SINGLE AS/90000
SINGLE I/MAC 8503F
ENGLISH
Dental Air Abrasion & Polishing Unit
Installation & Operation Maintenance Manual
ATTENTION:
DO NOT CONNECT TO THE AIR SUPPLY BEFORE READING THIS GUIDE.
40°C
CLASS
AquaCare
80%
User Manual Iss. 19
IIa
I/LIT0101P Issued 06/22
www.velopex.com
15°C
10%
Medical Device
Temperature Limit
1.95KG
EC
REP
MedNet EC-REP GmbH
9051184
1639
Borkstrasse 10 | 48163 Münster
Germany
MEDIVANCE INSTRUMENTS LTD. • Barretts Green Road • Harlesden • London • NW10 7AP
Advertisement
Table of Contents
Related Manuals for AquaCare SINGLE I/MAC 8503F
Summary of Contents for AquaCare SINGLE I/MAC 8503F
- Page 1 SINGLE AS/90000 SINGLE I/MAC 8503F ENGLISH Dental Air Abrasion & Polishing Unit Installation & Operation Maintenance Manual ATTENTION: DO NOT CONNECT TO THE AIR SUPPLY BEFORE READING THIS GUIDE. 40°C CLASS AquaCare User Manual Iss. 19 I/LIT0101P Issued 06/22 www.velopex.com 15°C...
-
Page 2: Table Of Contents
ATTACHING THE FOOT PEDAL INSERTING THE FLUID CONTAINER ASSEMBLING THE HANDPIECE FITTING THE DISPOSABLE FEEDLINE AND TIP CONNECTING THE AIR SUPPLY INSTALLATION TEST REMOVING THE DOSING CHAMBER LID INSERTING THE POWDER CARTRIDGES PREPARING THE AQUACARE FOR FIRST USE AquaCare: Introduction... -
Page 3: Contents
Contents OPERATION FIRST STEPS TO MASTERING THE AQUACARE SUGGESTED TREATMENT METHODS PREPARATIONS BEFORE TREATMENT TREATMENTS - Cleaning - Fissure Caries - Cavity Preparation - Removal of Composite Restorations - Bonding Orthodontic Brackets MAINTENANCE STERILISING THE HANDPIECE HANDPIECE MAINTENANCE TWIN TUBE ASSEMBLY MAINTENANCE... -
Page 4: Indications For Use And Contraindications
Contraindications For Use The AquaCare is not intended for removal of calculus. The AquaCare is not intended for cutting or removal of amalgam. Please refer to INTRODUCTION: SAFETY WARNINGS, Pg 5/6, and read these safety notes carefully before using the machine. -
Page 5: Safety Warnings
ALWAYS AIM TOWARDS THE INCISAL EDGE OF THE TOOTH. The AquaCare may cause soft tissue damage, including inflammation, bleeding, and creation of an air embolism. The AquaCare may cause hard tissue damage, including etching or abrasion of enamel or exposed root surfaces of the teeth. - Page 6 Do not place the unit in direct sunlight. When turning the AquaCare on and off, ensure that the nozzle is aimed into the inlet of your evacuation unit, and that the evacuation unit is switched on.
-
Page 7: Table Of Symbols
2. The Fluid control has approximately 1 rotation from minimum to maximum position, between - and +. 3. The Prophy operating range is normally between 2.5 and 3.0 bar. 4. The Prep operating range is normally between 4.0 and 5.0 bar. AquaCare: Introduction... -
Page 8: Technical Description
READ THIS MANUAL FULLY BEFORE ATTEMPTING TO INSTALL OR USE THE AQUACARE SINGLE MACHINE. The AquaCare is a fluid abrasion unit which cuts by emitting a stream of air, fluid and powder from its handpiece. It can be loaded with two different powders for use in cutting and cleaning operations. -
Page 9: Contents Of The Packaging
Contents PREP PROPHY FEEDLINES / TIPS A. 1 x AquaCare air abrasion unit. B. 1 x Inline Air Filter (see page 40). C. 1 x Three-position foot pedal. D. 1 x Silver 0.6mm handpiece. E. 1 x Gold 0.8mm handpiece. -
Page 10: Aquacare Parts And Features
Dosing Chamber Lid Powder Out Connection Fluid (500ml) Bottle Fluid Out Connection Handpiece Nozzle/Tip Fluid Control Handpiece Power Control Handpiece Handle Air Pressure Gauge ON/OFF Switch Media Gauge Foot Pedal Dosing Chamber Foot Pedal Lifting Arch AquaCare: Parts and Features... -
Page 11: Rear View Of Aquacare
Rear View Of AquaCare Foot Pedal Connection Black (4 Way Tubing) Foot Pedal Connection White FOOT PEDAL (4 Way Tubing) Air In Supply - Blue Foot Pedal Connection Green (4 Way Tubing) Foot Pedal Connection Yellow (4 Way Tubing) Using The Foot Pedal... -
Page 12: Handpiece
Handpiece 23. Fluid Connection 28. Powder Connection 24. Feedline And Tip 29. Handle 25. Nozzle (Range Of Sizes) 30. Twin Tube 26. Handpiece Front 31. Handpiece Holder 27. Hand Grip 32. Check Valve AquaCare: Parts and Features... -
Page 13: Powder Cartridges
Open Dosing Chamber PROPHY PREP Aluminium Oxide 29μ Sodium Bicarbonate For cutting, cavity preparation and For cleaning and polishing composite preparation Aluminium Oxide 53μ Sylc for AquaCare For cutting, cavity preparation and For cleaning and polishing composite preparation AquaCare: Parts and Features... -
Page 14: Siting The Aquacare
Siting The AquaCare Remove the AquaCare from its box and retain the packaging, use to return unit for service as required. If you are using the AquaCare with the Velopex Patient Treatment Centre, place the machine on the top shelf of the trolley, following the instructions received with the trolley. -
