperature between F or C degrees.
: Selects the unit for Wind Speed among Kts, m/s, Kmh, Bft.
: The possible choices are ddd mm ss (degrees, minutes and seconds), ddd
mm.mm (degrees, minutes and hundred of minutes), ddd mm.mmm (degrees,
minutes and thousands of minutes), TD (TD function allows converting GPS
coordinates to Loran-C coordinates and vice versa, see TD).
: Sets the datum reference used by the GPS receiver connected to (or integrated
in) the chart plotter so that the chart plotter converts the position received from
the GPS to the Map Datum currently selected in the menu in order to match the
position from the GPS with the position on the charts. You must know what
datum reference is used by the GPS and set it in the Fix Datum option.
: Allows selecting any Geodetic Datum reference from the over 100 available on
the chart plotter. Map Datum selection switches to the selected reference datum
applying the datum offsets stored with the charts.
: Turns On/Off the Correction from the positioning system. If the new Correction
is calculated, but the Correction is not enabled, the ship's position is not
changed.
ship's real position and selecting this option, the error is calculated and
internally memorized for appropriate correction, but not applied.
: Allows manual correction of fix position. The correction is entered as X, Y offset
in minutes and thousand of minutes +/- 9.999.
43
