Introduction and Overview The Duraklick height safety system HSS-rail in different lengths 1m, 3m und 6m consists of the following components: single fixing point fixing point with cantilever rail curve e.g. 90 ° also available in other angles step in / out rail connector rail switch Spacer...
Page 3
General instructions and preparations The Duraklick HSS is a personal safety device and was spe- cially developed for the Duraklick PV mounting systems. It can be installed on all systems (SR, EW, GR and ECO). The safety The installation of the HSS height safe- system may only be installed by Duraklick certified fitters.
Page 4
1. Planning and requirements Each Duraklick and HSS system is planned by Soltop for the respective PV system and the installing company receives an installation plan. 1. Delivery check Immediately after delivery, check the components for completeness and possible damage.
2. Important dimensions 1.Checking the conditions Before starting the installation, check the dimensions and specifications in the planning with the actual condi- tions. It is possible that a PV system was built differently than originally planned. Very important: - Minimum compound Minimum size of the module field must be 3 x 4 Minimum compound 3 x 4 modules modules.
Page 6
3. Installation of the achor points (short) 1. Position of the short anchor points The short anchor point must be mounted at least 20 mm from the end of the floor rail. So choose the distance of the drilling template accordingly. Distance of min.
Page 7
4. Installation of the lateral anchor points (long) 1. Position of the long anchor points The lateral (long) anchor points are normally placed centrally between the modules. Position of the long anchor points 2. Drilling Drill the 4 holes for mounting the single point stop with 11.5 mm drill bit.
Page 8
5. Installation of the wire rope system The lateral anchor points must be connected to the floor rails behind them by a steel cable. This is the only way they can absorb and distribute the load in an emergency. Rope system for load introduction into the system 1.
Page 9
6. Installation of the guide rails 1. Insert stainless steel screws Insert two M10 x 20 stainless steel screws into each of the guide rails Insert stainless steel screws 2. Insert sliding blocks Place sliding blocks on the EPO to absorb thermal ex- pansion.
Page 10
7. Assembling the fitting pieces 1. Measuring First measure the distance between the rails to be connected (minimum distance = 15 cm). Measure the distance between the rails 2. Assembling the passport pieces Cut best with a chop saw Drill holes for connectors using the drilling template. Drill Ø...
Page 11
1. Insert the fitting pieces Assemble the fitting piece accordingly. Insert it, move the rails apart a bit to make it easier and screw them together with connectors. Assemble the fitting piece accordingly. 2. Tightening the rails on the anchor point After all rails have been mounted, align the system so that it is stress-free.
Page 12
8. Final inspection 1. Final inspection Check the system for tight fit of all connecting ele- ments. Then check the function of the accesses/end stops. 2. Final testwalk Check the supplied „equipment set(s)“ (red case/bag) for completeness and function. Put on the equipment according to the instructions and perform a test walk of the system.
Page 13