Page 15: Attaching The Foot Pedal
B. Connect the foot pedal to the back of the machine by pushing each coloured tube into its colour-corresponding connector. TIP: To disconnect, push the coloured connector into the machine, and gently pull the tube out. AquaCare: Installation... -
Page 16: Inserting The Fluid Container
WARNING: The above fluid container is filled with a 17% alcohol solution. This acts as a biostatic solution in order to reduce biological growth within the fluid system. NOTE: Not for human consumption. Should the AquaCare unit be used with another solution obtained by the user, this must provide the required biostatic effect to ensure the machine’s fluid system cannot sustain biological growth. Failure to follow these guidelines could lead to user or patient contracting an infection or contagion. -
Page 17: Assembling The Handpiece
The tips and feedlines are for one time use only, a new tip and feedline should be used for each patient. To switch tips and feedlines remove the existing feedline tip and discard. Then follow the steps above. Purge the fluid through the system. See Maintenance: Purging the AquaCare Pg 33. AquaCare: Installation... -
Page 18: Connecting The Air Supply
4 - 7 bar FOOT PEDAL NOTE: In hot countries, If the air supply is damp it is recommended that a AquaCare DryAir Box I/MAC8552F is fitted in the air input tubing before connecting the supply to the AquaCare unit. -
Page 19: Installation Test
Installation Test Before adding the powder to complete installation of the AquaCare, you can check that the installation has been performed correctly using the following procedure: A. Check that the machine is off. B. Sterilise the handpiece. Refer to MAINTENANCE: STERILISING THE HANDPIECE, Pg 31. -
Page 20: Removing The Dosing Chamber Lid
DO NOT REMOVE IT, then refit the top insert. All powder cartridges supplied by Velopex are gamma irradiated. The contents are sterile until opened. Powder cartridges must not be refilled as the cartridges are not reusable. WAIT FOR DECOMPRESSION AquaCare: Installation... -
Page 21: Inserting The Powder Cartridges
Inserting The Powder Cartridges PULL OUT PUSH IN CLEAR TAG CLEAR TAG PUSH IN WARNING! DO NOT FULLY REMOVE CLEAR TAG! PULL BACK TO LOCK TAG AquaCare: Installation... -
Page 22: Preparing The Aquacare For First Use
G. The powder needs to be purged whenever you replace a powder cartridge. The MAINTENANCE: PURGING THE AQUACARE, Pg 33. H. The AquaCare is now ready for use when required. Turn off the machine. I. Always place the handpiece back in its holder after use. -
Page 23: First Steps To Mastering The Aquacare
N. After use, turn off machine and always place the handpiece in its holder. CUTTING TRAINING WITH GLASS SLIDES These steps show how the AquaCare cuts through tooth enamel. Observing the effects on the slide show the size/shape of the various cutting techniques available. -
Page 24: Suggested Treatment Methods
Dental Assistant to follow the nozzle with the aspirator. The AquaCare operates with low noise, and has no vibration or heat at the cutting tip. Its ability to cut wet or dry gives it a high flexibility of use. -
Page 25: Preparations Before Treatment
PURGING THE AQUACARE SINGLE, Pg 33. 8. It is recommended that AquaCare Cleaning/Cutting Fluid (AquaSol) should be used in the AquaCare Fluid System. The 500ml bottle supplied with the machine should be discarded when empty and replaced. The fluid can be used with all recommended treatments using this instrument. -
Page 26: Treatments
The most effective way to use fluid abrasion for this procedure is to use the handpiece of the AquaCare as if it were a paintbrush, making light strokes across the surface of the tooth until the surface is clean. With experience, the dentist will be able to work with a high degree of control, the learning curve being similar to that when first using a high speed drill. -
Page 27: Fissure Caries
Media Flow - Slightly under midway position. The AquaCare is of particular use for treating fissure caries. Hold the cutting nozzle about 2mm from the surface of the tooth and direct the particulate beam at the caries. Use it in short bursts, sweeping it along the vein until all the dark caries are removed and the sound tooth structure is revealed. -
Page 28: Cavity Preparation
Media Flow - Slightly above midway position. The procedure for the preparation of a cavity with the AquaCare will depend on the size of the cavity and the extent and type of caries. For small cavities, the cutting nozzle should be held at an angle of between 35 degrees and 45 degrees to the surface being abraded, and about 2mm or 3mm from the surface. -
Page 29: Removal Of Composite Restorations
Media Flow - Slightly above midway position. The AquaCare is very useful for the removal of old composite restorations. Hold the cutting nozzle at an angle of about 45 degrees to the surface of the old composite restoration and about 2mm or 3mm from the surface. -
Page 30: Bonding Orthodontic Brackets
“etched” surface, ready to accept the bonding agent, and the risk of saliva contamination is greatly reduced because the aluminium oxide dries the surrounding mucosa. The same technique can be used to clean the orthodontic brackets. Approx. 2 mm away from the surface. AquaCare: Operation... -
Page 31: Sterilising The Handpiece
20 cycles. The new metal handles can be sterilised untill the surface starts to deteriorate. H. The handpiece should be replaced when cutting efficiency is impaired. This cleaning and sterilising procedure satisfies UK Health Technical Memorandum 2030 Washers-Disinfectors and UK Health Technical Memorandum 2010 Sterilisation. AquaCare: Maintenance... -
Page 32: Handpiece Maintenance
Do not use a handpiece if the hole in the tip of the nozzle is worn to the outer edge or if the abrasive perforates the swan neck tube. The life expectancy in normal use is approx 6 months. Using the AquaCare at its higher power and media setting will lead to higher wear rates on the handpiece. -
Page 33: Purging The Aquacare
Purging The AquaCare PURGING THE FLUID When replacing the fluid bottle, the machine will need to be purged of any air that may have entered the system. A. Turn the media setting to minimum position. This will prevent unnecessary powder being expelled from the handpiece. -
Page 34: Weekly Maintenance
They should be checked for any visible damage whenever the powder is changed. If there is any damage visible, do not use the AquaCare unit until it has been inspected by a Velopex representative or Authorised Distributor. These will also be checked during the annual service and safety check, please see page 39. - Page 35 If you see anything that you are concerned about during this Weekly Maintenance Process, please feel free to contact your service department to discuss the matter. It is best to be sure. A well maintained AquaCare will serve you reliably for many years to come.
-
Page 36: Troubleshooting
Troubleshooting If you are having problems with your AquaCare, please follow the steps below before proceeding further as these will often resolve a problem. 1. Ensure that the compressed air supply is at the specified pressure, connected and 2. Ensure that the unit is switched on. - Page 37 7. If there are also air bubbles in the fluid tube this can indicate a leaking joint. Look along the tube to see where the air bubbles are appearing to find the source of the leak. Check the joint and replace if necessary. AquaCare: Troubleshooting...
- Page 38 NOTE: If the fault cannot be located and repaired by referring to this troubleshooting guide it will be necessary to acquire the services of a Velopex representative or authorised dealer for a more thorough diagnosis and service of the unit. AquaCare: Troubleshooting...
-
Page 39: Annual Service And Safety Check
Annual service and safety check In order to ensure that the AquaCare continues to function safely and reliably, it is important that you contact your Velopex supplier to book an annual service and safety check every 12 months. If during use there is a problem that could not be rectified after following the troubleshooting checks (as detailed on pages 36-38), then a service will be required to rectify the fault. -
Page 40: Recommended And Complementary Accessories
Handpiece Tube Removal Tool I/ASS 8625F Handpiece – 0.6mm Silver I/ASS 8191F Handpiece – 0.8mm Gold I/ASS 8192F 500 ml AquaCare Fluid Bottle (AquaSol) I/PAC 8200F 500 ml Bottle (Empty) I/ASS 8201F 500ml x 6 AquaCare Economy Pack I/PAC 8206F... -
Page 41: Inline Air Filter
Inline Air Filter The AquaCare Device is designed to function using Clean, Dry Air in between 4-7 bar meeting the requirements of ISO 873.1 class 1.4.1. Failure to provide Air to the above requirements as detailed in the Installation &... -
Page 42: Handpiece Instructions
Fully engage both tubes. blue tubing and the cutting tip. NOTE: Slide the key from the narrower tube side. Tilt the key against the body of the handpiece to Remove the tubing. ease off the twin tube. AquaCare: Handpiece Instructions... -
Page 43: Notes
Notes AquaCare: Notes... - Page 44 SINGLE AS/90000 SINGLE I/MAC 8503F ENGLISH Dental Air Abrasion & Polishing Unit Installation & Operation Maintenance Manual www.velopex.com MedNet EC-REP GmbH Borkstrasse 10 | 48163 Münster Germany MEDIVANCE INSTRUMENTS LTD. • Barretts Green Road • Harlesden • London • NW10 7AP AquaCare User Manual Iss.
